BDS Mortice Magnetic Gate Latch Body to suit BORG Mech-Digital Keypad Series 2000 Or 4000 (Trencab)
The TML25DGT is a face fixed mortice magnetic latch body for keypad gates, made by Trencab and listed in our BDS range. It is made to suit Borg 2000 series and 4000 series mechanical digital keypads, such as the BL2000KSCNEW knob keypad and the BL4401KMGPRO lever keypad, and it pairs a 25mm backset latch body with a magnetic strike plate. Either part can go on the gate or the post, on metal or timber gates, doors and access panels in homes and light commercial sites.
Mortice magnetic latches tend to be chosen for narrow gate stiles, where a standard 60mm latch will not fit. Our Mechanical Digital Locks chapter on gates and our guide to how a mortice magnetic latch works explain the trade-offs before you commit. If your gate is keyed rather than keypad operated, the TML25E is the euro cylinder version of this latch.
Magnetic Latches Need a Steady Gate
This latch will not stop a swinging gate, so a gate stop has to be fitted, but a stop is not a fix for a gate that moves. A small amount of gate or post movement is enough to put the latch pin out of line with the strike, and about half of our own magnetic latch installations needed a return visit to realign. On most narrow keypad gates we now fit Borg's 28mm latch instead, sold for the 2000 series as the BLS272000RH and BLS272000LH.
This latch will not stop a swinging gate, so a gate stop has to be fitted, but a stop is not a fix for a gate that moves. A small amount of gate or post movement is enough to put the latch pin out of line with the strike, and about half of our own magnetic latch installations needed a return visit to realign. On most narrow keypad gates we now fit Borg's 28mm latch instead, sold for the 2000 series as the BLS272000RH and BLS272000LH.
Key Features
- Made to suit Borg 2000 series and 4000 series mechanical digital keypads from Borg's battery-free range.
- Short backset latch body that sits close to the edge, which is why this style of latch is used on narrow stiles.
- Magnetic latching: when the closed gate lines up, the latch pin throws into the magnetic strike plate (how a mortice magnetic latch works).
- The latch body and the strike can each go on the gate or the post, and both are designed to face fix, with flush fixing possible if you make your own measurement adjustments (Trencab's product information).
- Strike plate packers in the box take up larger gaps between the gate and the post.
- Paper installation template in the box, with every mark taken from one reference line on the gate and post (installation steps).
- Australian owned, designed and manufactured by Trencab, and patented.
What's in the Box
TML25DGT Mortice Magnetic Gate Latch Body
- TML25-DGT latch body x1
- Magnetic strike plate x1
- 2.5mm strike plate packers x2
- Coil spring x1
- Installation template x1
Made to suit Borg 2000 series keypads such as the BL2000KSCNEW and Borg 4000 series keypads such as the BL4401KMGPRO. The two packers are for gates that close with a gap larger than 8mm (product information page), and the template follows the marking out steps on page 1 of Trencab's installation sheet.
Suitable Uses
- Metal or timber gates fitted with a Borg 2000 or 4000 series keypad from our Digital Mechanical Locks range (why these locks suit gates).
- External or internal gates, doors and access panels, in homes and light commercial sites (door and gate types compared).
- Keypad gates where the latch has to go into a narrow stile or post, once you have measured the stile and checked the fit with us.
- Solidly hung gates with a gate stop fitted, because gate movement is what upsets a magnetic latch.
Available Finish Options
Black
(This Product)
STK TML25DGT
Finish selection does not affect functionality, compliance, or performance.
TML25 Mortice Magnetic Gate Latch - Item Code Family
Borg Keypads It Is Made to Suit
If your keypad is not listed here, or you are not sure which series you have, ask us to confirm your model before you order.
Full Specifications
Dimensions
Technical drawing of the TML25DGT latch body. The backset, case depth and strike figures are in the Full Specifications table, and the gap, packer and flush fixing details are on Trencab's product information page.
Installation Notes
Marking Out and Drilling the Latch Body
- Decide whether the latch body goes in the gate or the post, then run painter's tape along the faces and edges of both at the height you are working. The marks are easier to see and the finish is less likely to scratch.
- Start with a level reference line 40mm below the centre of the keypad lever, marked on the faces and edges of both the gate and the post. Every other measurement is taken up from it.
- The latch body gets a vertical centreline down the edge, and the keypad hardware gets vertical centrelines on both faces, 25mm in from the front edge.
- Sit the bottom of the template on the reference line, line it up with your centrelines, mark the holes and check your measurements before drilling. Trencab suggests an adjustable set square and a centre punch for accurate marking.
- Pilot holes keep the step drill or holesaw from walking off your marks, and a file takes off the sharp points so the latch body slides in.
- If your keypad hardware has a coil spring around its spindle, take it off and fit the coil spring from the box, and make sure the codepad locating pin is fitted so the codepad lines up with the latch body.
- Do not use power tools to attach the latch body or the strike. The full steps are on page 1 of Trencab's installation sheet.
Fitting the Magnetic Strike
- Fit the strike only once the latch body is fully installed, and make sure the gate is hanging true first, because misalignment left unaddressed is a common installation mistake.
- Mark the latch pin centreline 61mm up from the reference line, or take it from the template.
- Close the gate, measure exactly where the centre of the latch pin sits, then mark and centre punch that point. A pin that sits even slightly out of line will not throw into the strike.
- Drill a pilot hole, then open it up to 25mm.
- Clean away every metal shaving before you take the strike out of its plastic bag, because shavings collect inside the magnetic cup.
- Where the gap between the gate and the post is larger than 8mm, use the 2.5mm strike plate packers.
- If you would rather not drill your gate and post, talk to us about installation.
Frequently Asked Questions
Will it suit my Borg keypad?
It is made to suit Borg 2000 series and 4000 series mechanical digital keypads. On our store that covers the BL2000KSCNEW knob keypad, the BL2000SC and BL2000PB locks, the BL4401KMGPRO lever keypad and the BL4401MGPRO gate lock. If you are not sure which series you have, we can identify it for you.
It is made to suit Borg 2000 series and 4000 series mechanical digital keypads. On our store that covers the BL2000KSCNEW knob keypad, the BL2000SC and BL2000PB locks, the BL4401KMGPRO lever keypad and the BL4401MGPRO gate lock. If you are not sure which series you have, we can identify it for you.
How much gap do I need between the gate and the post?
Face fixing needs an 8mm gap. Two 2.5mm packers come in the box for larger gaps, and the latch body or strike can be flush fixed if you make your own measurement adjustments (product information page). Trencab does not list a minimum stile or post size, so measure the stile and check with us before ordering.
Face fixing needs an 8mm gap. Two 2.5mm packers come in the box for larger gaps, and the latch body or strike can be flush fixed if you make your own measurement adjustments (product information page). Trencab does not list a minimum stile or post size, so measure the stile and check with us before ordering.
Does the latch stop the gate?
No. It will not stop a swinging gate, so a suitable gate stop has to be fitted. The stop is needed for the latch to work, but it cannot stop a gate or post moving over time, and even slight movement can leave the pin out of line with the strike.
No. It will not stop a swinging gate, so a suitable gate stop has to be fitted. The stop is needed for the latch to work, but it cannot stop a gate or post moving over time, and even slight movement can leave the pin out of line with the strike.
Is this a magnetic pool gate latch?
No. This is a mortice magnetic latch that fits into the edge of the gate or post and works with a Borg keypad. Magnetic pool safety latches are a very different product that shares the name. For how we set up keypad locks on barrier gates, see pool safety barrier gates.
No. This is a mortice magnetic latch that fits into the edge of the gate or post and works with a Borg keypad. Magnetic pool safety latches are a very different product that shares the name. For how we set up keypad locks on barrier gates, see pool safety barrier gates.
Can I fit it myself?
If you are handy with a step drill or holesaw and can mark out accurately, yes. The template in the box and Trencab's installation steps take you through the latch body, the keypad holes and the strike, all measured from one reference line. The strike has to sit exactly where the latch pin lands, so if drilling your gate and post is not a job you want, talk to us about installation or read when to do it yourself and when not to.
If you are handy with a step drill or holesaw and can mark out accurately, yes. The template in the box and Trencab's installation steps take you through the latch body, the keypad holes and the strike, all measured from one reference line. The strike has to sit exactly where the latch pin lands, so if drilling your gate and post is not a job you want, talk to us about installation or read when to do it yourself and when not to.
Additional Information
- Alignment and movement: A magnetic latch only works while the pin and the strike stay in line. Sag, hinges, ground movement and wind all shift a gate over time, so look for the signs that call for caution before choosing this style of latch, and see common gate latch problems.
- Our field experience: After the return visits our magnetic latch jobs needed, we now strongly prefer Borg's 28mm latch and rarely fit a TML25. There are still a few situations where one makes sense, and other gate factors can change the answer for your gate.
- Care: Trencab says not to lubricate the latch body, and there are no serviceable parts inside. Removing the latch case screws or using other fixings voids the warranty. If the latch stops catching, check whether the gate has moved rather than reaching for a lubricant.
- Other options for a narrow gate: Our narrow gate post guide covers the alternatives: a short backset mortice latch as fitted to the BL2002SC and BL2202SC, a forend fixing gate lock such as the BL3400GATE or back-to-back BL3430GATE, or a prefabricated lock box such as the LB21 for Borg 2000 series keypads, which is welded on and suits steel gates only. Check what to measure before you order.
Download PDF Resources
Trencab TML25-DGT Face Fixed Mortice Latch - Box Information and Installation Sheet (PDF)
Two-page Trencab box information and installation sheet for this latch: marking out from the reference line, drilling, fitting the magnetic strike, the strike plate packers, flush fixing and the care conditions.
Two-page Trencab box information and installation sheet for this latch: marking out from the reference line, drilling, fitting the magnetic strike, the strike plate packers, flush fixing and the care conditions.
TML25DGT - FAQ, Fitting and Owner's Guide
Straight answers on choosing, fitting and living with the TML25DGT latch body. For the wider picture, see our Smart Lock FAQ, the full Buyer's Guide and the Mechanical Digital Locks chapter.
Fit and Compatibility
Which Borg keypads is the TML25DGT made to suit?
Borg 2000 series and 4000 series mechanical digital keypads. On our store, the 2000 series options are the BL2000KSCNEW knob keypad and the BL2000SC and BL2000PB knob and medium lever locks. The 4000 series options are the BL4401KMGPRO lever keypad and the BL4401MGPRO gate lock. For any other model, ask us to confirm the fit before ordering.
Borg 2000 series and 4000 series mechanical digital keypads. On our store, the 2000 series options are the BL2000KSCNEW knob keypad and the BL2000SC and BL2000PB knob and medium lever locks. The 4000 series options are the BL4401KMGPRO lever keypad and the BL4401MGPRO gate lock. For any other model, ask us to confirm the fit before ordering.
Is there a version for a keyed gate?
Yes. The TML25E is the euro cylinder version of this mortice magnetic gate latch body, for gates opened with a key rather than a Borg keypad.
Yes. The TML25E is the euro cylinder version of this mortice magnetic gate latch body, for gates opened with a key rather than a Borg keypad.
Can the latch body go in the post instead of the gate?
Yes. The latch body and the magnetic strike can each go on the gate or the post, so choose whichever suits your gate before you start marking out (Trencab's product information). The strike always goes in last, once the latch body is finished.
Yes. The latch body and the magnetic strike can each go on the gate or the post, so choose whichever suits your gate before you start marking out (Trencab's product information). The strike always goes in last, once the latch body is finished.
What gap between the gate and the post does face fixing need?
An 8mm gap. The magnetic strike plate is 21mm deep when surface mounted, and the two 2.5mm strike plate packers in the box are there for larger gaps. If you flush fix the latch body, the strike or both, you will need to work out your own measurement adjustments. Before ordering, check what to measure on a narrow gate.
An 8mm gap. The magnetic strike plate is 21mm deep when surface mounted, and the two 2.5mm strike plate packers in the box are there for larger gaps. If you flush fix the latch body, the strike or both, you will need to work out your own measurement adjustments. Before ordering, check what to measure on a narrow gate.
Can it go on an outdoor gate?
Yes. It is designed for external or internal metal or timber gates, doors and access panels in domestic or light commercial use, and the body is glass-filled nylon. Trencab does not list a salt spray or corrosion rating for it. For an exposed or coastal gate, read where Marine Grade Pro keypads are useful when you choose the keypad.
Yes. It is designed for external or internal metal or timber gates, doors and access panels in domestic or light commercial use, and the body is glass-filled nylon. Trencab does not list a salt spray or corrosion rating for it. For an exposed or coastal gate, read where Marine Grade Pro keypads are useful when you choose the keypad.
Installing the Latch and Strike
Where do I start marking out?
At the keypad lever. Measure 40mm down from its centre and draw a level reference line across the faces and edges of the gate and the post, because every other mark is measured up from there. Add a centreline down the edge for the latch body and centrelines on both faces 25mm in from the front edge for the keypad hardware, then rest the bottom of the template on the reference line to mark the holes. The full sequence is on page 1 of Trencab's installation sheet.
At the keypad lever. Measure 40mm down from its centre and draw a level reference line across the faces and edges of the gate and the post, because every other mark is measured up from there. Add a centreline down the edge for the latch body and centrelines on both faces 25mm in from the front edge for the keypad hardware, then rest the bottom of the template on the reference line to mark the holes. The full sequence is on page 1 of Trencab's installation sheet.
What tools will I need?
Trencab suggests an adjustable set square and an automatic centre punch or centre punch for accurate marking, with painter's tape on the faces and edges to help the marking and reduce scratches. You will also need a drill for the pilot holes, a step drill or holesaw for the larger holes, a 25mm drill for the strike hole and a file for the sharp points. Drilling is fine, but Trencab says not to use power tools to attach the latch body or the strike. If that is more gear than you have, talk to us about installation.
Trencab suggests an adjustable set square and an automatic centre punch or centre punch for accurate marking, with painter's tape on the faces and edges to help the marking and reduce scratches. You will also need a drill for the pilot holes, a step drill or holesaw for the larger holes, a 25mm drill for the strike hole and a file for the sharp points. Drilling is fine, but Trencab says not to use power tools to attach the latch body or the strike. If that is more gear than you have, talk to us about installation.
What is the coil spring in the box for?
Some keypad hardware has a coil spring fitted around its spindle. If yours does, remove it and fit the coil spring supplied with the latch. At the same stage, make sure the codepad locating pin is fitted so the codepad lines up with the latch body (installation steps).
Some keypad hardware has a coil spring fitted around its spindle. If yours does, remove it and fit the coil spring supplied with the latch. At the same stage, make sure the codepad locating pin is fitted so the codepad lines up with the latch body (installation steps).
How do I position the magnetic strike?
Fit it last, after the latch body installation is complete. Come up 61mm from the reference line for the latch pin centreline, or use the template, then close the gate and measure exactly where the centre of the pin sits. Centre punch that point, drill a pilot hole and open it up to 25mm. The strike has to sit where the pin lands, which is why sorting out misalignment comes before drilling.
Fit it last, after the latch body installation is complete. Come up 61mm from the reference line for the latch pin centreline, or use the template, then close the gate and measure exactly where the centre of the pin sits. Centre punch that point, drill a pilot hole and open it up to 25mm. The strike has to sit where the pin lands, which is why sorting out misalignment comes before drilling.
Why does the strike stay in its plastic bag until the end?
Drilling leaves metal shavings, and they collect inside the magnetic strike cup. Clean every shaving off the gate and post before you unbag the strike (Trencab's product information).
Drilling leaves metal shavings, and they collect inside the magnetic strike cup. Clean every shaving off the gate and post before you unbag the strike (Trencab's product information).
Living With a Magnetic Latch
Do I need a gate stop?
Yes. The latch will not stop a swinging gate, so a suitable stopper has to be fitted. A stop is required, but it is not a fix: it cannot prevent the gate or post from moving over time.
Yes. The latch will not stop a swinging gate, so a suitable stopper has to be fitted. A stop is required, but it is not a fix: it cannot prevent the gate or post from moving over time.
Why would a magnetic latch stop catching?
Most often because the gate has moved. Sag, hinges, ground movement and wind shift a gate over time, and slight movement is enough for the pin to miss the strike. Realigning brings it back, and our guide to common gate latch problems has more.
Most often because the gate has moved. Sag, hinges, ground movement and wind shift a gate over time, and slight movement is enough for the pin to miss the strike. Realigning brings it back, and our guide to common gate latch problems has more.
Can I oil or service the latch?
No. Trencab says not to lubricate the latch body and there are no serviceable parts inside, so leave the latch case screws where they are. If it stops working properly, look at the alignment first.
No. Trencab says not to lubricate the latch body and there are no serviceable parts inside, so leave the latch case screws where they are. If it stops working properly, look at the alignment first.
How often do magnetic latches need realigning?
It depends on the gate and how much it moves, but about half of the magnetic latches we installed needed a return visit to realign. Whichever keypad lock you choose, gates need extra care.
It depends on the gate and how much it moves, but about half of the magnetic latches we installed needed a return visit to realign. Whichever keypad lock you choose, gates need extra care.
Is this the same as a magnetic pool safety latch?
No. They share a name, but a mortice magnetic latch like this one and a magnetic pool safety latch such as a MagnaLatch are two very different products. See pool safety barrier gates for how keypad locks and self-latching pool latches work together on barrier gates, and what self-latching means.
No. They share a name, but a mortice magnetic latch like this one and a magnetic pool safety latch such as a MagnaLatch are two very different products. See pool safety barrier gates for how keypad locks and self-latching pool latches work together on barrier gates, and what self-latching means.
Choosing a Latch for a Narrow Gate
Why do you prefer Borg's 28mm latch?
Because a magnetic latch relies on the pin and strike staying lined up, and gates move. Borg's 28mm latch is our preferred short backset option. It is sold on its own for the 2000 series as the BLS272000RH and BLS272000LH, and it comes fitted to locks such as the BL2002SC, BL2202SC and BL2702SCECP. The latch-only version is sold in left and right hand, so check your gate's handing before you order.
Because a magnetic latch relies on the pin and strike staying lined up, and gates move. Borg's 28mm latch is our preferred short backset option. It is sold on its own for the 2000 series as the BLS272000RH and BLS272000LH, and it comes fitted to locks such as the BL2002SC, BL2202SC and BL2702SCECP. The latch-only version is sold in left and right hand, so check your gate's handing before you order.
When does a magnetic latch still make sense?
There are still some situations where we would fit one, and some warning signs that call for caution. Other gate factors come into it too, so if you are weighing it up, ask us for a recommendation.
There are still some situations where we would fit one, and some warning signs that call for caution. Other gate factors come into it too, so if you are weighing it up, ask us for a recommendation.
What other options are there for a narrow stile?
Our guide to narrow stile gates covers four: a short backset mortice latch, a forend fixing gate lock such as the BL3400GATE single keypad or BL3430GATE back-to-back keypads, a prefabricated lock box such as the LB21 for Borg 2000 series keypads (welded on, so steel gates only), or a workshop solution.
Our guide to narrow stile gates covers four: a short backset mortice latch, a forend fixing gate lock such as the BL3400GATE single keypad or BL3430GATE back-to-back keypads, a prefabricated lock box such as the LB21 for Borg 2000 series keypads (welded on, so steel gates only), or a workshop solution.
Related Products, Guides and Chapters
TML25 family: TML25E euro cylinder version
Borg 2000 series: BL2000KSCNEW · BL2000SC · BL2000PB
Borg 4000 series: BL4401KMGPRO · BL4401MGPRO
Borg 28mm latch and locks: BLS272000RH · BLS272000LH · BL2002SC · BL2202SC · BL2702SCECP
Other narrow gate options: BL3400GATE · BL3430GATE · LB21 lock box (steel gates only)
Brands and range: BDS · Borg · Borg brand profile · Digital Mechanical Locks
Blogs: Why Magnetic Gate Latches Can Be Problematic · Gate Post Too Narrow for a 60mm Latch? · Latch vs Bolt Mechanical Digital Locks · What Is a Mechanical Digital Lock? · Lockwood vs Borg vs Carbine: gates · What Marine Grade Pro Means · Why our mechanical digital range beats hardware store imitations (gates)
Buyer's Guide chapters: Chapter 02: Measuring Your Door (backset) · Chapter 04: Door Type Compatibility (matrix) · Chapter 12: Installation and Troubleshooting (when to call a locksmith) · Chapter 13: Smart Lock FAQ · Chapter 16: Mechanical Digital Locks (gates) · All chapters
Help and downloads: Qualified Locksmith Recommendation · Advice and Installation · TML25-DGT installation sheet (PDF)
What's in the Box - TML25DGT
- TML25-DGT latch body x1
- Magnetic strike plate x1
- 2.5mm strike plate packers x2
- Coil spring x1
- Installation template x1
Made to suit Borg 2000 series keypads and locks such as the BL2000KSCNEW, BL2000SC and BL2000PB, and Borg 4000 series keypads and gate locks such as the BL4401KMGPRO and BL4401MGPRO. The coil spring replaces any spring fitted around your keypad hardware's spindle, the packers are for gaps larger than 8mm, and the paper template is your marking guide for Trencab's installation steps.
BDS TML25DGT - Dimensions
Technical drawing of the TML25DGT latch body. The backset, case depth and strike depth figures are in the Full Specifications on this page. The marking out positions for the latch body, keypad hardware and strike are on page 1 of Trencab's installation sheet, and the gap, packer and flush fixing details are on page 2.
