Carbine CEL2-BT Digital Bluetooth Deadbolt with Key Override – Matte Black Kit with Batteries
At A Glance
At A Glance
DISPATCHSame Day if Before 11am AEST
FIRE RATINGNot Fire Rated
PIN Code
BluetoothApp
MechanicalKey
RFIDNot Available
The Carbine CEL2-BT Digital Bluetooth Deadbolt (CEL2-BT-DBMBKIT) is the Bluetooth-enabled deadbolt in the Carbine CEL2-BT range. It provides touchscreen PIN code entry, Bluetooth access through the Carbine Connect App, and mechanical key override. It stores up to 200 user PIN codes and supports up to 10 Bluetooth users per lock — all managed through the app or directly on the keypad.
Important — RFID is not available on this model. Unlike the CEL2-3IN1 deadbolt, the Bluetooth deadbolt does not read RFID cards, FOBs, wristbands, stickers, or NFC phones. If RFID access is required, select the CEL2-3IN1-DBMBKIT (PIN + RFID + Key, same Matte Black finish) instead. For Bluetooth and RFID together, the CEL2-BT leverset models support all three access types.
The Carbine Connect App needs no internet connection or gateway — it communicates directly with the lock over Bluetooth. Remote access (unlocking from outside Bluetooth range) is not possible. For short-stay rental automations that need remote access, see: Airbnb smart locks — do you need WiFi?
A Satin Nickel variant (CEL2-BT-DBSNKIT) is also available.
Estimated Dispatch
Usually ships same day if ordered before 11am AEST (excludes weekends and Queensland public holidays).
Usually ships same day if ordered before 11am AEST (excludes weekends and Queensland public holidays).
RFID Not Compatible with Bluetooth Deadbolt Models
This lock does not read RFID cards, key FOBs, wristbands, stickers, or NFC-enabled smartphones — the Bluetooth deadbolt is a PIN, Bluetooth and key product only. If RFID access is required, select the CEL2-3IN1-DBMBKIT (PIN + RFID + Key, Matte Black). For RFID + Bluetooth + PIN, choose one of the CEL2-BT leverset models. See: Buyers Guide Ch03: RFID access methods
This lock does not read RFID cards, key FOBs, wristbands, stickers, or NFC-enabled smartphones — the Bluetooth deadbolt is a PIN, Bluetooth and key product only. If RFID access is required, select the CEL2-3IN1-DBMBKIT (PIN + RFID + Key, Matte Black). For RFID + Bluetooth + PIN, choose one of the CEL2-BT leverset models. See: Buyers Guide Ch03: RFID access methods
Available Finish Options
Satin Nickel
CEL2-BT-DBSNKIT →
Matte Black
(This Product)
STK CEL2-BT-DBMBKIT
Finish selection does not affect functionality, compliance, or performance.
Key Features
- Three access methods: touchscreen PIN code, Bluetooth via the Carbine Connect App, and mechanical key override. See: Buyers Guide Ch03: Bluetooth access
- Stores up to 200 user PIN codes (4–8 digits) and up to 10 Bluetooth users per lock. RFID not supported on this model.
- Carbine Connect App (iOS and Android) — manage users, set time-restricted access, view the event log, and use auto-unlock. See: Carbine Connect Platform Guide
- Three user access types via the app: permanent, time period (limited duration), or scheduled (specific times of day). See: the three passcode types
- Auto-unlock — the phone unlocks the door automatically on approach using GPS and Bluetooth (optional; disabled by default). See: Carbine Connect: Auto-unlock
- Event log records all access activity — viewable in the app when connected to the lock. See: event log and notifications
- Carbine Connect App independently penetration-tested and rated “Low Risk”. See: the SilentGrid security audit
- Guiding code, single-use PIN codes, vacation mode, double authorisation, and auto-lock 10–900 seconds.
- ANSI Grade 2: mechanical 150,000 cycles; electronic 75,000 cycles; salt spray tested to 240 hours.
- IP54 rated exterior module. Fits a 54mm or 38mm bore (adapter collar included); door thickness 35–51mm; backset 60–70mm adjustable. See: Buyers Guide Ch02: Measuring Your Door
- Handing auto-detects after a factory reset when installed on the door. Not fire rated.
Carbine Connect App — Bluetooth Access
The Carbine Connect App (iOS
and Android
) pairs to the lock by scanning the QR code inside the battery compartment. Once paired, the app owner can add up to 10 Bluetooth users by sharing access via QR code, SMS, or email. Users can be given permanent, time-limited, or scheduled access. The event log shows all entry activity. Auto-unlock opens the lock automatically as you approach, using GPS and Bluetooth (requires Location set to “Always”; disabled by default — test before relying on it). Bluetooth range only — no internet, gateway, or remote access. Photograph the QR code immediately after installation and store it safely. See: No remote access explained · Buyers Guide Ch08: Gateway Comparison · Buyers Guide Ch15: App Platforms
The Carbine Connect App (iOS
and Android ) pairs to the lock by scanning the QR code inside the battery compartment. Once paired, the app owner can add up to 10 Bluetooth users by sharing access via QR code, SMS, or email. Users can be given permanent, time-limited, or scheduled access. The event log shows all entry activity. Auto-unlock opens the lock automatically as you approach, using GPS and Bluetooth (requires Location set to “Always”; disabled by default — test before relying on it). Bluetooth range only — no internet, gateway, or remote access. Photograph the QR code immediately after installation and store it safely. See: No remote access explained · Buyers Guide Ch08: Gateway Comparison · Buyers Guide Ch15: App Platforms Access Methods
Fingerprint
Face Recognition
Suitable Uses
- Secondary deadbolt on a door with an existing primary latch, where Bluetooth app management is preferred over RFID credentials.
- Investment properties and short-stay rentals where the host wants app-based user management (share access by QR code or app invitation) without needing RFID cards. See: Airbnb smart locks — do you need WiFi?
- Residential entry where the occupant wants auto-unlock (the phone unlocks the door as they approach). See: Carbine Connect: Auto-unlock feature
- Applications where a cloud-free, no-gateway Bluetooth solution is preferred. See: Buyers Guide Ch08: what a gateway does
- Internal doors, offices and bedrooms where a keyless deadbolt with app control suits the space. Browse smart locks for internal doors, or the full Bluetooth smart lock range.
See also: Deadbolts, peepholes and fire-rated doors · Check clearance between door and security screen · What is bolt throw and why does it matter?
What’s in the Box
- 1 × exterior electronic module with touchscreen keypad (Bluetooth)
- 1 × interior thumbturn housing
- 1 × deadbolt assembly (adjustable 60–70mm backset)
- 1 × C4 keyway cylinder (6-pin, keyed to a 5-pin key)
- 2 × mechanical keys
- 1 × adapter collar (for 38mm bore installation)
- 1 × user manual / product guide
- 1 × set of fixing screws
- 4 × AA alkaline batteries (Duracell Procell)
Note: RFID cards are not included and are not compatible with this model. To add Bluetooth users, download the Carbine Connect App on iOS or Android after installation.
Carbine CEL / CEL2 / CDL2 – Complete Product Family
CEL2-BT deadbolt: RFID not available — Bluetooth and PIN only. CEL2-BT leverset: RFID + Bluetooth + PIN. CDL2: membrane keypad, no RFID, no touchscreen. All KIT part numbers include batteries. See: Carbine CEL & CDL Digital Lock Range — Complete Buyer’s Guide
Accessories & Retrofit Plates
Retrofit plates cover the screw holes left when replacing an older CEL-3IN1 unit — the CEL2 and CEL-3IN1 screw positions do not align. Browse scar and adaptor plates for smart locks.
Full Specifications
Key Dimensions
Manufacturer dimensional drawing. Key measurements: overall height 159.6mm, body width 67.1mm, keypad face height 139mm, adjustable backset 60/70mm, door thickness range 35-51mm. All dimensions in millimetres.
Battery, Power & Backup Access
- Powered by 4 × AA alkaline batteries (Duracell Procell recommended). Do not use lithium or rechargeable batteries — damage from incompatible batteries is not covered under warranty.
- Battery life is approximately 5,000 openings. Install in the correct alternating pattern as shown in the battery compartment. A low-battery warning is given via LED indicator and audible tone before full depletion. See: How long do digital door locks last?
- Mechanical key override provides physical backup entry at all times regardless of battery state or Bluetooth connectivity.
- This KIT version includes batteries.
Frequently Asked Questions
Can I unlock this lock remotely from anywhere?
No. The Carbine Connect App communicates over Bluetooth only. You must be within roughly 10 metres of the lock to control it from the app. There is no cloud connection, gateway, or internet integration. For remote access (for example, letting a tradesperson in while you are away), share a PIN code in advance, or choose a lock that supports remote access via a gateway. See: Carbine Connect: No remote access explained · Buyers Guide Ch08: Gateway Comparison
No. The Carbine Connect App communicates over Bluetooth only. You must be within roughly 10 metres of the lock to control it from the app. There is no cloud connection, gateway, or internet integration. For remote access (for example, letting a tradesperson in while you are away), share a PIN code in advance, or choose a lock that supports remote access via a gateway. See: Carbine Connect: No remote access explained · Buyers Guide Ch08: Gateway Comparison
Why doesn’t this deadbolt support RFID when the leverset BT models do?
This is a hardware design difference between the deadbolt and leverset variants of the CEL2-BT range. The BT leverset models support PIN, RFID, Bluetooth, and key. The BT deadbolt models support PIN, Bluetooth, and key only. If RFID on a deadbolt is required, use the CEL2-3IN1-DBMBKIT (PIN + RFID + Key, no Bluetooth). See: Buyers Guide Ch03: RFID access methods
This is a hardware design difference between the deadbolt and leverset variants of the CEL2-BT range. The BT leverset models support PIN, RFID, Bluetooth, and key. The BT deadbolt models support PIN, Bluetooth, and key only. If RFID on a deadbolt is required, use the CEL2-3IN1-DBMBKIT (PIN + RFID + Key, no Bluetooth). See: Buyers Guide Ch03: RFID access methods
How do I add Bluetooth users to this lock?
Pair the lock to the Carbine Connect App by scanning the QR code inside the battery compartment. Once the Owner account is set up, additional users can be invited by sharing a QR code, SMS, or email through the app. Users can be assigned permanent, time-limited, or scheduled access. Up to 10 Bluetooth users can be active per lock. You must be within Bluetooth range to add or modify users. See: Carbine Connect: User management
Pair the lock to the Carbine Connect App by scanning the QR code inside the battery compartment. Once the Owner account is set up, additional users can be invited by sharing a QR code, SMS, or email through the app. Users can be assigned permanent, time-limited, or scheduled access. Up to 10 Bluetooth users can be active per lock. You must be within Bluetooth range to add or modify users. See: Carbine Connect: User management
Is this lock fire rated?
No. The CEL2-BT deadbolt does not carry fire door certification and is not suitable for fire-rated door assemblies. For fire door applications, use the CEL2-3IN1 or CEL2-BT fire-rated leverset models. See: Buyers Guide Ch05: Fire Door Smart Locks
No. The CEL2-BT deadbolt does not carry fire door certification and is not suitable for fire-rated door assemblies. For fire door applications, use the CEL2-3IN1 or CEL2-BT fire-rated leverset models. See: Buyers Guide Ch05: Fire Door Smart Locks
My door has a 38mm bore hole — will this lock fit?
Yes. An adapter collar is included for 38mm bore hole installation. Remove the screw post and adapter collar from the assembly before fitting, as shown in the installation instructions. See: Buyers Guide Ch02: Measuring Your Door
Yes. An adapter collar is included for 38mm bore hole installation. Remove the screw post and adapter collar from the assembly before fitting, as shown in the installation instructions. See: Buyers Guide Ch02: Measuring Your Door
Additional Information
Protect the pairing QR code:
The QR code in the battery compartment is the only way to pair a new device to the lock. If it is removed or damaged, pairing is no longer possible via the app. Take a photo of the QR code immediately after installation and keep it somewhere safe. For commercial or short-stay rental applications, Carbine recommends removing the QR code label from the lock after photographing it, to prevent unauthorised re-pairing. See: Carbine Connect: setup and critical gotchas
The QR code in the battery compartment is the only way to pair a new device to the lock. If it is removed or damaged, pairing is no longer possible via the app. Take a photo of the QR code immediately after installation and keep it somewhere safe. For commercial or short-stay rental applications, Carbine recommends removing the QR code label from the lock after photographing it, to prevent unauthorised re-pairing. See: Carbine Connect: setup and critical gotchas
Handing — auto-detection on factory reset:
The CEL2-BT deadbolt automatically detects its handing (the direction the bolt throws) after a factory reset, but the lock must be fully installed on the door for this to work correctly. Do not test handing off the door. If the bolt behaviour is reversed after installation, perform a factory reset with the lock on the door and allow the self-calibration cycle (about 30 seconds) to complete. See: Understanding door handing in Australia
The CEL2-BT deadbolt automatically detects its handing (the direction the bolt throws) after a factory reset, but the lock must be fully installed on the door for this to work correctly. Do not test handing off the door. If the bolt behaviour is reversed after installation, perform a factory reset with the lock on the door and allow the self-calibration cycle (about 30 seconds) to complete. See: Understanding door handing in Australia
Cable routing — a critical installation step:
The cable connecting the exterior and interior modules must be seated correctly in the designated channel of the mounting plate. Incorrect routing results in a pinched cable that can cause an unresponsive keypad, a battery cover that won’t close, or the Set button being held down permanently. If the keypad stops responding after the battery cover is installed, suspect the cable first. See: 3 common DIY smart lock installation mistakes
The cable connecting the exterior and interior modules must be seated correctly in the designated channel of the mounting plate. Incorrect routing results in a pinched cable that can cause an unresponsive keypad, a battery cover that won’t close, or the Set button being held down permanently. If the keypad stops responding after the battery cover is installed, suspect the cable first. See: 3 common DIY smart lock installation mistakes
Auto-unlock feature:
Auto-unlock uses GPS and Bluetooth to open the lock automatically as you approach. It requires Location permission set to “Always” (iOS) or “All the time” (Android) and the app running in the background. GPS accuracy and phone settings affect reliability. The lock uses a 200-metre departure threshold and a 10-metre Bluetooth activation range. Test thoroughly before relying on it. Auto-unlock is disabled by default. See: Carbine Connect: Auto-unlock
Auto-unlock uses GPS and Bluetooth to open the lock automatically as you approach. It requires Location permission set to “Always” (iOS) or “All the time” (Android) and the app running in the background. GPS accuracy and phone settings affect reliability. The lock uses a 200-metre departure threshold and a 10-metre Bluetooth activation range. Test thoroughly before relying on it. Auto-unlock is disabled by default. See: Carbine Connect: Auto-unlock
Professional installation available:
Terry’s Locksmiths offers supply and installation on the Gold Coast. See: Site survey and installation services. For self-installation guidance: Buyers Guide Ch12: Installation & Troubleshooting
Terry’s Locksmiths offers supply and installation on the Gold Coast. See: Site survey and installation services. For self-installation guidance: Buyers Guide Ch12: Installation & Troubleshooting
Warranty
Warranty
Carbine products are backed by Davcor Group Pty Ltd, the Australian manufacturer and owner of the Carbine brand, distributed locally through Lock and Key Co. Warranty periods vary by product category:
Carbine products are backed by Davcor Group Pty Ltd, the Australian manufacturer and owner of the Carbine brand, distributed locally through Lock and Key Co. Warranty periods vary by product category:
- Up to 15 years - mechanical hardware, door hardware, cabinet furniture, utility and window locks
- 10 years - padlocks and mechanical digital locks
- 5 years - cylinders and keys
- 12 months - electronic and digital locks, locksmith tools and supplies
Download PDF Resources
Carbine CEL2-BT Deadbolt - Product Guide (Quick Start, Installation & User Guide) (PDF)
46-page guide - quick start and Carbine Connect app pairing, installation (54mm or 38mm bore, 60mm or 70mm backset), the user guide with 200 entry codes, auto-lock and factory reset, plus mechanical, electronic, app and Bluetooth troubleshooting.
46-page guide - quick start and Carbine Connect app pairing, installation (54mm or 38mm bore, 60mm or 70mm backset), the user guide with 200 entry codes, auto-lock and factory reset, plus mechanical, electronic, app and Bluetooth troubleshooting.
Carbine CEL2-BT - Bluetooth Product Brochure (PDF)
Nine-page brochure covering the standard and Bluetooth CEL2 ranges - Carbine Connect app features and access types, a model comparison chart with cycle and salt spray test figures, and the retrofit plates. It confirms the Bluetooth deadbolt holds 200 user codes and does not read RFID credentials.
Nine-page brochure covering the standard and Bluetooth CEL2 ranges - Carbine Connect app features and access types, a model comparison chart with cycle and salt spray test figures, and the retrofit plates. It confirms the Bluetooth deadbolt holds 200 user codes and does not read RFID credentials.
Carbine CEL2 Deadbolt - Installation Instructions (PDF)
Two-page installation sheet for the CEL2 deadbolt - parts list with the reinforced strike plate, door prep template (54mm or 38mm bore, 25mm edge hole, 60mm or 70mm backset, 35-51mm door thicknesses), strike and jamb dimensions, cable routing, batteries, and the automatic bolt-direction step. The physical install matches the Bluetooth deadbolt.
Two-page installation sheet for the CEL2 deadbolt - parts list with the reinforced strike plate, door prep template (54mm or 38mm bore, 25mm edge hole, 60mm or 70mm backset, 35-51mm door thicknesses), strike and jamb dimensions, cable routing, batteries, and the automatic bolt-direction step. The physical install matches the Bluetooth deadbolt.
Carbine CEL2-3IN1 - Troubleshooting Guide (PDF)
14-page problem, cause and fix guide for CEL2-3in1 and CEL-3in1 leversets and deadbolts - unresponsive keypad, overheating, passage mode, motor and programming faults, deadbolt handing, Bluetooth issues with the Carbine Connect app, battery tips and factory reset.
14-page problem, cause and fix guide for CEL2-3in1 and CEL-3in1 leversets and deadbolts - unresponsive keypad, overheating, passage mode, motor and programming faults, deadbolt handing, Bluetooth issues with the Carbine Connect app, battery tips and factory reset.
Carbine CEL2 Electronic Digital Lock Range Brochure (PDF)
10-page brochure for the standard CEL2 (non-Bluetooth) range - leverset, deadbolt and fire-rated leverset - with the retrofit plate part numbers and shared physical specs (54mm bore, 35-51mm door, 60-70mm backset, C4 keyway). Note the code and auto-lock figures on this sheet describe the standard CEL2, not the Bluetooth model.
10-page brochure for the standard CEL2 (non-Bluetooth) range - leverset, deadbolt and fire-rated leverset - with the retrofit plate part numbers and shared physical specs (54mm bore, 35-51mm door, 60-70mm backset, C4 keyway). Note the code and auto-lock figures on this sheet describe the standard CEL2, not the Bluetooth model.
Carbine CEL2 Deadbolt Retrofit Plate (CEL2-DB-RP) - Spec Sheet (PDF)
One-page dimensioned drawing of the deadbolt retrofit plate - 75 x 147mm and 1.6mm thick with a 55mm cut-out, in brushed 304 stainless steel (CEL2-DB-RP-SS) or satin black (CEL2-DB-RP-BLK).
One-page dimensioned drawing of the deadbolt retrofit plate - 75 x 147mm and 1.6mm thick with a 55mm cut-out, in brushed 304 stainless steel (CEL2-DB-RP-SS) or satin black (CEL2-DB-RP-BLK).
Carbine CEL2-BT Deadbolt — FAQ, Setup and Owner’s Guide
Everything a buyer, installer or owner tends to ask about the Matte Black Bluetooth deadbolt (CEL2-BT-DBMBKIT). For the wider picture, see the Smart Lock FAQ chapter and the Carbine CEL & CDL Buyer’s Guide.
Access & Credentials
How do you unlock this deadbolt?
Three ways: a 4–8 digit PIN code on the touchscreen, the Carbine Connect App over Bluetooth, or the mechanical key. It holds up to 200 user PIN codes and up to 10 Bluetooth users. There is no RFID, fingerprint, face or Wi-Fi on this model. Compare the credentials in Buyers Guide Ch03: Access Methods.
Three ways: a 4–8 digit PIN code on the touchscreen, the Carbine Connect App over Bluetooth, or the mechanical key. It holds up to 200 user PIN codes and up to 10 Bluetooth users. There is no RFID, fingerprint, face or Wi-Fi on this model. Compare the credentials in Buyers Guide Ch03: Access Methods.
Can I add RFID cards or fobs later?
No. The Bluetooth deadbolt has no RFID reader, so cards, fobs, wristbands, stickers and NFC phones will not work on it — and that cannot be added afterwards. If you want RFID on a deadbolt, the CEL2-3IN1-DBMBKIT reads RFID (but has no Bluetooth); to have RFID and Bluetooth together you need a leverset such as the CEL2-BT-SL8MBKIT. The compatible Carbine credentials — card, fob, sticker, wristband and ultra fob — all work on the RFID-capable models, not on this one.
No. The Bluetooth deadbolt has no RFID reader, so cards, fobs, wristbands, stickers and NFC phones will not work on it — and that cannot be added afterwards. If you want RFID on a deadbolt, the CEL2-3IN1-DBMBKIT reads RFID (but has no Bluetooth); to have RFID and Bluetooth together you need a leverset such as the CEL2-BT-SL8MBKIT. The compatible Carbine credentials — card, fob, sticker, wristband and ultra fob — all work on the RFID-capable models, not on this one.
How many PIN codes can it hold, and what length?
Up to 200 user codes, each 4 to 8 digits. It also supports single-use codes (4-digit, in limited sets), a guiding code (type random digits before or after the real code to hide it from onlookers), and double authorisation (two codes required to open). The default programming code is 12345678 — change it before use.
Up to 200 user codes, each 4 to 8 digits. It also supports single-use codes (4-digit, in limited sets), a guiding code (type random digits before or after the real code to hide it from onlookers), and double authorisation (two codes required to open). The default programming code is 12345678 — change it before use.
What key does it use, and can it be rekeyed?
A C4 keyway cylinder (6-pin PD style, supplied keyed to a 5-pin key) with two keys in the box. The mechanical key is a full backup that always works, regardless of battery or Bluetooth state. A locksmith can rekey the cylinder to an existing C4 key system.
A C4 keyway cylinder (6-pin PD style, supplied keyed to a 5-pin key) with two keys in the box. The mechanical key is a full backup that always works, regardless of battery or Bluetooth state. A locksmith can rekey the cylinder to an existing C4 key system.
Carbine Connect App & Remote Access
Can I let someone in while I’m away from home?
Not through the app in real time — Carbine Connect is Bluetooth only, so you must be within about 10 metres to operate the lock from your phone. To give access remotely, set up a PIN code (permanent, time-limited or scheduled) in advance while you are at the lock; the visitor then uses that code. If you need to grant or revoke access from anywhere, choose a gateway-connected lock instead. See: the no-remote-access reality · Buyers Guide Ch08: gateways.
Not through the app in real time — Carbine Connect is Bluetooth only, so you must be within about 10 metres to operate the lock from your phone. To give access remotely, set up a PIN code (permanent, time-limited or scheduled) in advance while you are at the lock; the visitor then uses that code. If you need to grant or revoke access from anywhere, choose a gateway-connected lock instead. See: the no-remote-access reality · Buyers Guide Ch08: gateways.
How does auto-unlock work, and is it reliable?
Auto-unlock uses your phone’s GPS and Bluetooth to open the lock as you walk up to the door. It is optional and off by default. It needs Location set to “Always” and the app running in the background; the lock uses a 200-metre departure threshold and a roughly 10-metre Bluetooth activation range. Reliability depends on GPS accuracy and phone power settings, so test it thoroughly before you depend on it. See: Carbine Connect: auto-unlock.
Auto-unlock uses your phone’s GPS and Bluetooth to open the lock as you walk up to the door. It is optional and off by default. It needs Location set to “Always” and the app running in the background; the lock uses a 200-metre departure threshold and a roughly 10-metre Bluetooth activation range. Reliability depends on GPS accuracy and phone power settings, so test it thoroughly before you depend on it. See: Carbine Connect: auto-unlock.
Does it keep a record of who came and went?
Yes. The event log records access activity and is viewable in the app when you are connected to the lock over Bluetooth. Because there is no gateway, the log is not pushed to you remotely — you read it next time you are within range. See: event log and notifications.
Yes. The event log records access activity and is viewable in the app when you are connected to the lock over Bluetooth. Because there is no gateway, the log is not pushed to you remotely — you read it next time you are within range. See: event log and notifications.
Is the app secure?
The Carbine Connect App was independently penetration-tested and rated “Low Risk”. Because it is Bluetooth-only with no cloud account, there is no internet-facing service to attack when you are away from the lock. See: the SilentGrid security audit.
The Carbine Connect App was independently penetration-tested and rated “Low Risk”. Because it is Bluetooth-only with no cloud account, there is no internet-facing service to attack when you are away from the lock. See: the SilentGrid security audit.
Door Fit & Installation
Will it fit my door?
It suits doors 35–51mm thick with an adjustable 60–70mm backset (a 127mm backset is not supported). It fits a standard 54mm bore, and a 38mm bore using the included adapter collar. Measure before you order — see Buyers Guide Ch02: backset and door thickness.
It suits doors 35–51mm thick with an adjustable 60–70mm backset (a 127mm backset is not supported). It fits a standard 54mm bore, and a 38mm bore using the included adapter collar. Measure before you order — see Buyers Guide Ch02: backset and door thickness.
The bolt throws the wrong way after fitting — how do I fix the handing?
The deadbolt sets its own handing during a factory reset, but only when it is installed on the door. Do not test it off the door. If the bolt behaves backwards after fitting, factory reset the lock while it is on the door and let the self-calibration cycle (about 30 seconds) finish. See: understanding door handing.
The deadbolt sets its own handing during a factory reset, but only when it is installed on the door. Do not test it off the door. If the bolt behaves backwards after fitting, factory reset the lock while it is on the door and let the self-calibration cycle (about 30 seconds) finish. See: understanding door handing.
The keypad went dead after I put the battery cover on. What happened?
Almost always a pinched connecting cable. The cable between the outside and inside modules has to sit in its channel on the mounting plate; if it is crushed when the cover goes on, the keypad can stop responding, the cover may not close, or the Set button can be held down. Re-route the cable first. See: 3 common DIY installation mistakes and Buyers Guide Ch12: troubleshooting.
Almost always a pinched connecting cable. The cable between the outside and inside modules has to sit in its channel on the mounting plate; if it is crushed when the cover goes on, the keypad can stop responding, the cover may not close, or the Set button can be held down. Re-route the cable first. See: 3 common DIY installation mistakes and Buyers Guide Ch12: troubleshooting.
I’m replacing an older CEL-3IN1 — will the old screw holes show?
The CEL2 and CEL-3IN1 screw positions do not line up, so an upgrade can leave visible holes. The CEL2 deadbolt retrofit plate (CEL2-DB-RP-SS brushed stainless or CEL2-DB-RP-MB Matte Black, 75 x 147mm) covers the external-side holes. Browse scar and adaptor plates.
The CEL2 and CEL-3IN1 screw positions do not line up, so an upgrade can leave visible holes. The CEL2 deadbolt retrofit plate (CEL2-DB-RP-SS brushed stainless or CEL2-DB-RP-MB Matte Black, 75 x 147mm) covers the external-side holes. Browse scar and adaptor plates.
Power, Weather & Compliance
What batteries does it take and how long do they last?
Four AA 1.5V alkaline batteries (Duracell Procell recommended, included in the KIT), giving roughly 5,000 openings. Do not use lithium or rechargeable batteries — damage from incompatible batteries is not covered by warranty. A low-battery warning (LED and tone) sounds before the batteries are exhausted, and the mechanical key is always there as backup. See: how long do digital door locks last?
Four AA 1.5V alkaline batteries (Duracell Procell recommended, included in the KIT), giving roughly 5,000 openings. Do not use lithium or rechargeable batteries — damage from incompatible batteries is not covered by warranty. A low-battery warning (LED and tone) sounds before the batteries are exhausted, and the mechanical key is always there as backup. See: how long do digital door locks last?
Can it go on an exposed outside door?
The exterior module is rated IP54, which covers everyday weather on a typical front door. The IP rating applies to the outside module only; the internal module houses the battery compartment and electronics and is for interior use. For a door fully exposed to driving rain, add weather protection or an awning. See: Buyers Guide Ch11: IP ratings.
The exterior module is rated IP54, which covers everyday weather on a typical front door. The IP rating applies to the outside module only; the internal module houses the battery compartment and electronics and is for interior use. For a door fully exposed to driving rain, add weather protection or an awning. See: Buyers Guide Ch11: IP ratings.
How does it hold up near the coast?
Carbine salt spray tests the CEL range to 240 hours. That is a laboratory cabinet test — the lock is sealed in a continuous salt fog and the hours are how long the finish went before corrosion appeared — not a warranty for coastal service. In a salt-air location, rinse the lock periodically and keep it out of constant spray. See: Buyers Guide Ch11: AS4145 corrosion.
Carbine salt spray tests the CEL range to 240 hours. That is a laboratory cabinet test — the lock is sealed in a continuous salt fog and the hours are how long the finish went before corrosion appeared — not a warranty for coastal service. In a salt-air location, rinse the lock periodically and keep it out of constant spray. See: Buyers Guide Ch11: AS4145 corrosion.
Can it go on a fire door?
No. This deadbolt is not fire rated and must not be fitted to a fire-rated door assembly. On an apartment fire door, a deadbolt is generally not the compliant secondary option in any case — a fire-rated deadlatch is. For a fire-rated Carbine, step up to a CEL2-3IN1 or CEL2-BT fire-rated leverset. See: Buyers Guide Ch05: fire door core types · the compliant secondary option.
No. This deadbolt is not fire rated and must not be fitted to a fire-rated door assembly. On an apartment fire door, a deadbolt is generally not the compliant secondary option in any case — a fire-rated deadlatch is. For a fire-rated Carbine, step up to a CEL2-3IN1 or CEL2-BT fire-rated leverset. See: Buyers Guide Ch05: fire door core types · the compliant secondary option.
Is it suitable for a busy commercial door?
It is ANSI Grade 2, tested to 150,000 mechanical and 75,000 electronic cycles — fine for residential and light-commercial use. The CEL2-BT leverset models carry higher cycle figures (500,000 mechanical / 250,000 electronic) if the door sees heavy traffic. Compare the range in the Carbine range-at-a-glance table.
It is ANSI Grade 2, tested to 150,000 mechanical and 75,000 electronic cycles — fine for residential and light-commercial use. The CEL2-BT leverset models carry higher cycle figures (500,000 mechanical / 250,000 electronic) if the door sees heavy traffic. Compare the range in the Carbine range-at-a-glance table.
Choosing the Right Model
Deadbolt or leverset — which do I need?
A deadbolt is a secondary bolt with no handle; it suits a door that already has a working latch and you want a second, app-managed lock. If the door needs its handle and latch replaced too, choose a CEL2 leverset instead. See: secondary locks explained.
A deadbolt is a secondary bolt with no handle; it suits a door that already has a working latch and you want a second, app-managed lock. If the door needs its handle and latch replaced too, choose a CEL2 leverset instead. See: secondary locks explained.
How is this different from the CEL2-3IN1 deadbolt and the CDL2 deadbolt?
This CEL2-BT deadbolt adds the Carbine Connect app (Bluetooth, 200 PIN codes) but drops RFID. The CEL2-3IN1-DBMBKIT keeps RFID and PIN (100 combined) but has no app. The entry-level CDL2-DB is PIN and key only (10 codes, membrane keypad, no touchscreen, no app). Pick by whether you value app control (this model), RFID cards (CEL2-3IN1), or lowest cost (CDL2).
This CEL2-BT deadbolt adds the Carbine Connect app (Bluetooth, 200 PIN codes) but drops RFID. The CEL2-3IN1-DBMBKIT keeps RFID and PIN (100 combined) but has no app. The entry-level CDL2-DB is PIN and key only (10 codes, membrane keypad, no touchscreen, no app). Pick by whether you value app control (this model), RFID cards (CEL2-3IN1), or lowest cost (CDL2).
Is it available in another finish?
Yes — this is the Matte Black kit; the same lock is also sold in Satin Nickel (CEL2-BT-DBSNKIT). Finish does not change function, compliance or performance.
Yes — this is the Matte Black kit; the same lock is also sold in Satin Nickel (CEL2-BT-DBSNKIT). Finish does not change function, compliance or performance.
Related products, guides and chapters
Deadbolt alternatives: CEL2-BT-DBSNKIT (Satin Nickel) · CEL2-3IN1-DBMBKIT (RFID, no app) · CEL2-3IN1-DBSNKIT · CDL2-DB (PIN only)
Step up to a Bluetooth leverset (adds RFID): CEL2-BT-SL8MBKIT · CEL2-BT-SL8SNKIT · fire-rated: CEL2-BT-SL8MB-FRKIT · CEL2-BT-SL8SN-FRKIT
Retrofit plates: browse scar & adaptor plates for smart locks. Browse the range: Bluetooth smart locks · PIN-code smart locks · internal-door smart locks · all Carbine
Buyer’s Guide chapters: Ch 02 Measuring Your Door · Ch 03 Access Methods · Ch 05 Fire Doors · Ch 08 Gateways · Ch 11 Standards & IP · Ch 12 Installation & Troubleshooting · Ch 13 Smart Lock FAQ · Ch 15 App Platforms
Helpful reading: Carbine Connect Platform Guide · Carbine CEL & CDL range Buyer’s Guide · Airbnb smart locks — do you need WiFi? · What is bolt throw?
What’s in the Box – CEL2-BT-DBMBKIT
- 1 × exterior electronic module with touchscreen keypad (Bluetooth)
- 1 × interior thumbturn housing
- 1 × deadbolt assembly (adjustable 60–70mm backset)
- 1 × C4 keyway cylinder (6-pin, keyed to a 5-pin key)
- 2 × mechanical keys
- 1 × adapter collar (for 38mm bore installation)
- 1 × user manual / product guide
- 1 × set of fixing screws
- 4 × AA alkaline batteries (Duracell Procell)
Note: RFID cards are not included and are not compatible with this model. Bluetooth users are added via the Carbine Connect App after installation.
Carbine CEL2 Deadbolt - Dimensions
Manufacturer dimensional drawing. Key measurements: overall height 159.6mm, body width 67.1mm, keypad face height 139mm, adjustable backset 60/70mm, door thickness range 35-51mm. All dimensions in millimetres.
Carbine CEL2-BT – Bluetooth Product Brochure
Page 1
Page 2
Page 3
Page 4
Page 5
Page 6
Page 7
Page 8
Page 9
PDF Files - Carbine CEL2-BT Deadbolt
Carbine CEL2-BT Deadbolt - Product Guide (Quick Start, Installation & User Guide) (PDF)
46-page guide - quick start and Carbine Connect app pairing, installation (54mm or 38mm bore, 60mm or 70mm backset), the user guide with 200 entry codes, auto-lock and factory reset, plus mechanical, electronic, app and Bluetooth troubleshooting.
46-page guide - quick start and Carbine Connect app pairing, installation (54mm or 38mm bore, 60mm or 70mm backset), the user guide with 200 entry codes, auto-lock and factory reset, plus mechanical, electronic, app and Bluetooth troubleshooting.
Carbine CEL2-BT - Bluetooth Product Brochure (PDF)
Nine-page brochure covering the standard and Bluetooth CEL2 ranges - Carbine Connect app features and access types, a model comparison chart with cycle and salt spray test figures, and the retrofit plates. It confirms the Bluetooth deadbolt holds 200 user codes and does not read RFID credentials.
Nine-page brochure covering the standard and Bluetooth CEL2 ranges - Carbine Connect app features and access types, a model comparison chart with cycle and salt spray test figures, and the retrofit plates. It confirms the Bluetooth deadbolt holds 200 user codes and does not read RFID credentials.
Carbine CEL2 Deadbolt - Installation Instructions (PDF)
Two-page installation sheet for the CEL2 deadbolt - parts list with the reinforced strike plate, door prep template (54mm or 38mm bore, 25mm edge hole, 60mm or 70mm backset, 35-51mm door thicknesses), strike and jamb dimensions, cable routing, batteries, and the automatic bolt-direction step. The physical install matches the Bluetooth deadbolt.
Two-page installation sheet for the CEL2 deadbolt - parts list with the reinforced strike plate, door prep template (54mm or 38mm bore, 25mm edge hole, 60mm or 70mm backset, 35-51mm door thicknesses), strike and jamb dimensions, cable routing, batteries, and the automatic bolt-direction step. The physical install matches the Bluetooth deadbolt.
Carbine CEL2-3IN1 - Troubleshooting Guide (PDF)
14-page problem, cause and fix guide for CEL2-3in1 and CEL-3in1 leversets and deadbolts - unresponsive keypad, overheating, passage mode, motor and programming faults, deadbolt handing, Bluetooth issues with the Carbine Connect app, battery tips and factory reset.
14-page problem, cause and fix guide for CEL2-3in1 and CEL-3in1 leversets and deadbolts - unresponsive keypad, overheating, passage mode, motor and programming faults, deadbolt handing, Bluetooth issues with the Carbine Connect app, battery tips and factory reset.
Carbine CEL2 Electronic Digital Lock Range Brochure (PDF)
10-page brochure for the standard CEL2 (non-Bluetooth) range - leverset, deadbolt and fire-rated leverset - with the retrofit plate part numbers and shared physical specs (54mm bore, 35-51mm door, 60-70mm backset, C4 keyway). Note the code and auto-lock figures on this sheet describe the standard CEL2, not the Bluetooth model.
10-page brochure for the standard CEL2 (non-Bluetooth) range - leverset, deadbolt and fire-rated leverset - with the retrofit plate part numbers and shared physical specs (54mm bore, 35-51mm door, 60-70mm backset, C4 keyway). Note the code and auto-lock figures on this sheet describe the standard CEL2, not the Bluetooth model.
Carbine CEL2 Deadbolt Retrofit Plate (CEL2-DB-RP) - Spec Sheet (PDF)
One-page dimensioned drawing of the deadbolt retrofit plate - 75 x 147mm and 1.6mm thick with a 55mm cut-out, in brushed 304 stainless steel (CEL2-DB-RP-SS) or satin black (CEL2-DB-RP-BLK).
One-page dimensioned drawing of the deadbolt retrofit plate - 75 x 147mm and 1.6mm thick with a 55mm cut-out, in brushed 304 stainless steel (CEL2-DB-RP-SS) or satin black (CEL2-DB-RP-BLK).
Carbine Warranty
Carbine is a flagship brand of Davcor Group Pty Ltd (ABN 95 003 562 598) - an Australian manufacturer, designer, and wholesale distributor of residential and commercial locking hardware. Engineered in collaboration with working locksmiths, Carbine products focus on high security, versatility, and ease of installation.
Davcor distributes Carbine through seven specialist divisions, including Lock and Key Co. - Davcor's dedicated trade distribution arm supplying locksmiths and the security industry across Australia, New Zealand, and beyond. Whether you purchased your Carbine product through Lock and Key Co., another trade channel, or directly through us, the same Davcor warranty applies.
All Carbine products are guaranteed by Davcor Group Pty Ltd to be free from defects in materials and workmanship from the date of original purchase, for the period applicable to the specific product category (refer to the Warranty Period table below). This warranty covers replacement of product only.
Warranty Summary
Warranty Periods by Product Category
Source: Davcor Warranty Against Defects - Appendix A. Warranty period runs from the date of original purchase.
How to Make a Claim
For full returns and warranty claim procedures, visit our Returns & Warranty page - this is kept up to date and is the authoritative reference for current claim steps.
- Contact Terry's Tradies Pty Ltd (the place of purchase) in writing as soon as the defect becomes apparent - and no later than 14 days after the end of the applicable warranty period.
- Include in your written claim: a description of the defect, the date of supply, your contact details, and satisfactory proof of purchase.
- Do not return the product until a return authorisation number has been issued by Davcor. If return is required, the product must be in its original, complete, and saleable packaging.
- Davcor will test and assess the product. No claim is valid unless Davcor has confirmed a defect is present.
- Once a valid claim is confirmed, Davcor will - at its discretion - repair the defect, replace the product, or supply an equivalent product. If repair or replacement cannot be completed within a reasonable time, you may request a full refund, provided the product has been returned.
Delivery inspection: If you believe a product is defective or incorrectly supplied at the time of delivery, telephone notice must be given within 72 hours of receipt, with written notice (including full particulars) within 14 days of the invoice date.
Exclusions
Australian Consumer Law
Our goods come with guarantees that cannot be excluded under the Australian Consumer Law. You are entitled to a replacement or refund for a major failure, and to compensation for any other reasonably foreseeable loss or damage. You are also entitled to have the goods repaired or replaced if they fail to be of acceptable quality and the failure does not amount to a major failure. The Carbine/Davcor express warranty operates alongside and in addition to your rights under the Australian Consumer Law.
Our goods come with guarantees that cannot be excluded under the Australian Consumer Law. You are entitled to a replacement or refund for a major failure, and to compensation for any other reasonably foreseeable loss or damage. You are also entitled to have the goods repaired or replaced if they fail to be of acceptable quality and the failure does not amount to a major failure. The Carbine/Davcor express warranty operates alongside and in addition to your rights under the Australian Consumer Law.
Confused? Overwhelmed? We get it.
Choosing the right smart lock can be genuinely tricky - door types, backsets, app platforms, compatibility with your existing hardware... there is a lot to consider. We have decades of experience fitting locks of all types, including smart locks, and we are happy to help.
Our expert recommendation service is free. Upload a few photos of your door and describe what you need, and one of our qualified locksmiths will give you a personalised recommendation.
Get Your Free Recommendation →How it works - three easy steps:
1. Upload photos
A few clear shots of your door, lock and frame - inside and out.
2. We assess
Our locksmith reviews your setup and requirements - door type, weather exposure, how you want to use it.
3. You get a recommendation
A personalised recommendation tailored to your door, budget and needs. No pressure, no upsell.
Also useful while you are deciding:
