ABUS Key Garage Wall Mount Push Button Key Storage Box – KG747LC
The ABUS Key Garage KG747LC is a wall-mounted key and card storage box secured by a resettable push button combination with up to ten digits. It is designed to provide controlled shared access to keys or access cards without issuing physical copies.
This model is intended for indoor use or protected outdoor locations and is commonly specified where higher internal capacity is required.
Key Features
- Wall-mounted ABUS Key Garage for shared access control.
- Resettable push button combination with up to ten digits.
- Hinged drop-down access door.
- Protective dust cover over the push button keypad.
- Steel body with steel back plate for permanent installation.
Specifications
- Item Code: KG747LC
- Mounting Type: Wall mount
- Lock Mechanism: Push button combination (resettable, up to 10 digits)
- Material: Steel body and back plate
- Finish: Black
- Key Capacity: Up to 25 keys (depending on key size and tags)
- Card Capacity: Up to 41 cards
- Permanent Mount: Yes
- Internal Dimensions: 62 mm (W) × 90 mm (H) × 54 mm (D)
- External Dimensions: 82 mm (W) × 120 mm (H) × 66 mm (D)
What's In The Box
- ABUS Key Garage KG747LC wall-mounted unit
- Wall fixing screws
- Installation and operating instructions
Suitable Uses
- Residential properties requiring higher-capacity shared key access.
- Holiday rentals and serviced accommodation.
- Trades, cleaners, and maintenance access management.
- Light commercial environments with frequent access changes.
ABUS Key Garage — Item Code Family
Download PDF Resources
|
ABUS Key Garage Catalogue |
Frequently Asked Questions
Is the KG747LC suitable for fully exposed outdoor installation?
No. This model is intended for indoor or protected outdoor locations only.
Can the push button code be changed after installation?
Yes. The push button combination is fully resettable.
Does this model support vehicle mounting?
No. The KG747LC is a wall-mounted unit and is not compatible with automotive adaptors.
Additional Information
- This model is often selected where higher key or card capacity is required in a fixed location.
- Key and card capacity figures assume standard flat keys and cards without bulky attachments.
- For exposed outdoor locations, alternative weather-rated access solutions should be considered.
