LOCKTON CADELL52 – Commercial & Domestic Electronic Lever Lock (60 mm Backset)
The CADELL52 is a commercial-grade electronic lever set that retrofits directly to Australian mortice lock furniture and easily replaces many knobsets, leversets and deadbolts. Built for heavy traffic environments yet equally at home on premium residences, it combines weather protection, fire performance and modern access control in a clean, stainless-steel form factor.
Key Features
- Retrofits over standard Australian mortice furniture post spacing for fast upgrades
- Unlock with PIN code, fingerprint, RFID tag, Bluetooth/TTLock app or 6-pin C4 oval key override
- IP66 weather rating on both external and internal handles
- Optional gateway for Internet/remote control and code issuance
- Up to 100 fingerprint users, 1,000 RFID tags, unlimited Bluetooth users and custom PIN codes
- Internal handle supplied as passage; convert to turn-snib with the included kit
- Supplied complete with 60 mm mortice, C4 oval cylinder, batteries and fitting hardware
Access & Tech Features
 Fingerprint (100 users) |
 Keypad / PIN (unlimited via app) |
 RFID Tags (up to 1,000) |
 Bluetooth / TTLock App |
 Wi-Fi (via optional gateway) |
 6-pin C4 Oval Key Override |
Suitable Uses
- Commercial premises – apartments, schools, hospitals, government and retail
- Private residences seeking commercial-grade strength and convenience
Fire, Security & Accessibility
- Fire tested up to 2 hours (Firecore) – independent third-party laboratory. Access certification documentation here
- SL8 physical security (with cylinder) and D8 durability (500,000 cycles)
- AS1428.1-2009 (DDA) compliant lever design for access and mobility
Specifications
| Backset / Mortice |
60 mm (SG-ML60) mortice supplied |
| Handle (H × W × D) |
263 × 52 × 22 mm; projection 48 mm |
| Handle material |
Solid stainless steel; 2 mm pressed 304 SS furniture |
| Door thickness / weight |
32–60 mm / 20–120 kg |
| Power / life |
4 × AAA alkaline; ~1 year typical |
| IP rating |
IP66 (external & internal handles) |
| Warranty |
3-year electronic; 10-year mechanical |
What's In The Box
- CADELL52 smart lock handle set
- 60 mm backset mortice lock (SG-ML60)
- 6-pin C4 rekeyable oval cylinder (convertible to restricted)
- 2 × RFID key fobs
- 3 × screw/spindle packs for 32–60 mm doors
- 4 × AAA batteries, fitting template & instruction manual
- Turn-snib conversion kit (internal handle)
Available Variants
| Item Code |
Finish |
Notes |
| CADELL52-SSS-ML60 |
Satin Stainless Steel |
Supplied with SG-ML60 mortice lock |
| CADELL52-BLK-ML60 |
Matte Black |
Supplied with SG-ML60 mortice lock |
