Lockwood 002DX Mechanical Digital Keypad Deadlatch with Lever for Opening Outwards Doors
The Lockwood 002DX Digital DX Deadlatch provides a fully mechanical method of keyless entry, designed for commercial environments where secure access control is required without reliance on power or electronics.
This lock operates using a single programmable PIN code and is suited to open-in doors. It is commonly used in applications where frequent code changes are required to maintain security.
Unlike electronic locks, the Digital DX mechanism operates entirely mechanically, eliminating battery maintenance and wiring requirements while delivering consistent operation in high-use conditions.
View the full range of mechanical keypad locks here:
Digital Mechanical Locks Collection
Designed for frequent use in commercial environments where durability and reliability are essential.
Key Features
- Fully mechanical keypad lock - no batteries or wiring required
- Programmable 4 to 6 digit access code (factory set to 5 digits)
- Designed for open-out doors
- Clutching mechanism protects internal components during forced attack
- Code entry via C button, followed by knob rotation to unlock
- Code automatically cancels after operation
- Inside knob or lever provides free egress at all times
- Bolt holdback function activated by rotating internal knob past 90 degrees
- Suitable for applications requiring frequent code changes
No electronics, no batteries, no wiring. Designed for consistent operation in high-use commercial environments.
Operation
- External Access: Press C button, enter correct code, then turn knob to unlock
- Auto Reset: Code cancels automatically once knob is released
- Internal Access: Free exit via knob or lever at all times
- Holdback: Internal knob rotation past 90 degrees holds latch open
Suitable Uses
- Commercial office entry doors
- Staff-only access areas
- Service and plant rooms
- Utility and maintenance doors
- Areas requiring simple mechanical access control
Specifications
Dimensions – External Keypad
Parts & Components
Frequently Asked Questions
- Does the Lockwood 002DX require power or batteries?
No. This is a fully mechanical lock. It operates independently of electrical power. - How many user codes can be programmed?
This model supports a single user code only. - Can the code be changed at the door?
No. Code changes require removal of the backplate and repositioning internal tumblers. - Are there restrictions on code selection?
Yes. Codes must be 4–6 digits and each digit can only be used once. - Does the lock allow free exit?
Yes. Internal knob or lever provides immediate egress at all times. - Is this a smart lock?
No. This is a mechanical keypad lock with no app or electronic features.
Additional Information
- Mechanical Code System:
Uses internal tumblers rather than electronics, requiring manual code changes. - Single Code Limitation:
Best suited to shared-access environments rather than individual credential systems. - Installation Requirements:
Requires accurate door preparation and spindle cutting to correct length. - Door Frame Reinforcement:
A frame strengthener is typically installed to improve durability at the strike point. - Maintenance:
Clean with mild soap and water. Avoid harsh chemicals. - Fire Door Considerations:
Rubber mounting pad must not be used in fire-rated applications. - System Positioning:
Commonly used in commercial environments where reliability is preferred over electronic features.
Item Code Family – Lockwood 002DX Digital Deadlatch Range
Configurations vary by handle type and door opening direction. Select the correct model to match how the door swings.
Lockwood branded products purchased new in Australia from authorised resellers are covered against defects in materials and workmanship for:
- Mechanical components: 25 years
- Electrical and electronic components: 2 years (excluding batteries)
Lockwood 002 / 530 Mechanical Digital Installations
Lockwood Warranty Overview
Lockwood branded products are covered by manufacturer warranties issued by ASSA ABLOY Australia Pty Ltd. Warranty periods vary depending on product type, mechanical components, electrical elements, and finish category.
This overview summarises the structure of Lockwood warranty coverage. Full terms, exclusions and claim procedures are set out in the official Lockwood Warranty document.
Warranty Periods Summary
Finish Coverage Guide
- Everbrass finishes: up to 25 years against corrosion, tarnishing and discolouration.
- Stainless steel, polished stainless steel, chrome plating and anodised finishes: typically up to 10 years.
- Decorative finishes including Antique Copper, Architectural Bronze, Oil Rubbed Bronze, Aged Brass, Polished Brass, Satin Brass and related variants: typically up to 2 years against corrosion.
- Unlacquered brass finishes will naturally age and change appearance over time. This is not considered a defect.
- Tea staining of stainless steel is not covered where cleaning and maintenance have not been followed.
What the Warranty Covers
- Defects in material and workmanship during the applicable warranty period.
- Assessment by ASSA ABLOY to determine repair, replacement with the same or closest equivalent product, or refund of purchase price.
Common Exclusions
- Normal wear and tear.
- Misuse, abuse, accidental damage or use outside published specifications.
- Improper maintenance or failure to follow care instructions.
- Unauthorised modification, repair or use of non-genuine parts.
- Exposure to corrosive environments including coastal air, salt spray, chemicals or pollution.
- Removal, refitment or associated labour charges.
- Products not originally sold in Australia through authorised channels.
Warranty Claim Process
- Retain proof of original purchase.
- Return the product through the original place of purchase where applicable.
- If claiming directly, obtain a case number before returning goods.
- Products must be securely packed and clearly identified.
- Warranty assessment determines repair, replacement or refund.
Australian Consumer Law
Lockwood warranties operate in addition to rights available under the Australian Consumer Law. Goods come with guarantees that cannot be excluded. Customers may be entitled to a replacement or refund for a major failure and compensation for reasonably foreseeable loss or damage.
Where a product fails to meet acceptable quality standards and the failure does not amount to a major failure, the customer is entitled to repair or replacement.
Official Warranty Document
