Vault Rebate Kit for Tubular Latch Locks - Double Door Conversion Kit
The Vault Rebate Kit for Tubular Latch Locks (Vault_Tub_Latch_Rebate_Kit) is a stainless steel conversion kit that lets a Vault smart lock fitted with a tubular latch or deadbolt close and lock correctly on rebated double doors - door pairs where one leaf overlaps the other at the meeting stiles. It adapts the latch or bolt face plate and the strike to the stepped profile of a rebated stile, so the bolt reaches a properly seated strike instead of the overlap of the other leaf.
It suits the Vault locks that take a tubular latch at checkout - the Vault Alpha, Vault Zenith, Vault Eclipse, Vault Guardian and Vault Guardian Vision, and the Vault Prime, Vault Neo and Vault Triton on their tubular latch - and the deadbolt-format Vault Nexus and Vault Nexus Vision. A Vault lock fitted with a mortice lock body, or a Vault mortice bought on its own, takes the Vault Rebate Kit for Mortice Locks instead. It is not needed on flush double doors or single doors.
Usually ships in 3 business days.
This kit suits a Vault lock on a tubular latch or deadbolt. If your Vault lock is fitted with a mortice lock body - the Hinged/Swinging Euro, Sliding Hook, 6068 or Innovative Mortice, or the Neo and Triton 5050 mortice - you need the Vault Rebate Kit for Mortice Locks instead. Not sure which body you have? See Which Vault Rebate Kit Do I Need? below.
Key Features
- Converts a Vault tubular latch or deadbolt installation for rebated (overlapping) double doors
- Stainless steel rebate plate, strike box and strike plate, supplied with countersunk fixing screws
- Suits every Vault smart lock with a tubular latch option, and the Nexus and Nexus Vision deadbolts
- Keeps the latch or bolt face and the strike correctly aligned across the step of the rebate
- Suitable for residential and commercial door pairs, timber or metal
- Not required on flush double doors or single doors, and not for mortice lock bodies - those take the mortice rebate kit
What's Included
- Rebate plate for the latch or bolt face, with a round bolt aperture
- Rebate strike box - a folded stainless steel channel with two fixing flanges
- Strike plate with radiused corners and a bolt aperture
- 4 x countersunk fixing screws
Contents as pictured.
Suitable Uses
- Rebated (overlapping) hinged double doors in residential or commercial settings
- A Vault smart lock ordered with the 60mm tubular latch option - the Vault Alpha, Vault Zenith, Vault Eclipse, Vault Guardian and Vault Guardian Vision
- A Vault Prime, Vault Neo or Vault Triton fitted with its tubular latch rather than its mortice
- A Vault Nexus or Vault Nexus Vision deadbolt on a rebated door pair
- Timber or metal rebated door sets - see also our other rebate kits and strikes for smart locks
Which Vault Rebate Kit Do I Need?
Vault makes two rebate kits, and the right one depends on the lock body on your door - not on the smart lock model. Look at the door edge: a long rectangular face plate carrying a latch and a bolt (or a hook) is a mortice; a single round spring bolt through a small face plate is a tubular latch; a single square bolt through a round bored hole is a deadbolt. Many Vault locks can be ordered either way, so check which body you chose at checkout.
Available Finish Options
Stainless Steel
(This Product)
STK Vault_Tub_Latch_Rebate_Kit
Finish selection does not affect functionality, compliance, or performance.
Compatible Vault Locks
This rebate kit suits the following Vault locks on a rebated double door, with the lock body shown. Always confirm the latch or bolt position and strike alignment on your pair before ordering:
- Vault Alpha - 60mm tubular latch option
- Vault Zenith - 60mm tubular latch option
- Vault Eclipse - 60mm tubular latch option
- Vault Guardian - 60mm tubular latch option
- Vault Guardian Vision - 60mm tubular latch option
- Vault Prime - tubular latch (single-tongue) lock body
- Vault Neo - tubular latch option
- Vault Triton - tubular latch option
- Vault Nexus - deadbolt in a bored door preparation
- Vault Nexus Vision - deadbolt in a bored door preparation
The same locks fitted with a Vault mortice body, and the push-pull mortice locks (Fortress, Fortress Vision, Quantum, Titan and Olympus), take the Vault Rebate Kit for Mortice Locks. The full Vault line-up is in our Vault smart lock range guide.
Full Specifications
Frequently Asked Questions
Only if the doors are rebated - one leaf overlaps the other where they meet - and the Vault lock on them uses a tubular latch or deadbolt. Flush double doors and single doors do not need a rebate kit at all.
Every Vault lock that can be ordered with the 60mm tubular latch - the Alpha, Zenith, Eclipse, Guardian and Guardian Vision - plus the Prime, Neo and Triton when fitted with their tubular latch, and the Nexus and Nexus Vision deadbolts. The full list is under Compatible Vault Locks. A lock on a Vault mortice body takes the mortice rebate kit.
Look at the edge of the door. A tubular latch is a single round spring bolt through a small face plate; a tubular deadbolt is a single square bolt through a round bored hole; a mortice is a long rectangular face plate with a latch and a bolt (or a hook) behind it. The comparison table above matches each body to its kit.
Yes. The Vault Nexus and Nexus Vision use a deadbolt in a bored door preparation rather than a mortice, and this is the kit that converts that preparation for a rebated pair. Confirm the bolt position and strike alignment on your doors before ordering.
The plates pack the latch or bolt face and the strike out to the step of the rebate, so accurate positioning is what matters - a strike that is a few millimetres out is the usual reason a lock on a rebated pair will not latch. See our notes on choosing the wrong hardware and poor door preparation, or ask about professional fitting through our Advice and Installation service.
