Häfele Genesis DL8800 Smart Lock - Coogee Lever - Black
The Häfele Genesis DL8800 is a multi-credential smart lock built on an Australian mortice lock platform. It provides five access methods — touchscreen PIN code, RFID card or tag, fingerprint biometrics, mobile app control, and mechanical key override — and is certified to Australian fire door, lockset, and accessibility standards.
The DL8800 operates on Häfele's Smart Living App platform (available on iOS and Android), providing user management, access history, timed PIN codes, and remote unlock capability. Remote access and app management features require pairing with the Häfele Zigbee Gateway (Cat. 985.03.024, sold separately). Without a gateway, the lock operates fully via its onboard access methods.
The body is constructed from stainless steel with forged steel front and back plates and is factory tested to AS4145.2 (Australian standard for locksets and door hardware). An Australian-profile oval cylinder is included, with master keying options available to suit site keying systems.
The Häfele Genesis DL8800 is tested and certified for use on AU/NZ rated fire doors. Certified for E-Core and Firecore door systems. Pyropanel certification is pending. Tested to AS1530.4 (Fire resistance in construction).
Disability Act Compliance (DDA)
- The DL8800 lever handle is DDA compliant to AS1428.1 (Design for access and mobility).
- The Coogee lever design assists users with limited grip strength or reduced dexterity.
- DDA compliance relates to the lever handle design only and does not imply full building access compliance for the installation.
Key Features
- Five access methods: touchscreen PIN code, RFID card or tag, fingerprint biometrics, mobile app, and mechanical key override.
- Stores up to 300 credentials: 10 administrator IDs, 100 fingerprints, 290 PIN codes, and 290 RFID key cards/tags.
- Australian mortice lock tested to AS4145.2 with a fixed 60mm backset.
- Fire certified to AS1530.4 for use on E-Core and Firecore fire-rated door assemblies.
- DDA compliant Coogee lever handle to AS1428.1.
- IP55 rated - tested for water spray resistance and dust ingress protection.
- Scramble code PIN entry prevents shoulder surfing and code identification from key wear.
- Automatic re-lock function with configurable delay time.
- Low battery warning via voice, tone, and LED indicators.
- USB-C emergency power port for backup access when batteries are depleted.
- Master keying options available: key alike, construction keying, and restricted keying.
- Voice, tone, and LED guided programming for straightforward setup.
- Remote unlock, timed codes, and access history via Häfele Smart Living App (Zigbee Gateway Cat. 985.03.024 required).
- Stainless steel body and levers with forged steel front and back plates.
Access Methods
What's in the Box
- 1 x front and back electronic module
- 1 x mortice lock (split spindles and strikes)
- 1 x Australian oval cylinder and cam
- 2 x mechanical keys
- 2 x Häfele Mifare RFID key cards
- 2 x Häfele Mifare RFID key tags
- 1 x user manual
- 1 x installation template
- 1 x set of fixing screws
- 4 x AA batteries
Suitable Uses
- Residential entry and front doors requiring fire door compliance
- Strata and apartment entry doors with DDA accessibility requirements
- Commercial applications requiring AS4145.2 lockset compliance
- Doors within master keying systems (key alike, construction keying, restricted keying)
- Fire-rated door assemblies using E-Core or Firecore door systems
- Applications requiring multiple access credential types on a single door
Häfele Smart Lock Range - Product Family
Accessories & Spares
Full Specifications
Dimensions
Battery, Power & Backup Access
- Powered by 4 x AA alkaline batteries, included in the complete lock kit.
- Low battery warning is provided via the lock's voice, tone, and LED indicators before batteries are fully depleted.
- USB-C emergency power port allows temporary operation from a portable power bank if batteries are fully depleted, enabling the door to be unlocked while replacement batteries are obtained.
- Mechanical key override provides physical backup entry if electronic access methods are unavailable.
Remote App Access (Optional - Zigbee Gateway Required)
The DL8800 communicates using Zigbee wireless protocol. Remote access features — including remote unlock from anywhere in the world, timed PIN codes, access authorisation management, and access history review — are only available when the lock is paired with the Häfele Zigbee Gateway with Wi-Fi/USB Cable (Cat. 985.03.024, sold separately). The gateway connects to your home or office 2.4GHz Wi-Fi network and bridges the lock to the Häfele Smart Living App. If your router merges 2.4GHz and 5GHz bands, this can cause connectivity issues — see our guide to Wi-Fi band steering and gateway selection before installing.
Without a gateway, the lock operates fully as a standalone unit using its onboard access methods: touchscreen PIN, fingerprint, RFID card/tag, and mechanical key.
Frequently Asked Questions
Does the DL8800 connect directly to my home Wi-Fi?
No. The lock communicates using Zigbee protocol. To access remote features via the Häfele Smart Living App, the lock must be paired with the Häfele Zigbee Gateway (Cat. 985.03.024, sold separately). The gateway connects to your 2.4GHz Wi-Fi network and bridges the lock to the internet. If your router merges 2.4GHz and 5GHz bands, see our article on why smart locks sometimes drop off Wi-Fi for network setup guidance.
Is the DL8800 suitable for fire-rated doors?
Yes. The DL8800 is tested and certified to AS1530.4 for use on AU/NZ fire-rated door assemblies. It is certified for E-Core and Firecore door systems. Pyropanel certification was pending at the time of publication — confirm current status with Häfele Australia before specifying for Pyropanel assemblies. For a full explanation of fire door types and compliance, see our guide to fire door types and smart lock certification and Chapter 05 - Fire Door Smart Locks in the Smart Lock Buyer's Guide.
Can this lock be integrated into a master keying system?
Yes. Order the No Cyl Lock Kit (912.20.787) and pair it with either the MK C4 Oval 570 Cylinder (911.75.222) for C4 master keying, or the MK Restricted Oval 570 Cylinder (911.75.226) for restricted keying systems. Confirm your keying requirements with your locksmith or Häfele distributor before ordering.
What RFID credentials does the DL8800 use?
The lock uses Häfele Mifare credentials. Replacement key cards (912.20.905) and key tags (912.20.906) are available separately. Use Häfele-supplied Mifare credentials for guaranteed compatibility. Third-party Mifare credentials may work but are not manufacturer-confirmed.
My door is thicker than 50mm - can this lock still be fitted?
Yes. An accessory screw pack with extended spindles (Cat. 912.20.785) extends the compatible door thickness range to 50-70mm. For doors 50-70mm thick, an oval cylinder extension piece (Cat. 916.85.190, M4 screws not included) is also available. The standard screw pack included with the kit suits 30-50mm doors.
Additional Information
The DL8800 is certified for use on E-Core and Firecore fire door assemblies to AS1530.4. When specifying for fire door use, confirm that all other hardware in the assembly — including hinges, strikes, and door seals — is also fire rated and compatible. Pyropanel certification was listed as pending in the manufacturer brochure; confirm current certification status with Häfele Australia prior to installation. See also: apartment fire doors - what locks are actually compliant and our overview of asbestos risk in older apartment fire doors before drilling.
The DL8800 supports scramble code entry, which allows additional random digits to be entered before or after the actual PIN code. This prevents observers from identifying the correct code through shoulder surfing or wear patterns on the touchscreen. The scramble digits are ignored by the lock; only the correct sequence within the string unlocks the door.
The No Cyl Lock Kit (912.20.787) is intended for installers integrating the DL8800 into an existing site keying system. A master keyed oval cylinder is ordered separately and fitted at installation. Confirm cylinder suitability with your locksmith or Häfele distributor to ensure compatibility with your existing keying system before ordering.
IP55 confirms the lock has been tested for resistance to water spray from any direction and protection against dust ingress. This makes the lock suitable for installation on external entry doors in residential and light commercial environments. IP55 does not mean fully waterproof — avoid sustained high-pressure water contact or direct immersion. For a plain-English explanation of what IP ratings mean and how they are tested, see Chapter 11 - Australian Smart Lock Standards.
The Coogee lever handle is DDA compliant to AS1428.1 (Design for access and mobility). Compliance relates to the lever handle geometry and operation only — it does not certify the entire installation as accessible under the Disability Discrimination Act 1992. For NDIS, SDA, and aged care applications, refer to Chapter 09 - DDA, NDIS & Accessibility in the Smart Lock Buyer's Guide. The DL8800 is also featured in our guide to DDA smart locks for NDIS and disability housing.
The brochure for this product refers to a total storage capacity of 300 codes. The individual limits are: 10 administrator IDs, 100 fingerprints, 290 PIN codes, and 290 key cards/tags. These pools are not fully independent — total stored credentials must remain within the overall lock memory capacity. Manage credentials through the lock's programming mode or the Häfele Smart Living App.
7-year warranty on mechanical and finish defects, 2-year warranty on electrical components — covers defective materials, components, and faulty workmanship. Proof of purchase required for all claims. Returns & Warranty | Häfele Warranty Information
What's in the Box - Complete Lock Kit (Cat. 912.20.786)
- 1 x front and back electronic module
- 1 x mortice lock (split spindles and strikes)
- 1 x Australian oval cylinder and cam
- 2 x mechanical keys
- 2 x Häfele Mifare RFID key cards
- 2 x Häfele Mifare RFID key tags
- 1 x user manual
- 1 x installation template
- 1 x set of fixing screws
- 4 x AA batteries
Häfele Genesis DL8800 Smart Lock - Real Installations
Häfele Genesis DL8800 - Dimensions
Häfele Genesis DL8800 - Product Brochure
H�fele Warranty
Warranty Summary
How to Make a Claim
- Keep your proof of purchase (receipt or invoice) � this is required for all H�fele warranty claims.
- Contact Terry's Tradies Pty Ltd and its associated websites, trading names, and subsidiaries (including Gold Coast Smart Locks) in the first instance to assess the fault and initiate the claim process.
- If directed to engage H�fele directly, contact them on 1300 185 044 or email customercare@hafele.com.au.
- H�fele will determine whether the product will be repaired, replaced, or refunded at their discretion.
- Reasonable claim expenses are covered by H�fele. Retain any receipts for costs incurred and contact H�fele directly to arrange reimbursement.
Exclusions
This warranty will be voided if:
- The lock is not installed in accordance with H�fele's installation instructions, where that non-compliance gives rise to the fault.
- The lock is installed in an outdoor setting without cover, in direct contact with rain or harsh weather conditions.
- The lock is misused, abused, or operated contrary to the instructions contained in the owner's handbook.
- The lock is used for any purpose other than its intended use.
This warranty does not cover:
- Damage to surface coatings caused by cleaning or maintenance products not recommended in the owner's handbook.
- Defects caused by normal wear and tear, accident, negligence, alteration, or misuse.
- A product that has been dismantled, repaired, or serviced by anyone other than an authorised H�fele service agent.
- Consumable items such as batteries.
Important Notes
Our goods come with guarantees that cannot be excluded under the Australian Consumer Law. You are entitled to a replacement or refund for a major failure, and to compensation for any other reasonably foreseeable loss or damage. You are also entitled to have goods repaired or replaced if they fail to be of acceptable quality and the failure does not amount to a major failure. The benefits of this warranty are in addition to any other rights or remedies you may have under law.
- Repairs carried out under this warranty do not extend or reset the warranty period. The warranty period for any replacement parts fitted ends at the same time as the warranty for the entire product.
- Service call charges apply where a technician attends and the fault is found to be excluded by this warranty, or where the product is found to be in full operating condition � these costs are borne by the owner.
- H�fele offers ongoing service and maintenance agreements through their Service+ Assist program. Contact H�fele on 1300 185 044 or email customercare@hafele.com.au for details.
