Kidde Touchpoint Lock & Bracket - Clay

Kidde Touchpoint Lock & Bracket - Pushbutton Combination Cam Lock

The Kidde Touchpoint Lock with Bracket is a resettable pushbutton combination cam lock designed to replace standard 19 mm cam locks on storage-style cabinets and enclosures. It provides keyless access through a ten-digit changeable combination, with a die cast body and a clutch mechanism to drive the cam. The bracket version is configured for flush mounting into a cabinet door or panel.

Available in Clay and Titanium finishes, both variants are mechanically identical. The lock can be surface mounted or flush mounted depending on the installation requirement. This product is aimed at original equipment manufacturers, facility managers, and tradespeople replacing unreliable key-based or worn combination locks on cabinets, tool chests, petty cash drawers, display cases, and similar enclosures.

Key Features

• Designed to replace standard 19 mm cam locks on storage and enclosure cabinets.
• Solid die cast body for durability in repeated-use environments.
• Ten-digit changeable combination - code can be reset after installation.
• Cam-turning clutch mechanism for reliable latch engagement.
• Bracket version supports flush mounting into a cabinet door or panel.
• No battery, no electronics - fully mechanical operation.
• Suitable for surface mount or flush mount installation.

Suitable Uses

• Cabinet doors currently fitted with a standard 19 mm cam lock where keyless access is preferred.
• Storage cabinets, tool chests, petty cash drawers, liquor cabinets, and supply cupboards.
• Courier pickup boxes, display cases, and KIOSKs requiring a resettable combination.
• OEM applications where the manufacturer specifies a cam lock cut-out.
• Facilities management and maintenance environments where key management is inconvenient.

Available Finish Options

•
  Clay
  (This Product)
  STK SU1798
•
  Titanium
  STK SU1773

Finish selection does not affect functionality or performance. Both Clay and Titanium variants are available as options within this listing.

Kidde Touchpoint - Item Code Family

The Touchpoint bracket model (this product) is suited to flush mount installations where the lock body sits recessed into the panel. The faceplate model (SU1827) is surface mounted and sits proud of the door face. Both versions share the same ten-digit mechanical combination mechanism.

Full Specifications

What's in the Box

• 1 x Kidde Touchpoint pushbutton cam lock body
• 1 x Flush mount bracket
• 1 x Flat cam (1-1/4" centre-to-tip)
• 1 x Offset cam (1-5/8" centre-to-tip, 1/4" offset)
• 1 x 90-degree stop
• 1 x 180-degree stop

Frequently Asked Questions

Will this lock replace a standard 19 mm cam lock?
Yes. The Touchpoint is specifically designed as a drop-in replacement for standard 19 mm cam lock preparations. Confirm that your cabinet has a 19 mm cam lock cut-out before ordering.

Can the combination be changed after installation?
Yes. The combination is resettable. The code can be changed at any time without removing the lock from the cabinet, which is useful when access personnel change.

What is the difference between the bracket model and the faceplate model?
The bracket model (this product) is designed for flush mount installations where the lock body sits recessed into the door. The faceplate model (SU1827) is surface mounted and the faceplate sits proud of the door face. Both use the same ten-digit combination mechanism.

Does the finish (Clay vs Titanium) affect the lock function?
No. Clay and Titanium are finish differences only. The lock mechanism, combination capacity, and cam hardware are identical across both variants.

What cam options are included?
The lock ships with a flat cam (1-1/4" centre-to-tip) and an offset cam (1-5/8" centre-to-tip with a 1/4" offset), along with 90-degree and 180-degree stops. This hardware covers most standard cabinet cam geometries.

Additional Information

Check door preparation before ordering. If you are replacing an existing cam lock, confirm the door preparation is sized for a 19 mm cam lock cut-out. Non-standard cut-outs may require modification and could affect the flush mount result.

Bracket version is suited to tight clearance applications. The flush mount design can help where door or frame clearances are limited and a surface-proud faceplate would interfere with a surrounding panel or frame edge.

Not intended for high-security or exterior door applications. The Touchpoint is designed for storage cabinets and enclosures, not for exterior entry doors, high-security enclosures, or applications requiring certified resistance ratings.

Warranty

Kidde Warranty
Kidde products are covered by a manufacturer's warranty against defects in materials and workmanship. Warranty terms and applicable periods are set by Kidde and apply from the date of purchase. Terry's Locksmiths manages warranty enquiries and claims for products purchased through this store. For Kidde warranty information, contact us or refer to documentation supplied with the product.

PDF Downloads

Download PDF Resources
Kidde Touchpoint Lock - User Guide (PDF)
