Lockwood Integral USB Card Encoder - RFID MIFARE Access Management Programmer
The Lockwood Integral USB Card Encoder (ITGL910-ENCODER) is the desktop programming device used to issue and manage RFID credentials within the ASSA ABLOY Integral Wireless Access Control system. It plugs into a Windows computer and lets authorised administrators create, modify and cancel the access cards, fobs and wristbands used by Integral escutcheon locksets.
The encoder works with the ISO 14443A MIFARE® RFID credential platform used across the Integral system, and is how permissions are written onto each credential. Because Integral is a data-on-card system, this is the tool that turns a blank card into a working credential and updates or revokes it later.
Every Integral installation needs at least one encoder connected to the management software to issue credentials. It is a system-management device rather than a door lock - it programs the credentials that the Integral escutcheon locksets read at the door.
Usually ships in 3 business days
The encoder is the device that programs and issues Integral credentials. At least one is required per site; larger installations may run several so multiple administrators can issue cards at once. It is part of a wider commercial access-control system used in accommodation, commercial, education and healthcare facilities.
Available Finish Options
Black
(This Product)
ITGL910-ENCODER
The encoder is supplied in a black flame-retardant ABS housing. Colour does not affect functionality.
Key Features
- USB plug-and-play RFID card encoder for Integral access management
- Programs the RFID credentials read by Integral wireless access control locks
- Compatible with ISO 14443A MIFARE® cards and fobs at 13.56MHz
- Issue, modify or cancel user credentials, and invalidate lost or stolen cards
- Programs all card types except the special IC (system activation) card
- Supports user, floor, zone, global, security and management card configurations
- Reads audit-trail information from locks when cards are presented
- Simple operation through the Windows-based Integral management software
- Compact desktop unit powered directly by USB - no separate power supply
- Essential device for issuing credentials in any Integral installation
What's in the Box
- Lockwood Integral USB RFID card encoder
- USB connection cable
The Integral access management software is required to operate the encoder and is provided/licensed with the system, not as a boxed item. Blank credentials such as ITGL920-USERCARD user cards are ordered separately.
Suitable Uses
- Programming Integral access-control user cards, fobs and wristbands
- Managing staff or resident credentials
- Hotel and accommodation keycard systems
- Commercial building access management
- Education and healthcare facility access systems
- Day-to-day security administration within Integral installations
Full Specifications
Accessories & Spares
These items are part of the same Integral ecosystem. Selection depends on whether the site runs in accommodation or commercial mode and how many doors and administrators are involved.
Integral System Product Family
Linked items are stocked. ITGL-AUT1I1SS / -SS-B / -BL variants, ITGL920-ICCard, ITGL930-ENERGY and ITGL930-LIFT are shown for system context.
Frequently Asked Questions
It programs and manages the RFID cards, fobs and wristbands used within the ASSA ABLOY Integral access control system - issuing, modifying and cancelling credentials from a Windows PC.
Yes. It issues, modifies and cancels Integral user credentials, and can invalidate lost or stolen cards. It programs all card types except the special IC (system activation) card.
Integral system credentials using ISO 14443A MIFARE® technology at 13.56MHz. See Chapter 03 - Access Methods for how RFID credentials work.
No. The encoder connects via USB to a computer running the Integral management software. Integral is an offline, data-on-card system - no network to each door is required.
Yes. Audit-trail information collected from door locks can be read back when the relevant card is presented to the encoder.
At least one per site. Larger installations often run several so multiple administrators can issue credentials at the same time. Each client PC that issues cards needs its own encoder.
Additional Information
The Integral platform uses a data-on-card architecture: access permissions are written onto the RFID credential rather than held on a central server that each door must reach. That is what lets the wireless locksets run independently while still supporting large, centrally managed credential pools. The encoder is the point where those credentials are created and updated.
Each Integral installation needs at least one encoder connected to the management software to create and update user cards. Larger sites may operate multiple encoders so several administrators can issue credentials at once, and the system scales to thousands of doors and unlimited users - suiting accommodation facilities, commercial buildings and multi-site organisations.
The encoder issues the credentials read by the Integral locksets such as the escutcheon with key override (or the bundled version with the 3772 mortice lock), and by the wall-mounted reader at doors without an escutcheon. On-site lock configuration and audit collection is handled by the handheld NFC programmer.
Terry's can scope, supply, commission and install a complete Integral system across the Gold Coast - see our site survey and installation services. For "why this brand" background, see the Lockwood brand profile (Lockwood is an ASSA ABLOY brand), or start with the Smart Lock Buyer's Guide overview.
Lockwood branded products purchased new in Australia from authorised resellers are covered against defects in materials and workmanship as follows:
- Mechanical components: 25 years — covers mechanical components and workmanship under normal use and correct installation.
- Electronic & electrical components: 3 years (PADDE & electric mortice locks 5 years; batteries excluded).
- Keys: 12 months.
- Finish: varies by finish type and exposure — Everbrass 25 years; Stainless / Chrome / Anodised 10 years; PVD / VIVID 10 years; Symmetry range 5 years; decorative finishes such as bronze, antique and powdercoat 2 years (natural brass ageing excluded).
Integral Wireless Access Control - Product Brochure
The encoder appears on Page 6 (Encoder). The full system catalogue is included below for context.
Lockwood Warranty Overview
Lockwood branded products are covered by manufacturer warranties issued by ASSA ABLOY Australia Pty Ltd. Warranty periods vary depending on product type, mechanical components, electrical elements, and finish category.
This overview summarises the structure of Lockwood warranty coverage. Full terms, exclusions and claim procedures are set out in the official Lockwood Warranty document.
Warranty Periods Summary
Finish Coverage Guide
- Everbrass finishes: up to 25 years against corrosion, tarnishing and discolouration.
- Stainless steel, polished stainless steel, chrome plating and anodised finishes: typically up to 10 years.
- Decorative finishes including Antique Copper, Architectural Bronze, Oil Rubbed Bronze, Aged Brass, Polished Brass, Satin Brass and related variants: typically up to 2 years against corrosion.
- Unlacquered brass finishes will naturally age and change appearance over time. This is not considered a defect.
- Tea staining of stainless steel is not covered where cleaning and maintenance have not been followed.
What the Warranty Covers
- Defects in material and workmanship during the applicable warranty period.
- Assessment by ASSA ABLOY to determine repair, replacement with the same or closest equivalent product, or refund of purchase price.
Common Exclusions
- Normal wear and tear.
- Misuse, abuse, accidental damage or use outside published specifications.
- Improper maintenance or failure to follow care instructions.
- Unauthorised modification, repair or use of non-genuine parts.
- Exposure to corrosive environments including coastal air, salt spray, chemicals or pollution.
- Removal, refitment or associated labour charges.
- Products not originally sold in Australia through authorised channels.
Warranty Claim Process
- Retain proof of original purchase.
- Return the product through the original place of purchase where applicable.
- If claiming directly, obtain a case number before returning goods.
- Products must be securely packed and clearly identified.
- Warranty assessment determines repair, replacement or refund.
Australian Consumer Law
Lockwood warranties operate in addition to rights available under the Australian Consumer Law. Goods come with guarantees that cannot be excluded. Customers may be entitled to a replacement or refund for a major failure and compensation for reasonably foreseeable loss or damage.
Where a product fails to meet acceptable quality standards and the failure does not amount to a major failure, the customer is entitled to repair or replacement.
