Borg Mechanical Digital BL5701 - Lever with Built-In Key Override - Easicode Pro
At A Glance
At A Glance
DISPATCHSame Day Before 11am
PIN Code
Key Override
No App
No BiometricThe Borg BL5701 ECP is a medium to heavy duty fully mechanical digital lever lock with a key override cylinder built directly into the keypad lever handle itself. This is an important distinction from other key-override locks: rather than mounting the cylinder below the keypad on the face plate, Borg integrates it inside the lever body, keeping the external face clean and placing the key exit point in a natural operating position. Inserting and rotating the key directly engages the lever clutch and 8mm spindle drive, pulling the door open without entering the code. There is no electronic component anywhere in the lock - no battery, no wiring, no firmware.
Easicode Pro (ECP) allows the PIN to be changed at the door using a supplied code-change key and the phi-button method - no lock removal, no disassembly. The inside handle is a flat bar lever that is always free to turn for immediate egress. Two variants are on this listing: BL5701SCECP in satin chrome for internal and sheltered external use, and BL5701MGPROECP in black Marine Grade Pro for coastal, marine, and harsh external environments including ISPS-compliant applications. These are not merely different colours - the MG Pro variant carries 316 stainless steel internal components and a fundamentally different surface treatment rated to 1,000 hours of continuous salt spray resistance.
The BL5701 sits in the Digital Mechanical Locks category alongside its closest family members: the BL5001 (same platform, no key override), the BL5771MGPROECP (back-to-back version with key override on both sides), and the BL7701 (heavier-duty body with SFIC in-lever key override for high-traffic applications).
Estimated Warehouse Dispatch
Usually same day if ordered before 11am AEST (excluding weekends and Queensland public holidays)
Usually same day if ordered before 11am AEST (excluding weekends and Queensland public holidays)
Key Override Built Into the Lever Handle - Not Below the Keypad
The key override cylinder on the BL5701 is integrated directly inside the keypad lever handle body. To operate by key: insert the key into the cylinder in the handle and rotate it away from the door edge (clockwise for a right-hand door; anti-clockwise for a left-hand door). The key rotation directly engages the lever clutch and 8mm spindle drive, allowing the door to be pulled open without entering the code. This eliminates the need for a separate external cylinder and provides clean, direct key override operation. Key cylinder is pre-fitted - keys are supplied. Read our guide to how mechanical key override works.
The key override cylinder on the BL5701 is integrated directly inside the keypad lever handle body. To operate by key: insert the key into the cylinder in the handle and rotate it away from the door edge (clockwise for a right-hand door; anti-clockwise for a left-hand door). The key rotation directly engages the lever clutch and 8mm spindle drive, allowing the door to be pulled open without entering the code. This eliminates the need for a separate external cylinder and provides clean, direct key override operation. Key cylinder is pre-fitted - keys are supplied. Read our guide to how mechanical key override works.
Flat Bar Inside Lever - Always Free to Turn
The BL5701 inside handle is a flat bar lever, unlike the BL5001 which uses a round bar inside handle. The inside lever is always free to turn for immediate egress without entering the code - suitable for fire egress paths and doors required to be free-exiting from inside. The flat bar profile is a lower-profile ergonomic design suited to the applications this lock targets.
The BL5701 inside handle is a flat bar lever, unlike the BL5001 which uses a round bar inside handle. The inside lever is always free to turn for immediate egress without entering the code - suitable for fire egress paths and doors required to be free-exiting from inside. The flat bar profile is a lower-profile ergonomic design suited to the applications this lock targets.
BL5701MGPROECP (Black) - Marine Grade Pro, Not Just a Colour
The black variant uses MG Pro black marine external grade coating with 316 stainless steel internal components and a stainless steel coding chamber. It is tested to 1,000 hours of continuous salt spray resistance and is ISPS compliant for marine and port facility applications. This is a fundamentally different specification to the BL5701SCECP. Choose BL5701MGPROECP for coastal, beachside, marine, and harsh external environments. See our MG Pro & ECP Explained guide for the full comparison.
The black variant uses MG Pro black marine external grade coating with 316 stainless steel internal components and a stainless steel coding chamber. It is tested to 1,000 hours of continuous salt spray resistance and is ISPS compliant for marine and port facility applications. This is a fundamentally different specification to the BL5701SCECP. Choose BL5701MGPROECP for coastal, beachside, marine, and harsh external environments. See our MG Pro & ECP Explained guide for the full comparison.
Corrosion Resistance Warranted - 12 Months (BL5701MGPROECP)
Borg warrants corrosion resistance for 12 months from date of sale under specified maintenance conditions. Monthly silicon lubrication and annual internal servicing are required to maintain the warranty. See the Borg Servicing Guide for full maintenance instructions.
Borg warrants corrosion resistance for 12 months from date of sale under specified maintenance conditions. Monthly silicon lubrication and annual internal servicing are required to maintain the warranty. See the Borg Servicing Guide for full maintenance instructions.
BL5701SCECP - Not Suitable for Coastal or Saline Environments
The satin chrome finish is designed for internal and sheltered external use in normal weather conditions. For coastal, beachside, or marine environments, specify the BL5701MGPROECP (black Marine Grade Pro) on this listing. See when you need MG Pro for guidance.
The satin chrome finish is designed for internal and sheltered external use in normal weather conditions. For coastal, beachside, or marine environments, specify the BL5701MGPROECP (black Marine Grade Pro) on this listing. See when you need MG Pro for guidance.
Easicode Pro - On-Door Code Change
The PIN code can be changed while the lock is installed on the door using the included code change key. Insert the key over the phi button at the top of the keypad, rotate 90 degrees clockwise and hold, press C to clear, enter the new code digits, confirm, then release and remove the key. No lock removal required. The on-door code change function can be permanently deactivated using the included plug if security policy requires it. See our guide to changing the code on an ECP lock.
The PIN code can be changed while the lock is installed on the door using the included code change key. Insert the key over the phi button at the top of the keypad, rotate 90 degrees clockwise and hold, press C to clear, enter the new code digits, confirm, then release and remove the key. No lock removal required. The on-door code change function can be permanently deactivated using the included plug if security policy requires it. See our guide to changing the code on an ECP lock.
Free Passage Function (F Button)
After entering the correct code and rotating the lever, press F to engage free passage mode. The lever becomes free-turning without code entry on each use - useful during business hours or move-in days. To exit free passage: rotate the lever and press C until an audible click is heard. Free passage can be permanently deactivated using the included plug. See our guide to passage and holdback modes.
After entering the correct code and rotating the lever, press F to engage free passage mode. The lever becomes free-turning without code entry on each use - useful during business hours or move-in days. To exit free passage: rotate the lever and press C until an audible click is heard. Free passage can be permanently deactivated using the included plug. See our guide to passage and holdback modes.
Fully Mechanical - No Batteries Required, Ever
The BL5701 is entirely mechanical. There is no power source, no wiring, no battery compartment, and no battery maintenance at any point in the lock's service life. This is a genuine operational advantage on high-use external doors where battery replacement is an ongoing cost and maintenance task on electronic alternatives. See why mechanical digital locks are chosen for critical access points.
The BL5701 is entirely mechanical. There is no power source, no wiring, no battery compartment, and no battery maintenance at any point in the lock's service life. This is a genuine operational advantage on high-use external doors where battery replacement is an ongoing cost and maintenance task on electronic alternatives. See why mechanical digital locks are chosen for critical access points.
Designed for medium to heavy usage areas
Stairwells, plant rooms, roof access, staff entries, and access-controlled residential or commercial doors where both code and key access are required. See our commercial mechanical digital lock guide.
Stairwells, plant rooms, roof access, staff entries, and access-controlled residential or commercial doors where both code and key access are required. See our commercial mechanical digital lock guide.
Not suitable for very high traffic commercial use without a servicing schedule
For genuinely heavy duty high-traffic applications, consider the Borg BL7701 (heavy duty body, SFIC key override), the Lockwood DX Mortice range, or the Carbine CDL7200. Read more at High Traffic Commercial Mechanical Digital Locks.
For genuinely heavy duty high-traffic applications, consider the Borg BL7701 (heavy duty body, SFIC key override), the Lockwood DX Mortice range, or the Carbine CDL7200. Read more at High Traffic Commercial Mechanical Digital Locks.
Single PIN Code Only
The BL5701, like all Borg Easicode Pro mechanical digital locks, stores a single active PIN code at any one time. This is a characteristic of the mechanical coding chamber - there is no memory and no user database. If audit trails or multiple user codes are required, this product is not the correct choice. The limitations of mechanical digital locks are covered in our buyer's guide.
The BL5701, like all Borg Easicode Pro mechanical digital locks, stores a single active PIN code at any one time. This is a characteristic of the mechanical coding chamber - there is no memory and no user database. If audit trails or multiple user codes are required, this product is not the correct choice. The limitations of mechanical digital locks are covered in our buyer's guide.
Key Features
- Key override cylinder built into the keypad lever handle body - not an external cylinder mounted on the face plate below the keypad.
- Key rotation directly engages the lever clutch and 8mm spindle drive - bypasses the code entirely without any secondary mechanism.
- Key override cylinder pre-fitted at the factory - keys supplied with the lock (no additional sourcing required).
- Flat bar inside lever always free to turn - immediate inside egress without entering the code, suitable for fire egress paths.
- Easicode Pro (ECP) on-door code change using the phi-button method - no lock removal required at any point.
- Optional free passage function (F button) - permanently deactivatable with supplied plug.
- Stainless steel coding chamber - mechanical durability and corrosion resistance at the heart of the lock.
- Medium to heavy duty BL5000 series lock body with fully clutched round bar keypad lever.
- 8mm square drive spindle - compatible with most leading tubular latch brands and the standard Australian lock preparation.
- Over 1,000 non-sequential code combinations.
- 60mm backset heavy duty tubular latch included; 70mm backset latch available separately as BLL500070.
- Suitable for timber, composite, and steel doors, installed internally and externally.
- Door thickness 35mm to 54mm (standard fixings supplied).
- Fully mechanical - no batteries, no wiring, no electronics anywhere in the lock.
- Reversible on site for left or right hand doors.
- BL5701MGPROECP - Black MG Pro 2 marine external grade coating; 316 stainless steel internal components and coding chamber; 1,000hr salt spray tested; ISPS compliant; corrosion resistance warranted 12 months.
- BL5701SCECP - Satin chrome (PVD); internal and sheltered external use only; not rated for coastal or saline environments.
Access Methods
What's in the Box
- Borg BL5701 ECP outside keypad and lever assembly with built-in key override cylinder (selected finish)
- Key override keys - pre-fitted cylinder, keys included (typically 2 keys; confirm current supply at order)
- Flat bar inside lever handle assembly (selected finish)
- 60mm heavy duty anti-thrust tubular latch (stainless steel)
- Strike plate and box keep
- Spindles - 80mm and 90mm supplied (use the longest that fits)
- M4 fixing screws - 40mm, 50mm, and 60mm options
- 4 x 16mm screws
- Easicode Pro code change key (phi key)
- Code change deactivation plug (for permanent on-door code change disabling)
- Free passage deactivation plug (for permanent free passage disabling)
- Hex wrench (Allen key)
- Handle screw rubber grommet
- Installation instructions
60mm anti-thrust stainless steel tubular latch - included with both variants
A 70mm backset latch (BLL500070) is available separately if required. No batteries, wiring, or electronic components are required or supplied.
Suitable Uses
- Medium to heavy usage doors requiring both keypad code access and a conventional key override for supervisor, emergency, or master-key access - stairwells, plant rooms, roof access hatches, electrical substations, storage areas
- Applications where key override must be low-profile - the in-handle cylinder keeps the face plate clean, with no visible external cylinder below the keypad
- Coastal, beachside, marine, and port facility applications - specify BL5701MGPROECP (black Marine Grade Pro). See External Gate - Exposed to Rain and our guide to where MG Pro is needed
- Internal and sheltered external commercial, strata, and institutional doors in standard weather conditions - specify BL5701SCECP (satin chrome). Suitable for Regular Front Door and Internal Office and Commercial Doors
- Timber, composite, and steel doors 35-54mm thick where both code and key access are required
- ISPS-compliant applications on marine facilities where electronic access is not practical - specify BL5701MGPROECP
- Hospitals, aged care, and secured wings where a key override is required for staff emergency access without app dependency
- Applications where battery-free operation is a genuine operational requirement - no maintenance, no lockout from flat batteries
Available Finish Options
Satin Chrome
(This Product)
BL5701SCECP
Black (MG Pro)
(This Product)
BL5701MGPROECP
Both finishes are on this listing. Finish selection does not affect function, combination count, or ECP code-change method. Marine Grade Pro (black) carries a fundamentally different internal construction and corrosion specification - it is not a colour variant of Satin Chrome.
BL5700 Series and Key Override Family
Accessories and Spare Parts
Contact Terry's Locksmiths for key override cylinder re-keying, master key system integration, or if you need an MG Pro equivalent spare keypad - the BL5701KSCECP is available in satin chrome only; a marine grade keypad-only unit may need to be sourced via trade enquiry.
Full Specifications
Dimensions
Dimensions from supplied engineering drawings. Verify against current Borg documentation before specifying for constrained installations.
BL5700 ECP series - outside keypad lever with key override and inside flat bar lever (legacy dimensional line drawing)
Frequently Asked Questions
How does the key override work on the BL5701 - where is the keyhole?
The key cylinder is inside the keypad lever handle body itself, not on the face plate below the keypad. To open by key: insert the key into the cylinder in the lever handle and rotate it away from the door edge - clockwise for a right-hand door; anti-clockwise for a left-hand door. The rotation engages the lever clutch and 8mm spindle, pulling the door open without entering the code. Keys are supplied with the lock and the cylinder is pre-fitted. For more detail see our guide to where the keyhole is on key-override locks.
The key cylinder is inside the keypad lever handle body itself, not on the face plate below the keypad. To open by key: insert the key into the cylinder in the lever handle and rotate it away from the door edge - clockwise for a right-hand door; anti-clockwise for a left-hand door. The rotation engages the lever clutch and 8mm spindle, pulling the door open without entering the code. Keys are supplied with the lock and the cylinder is pre-fitted. For more detail see our guide to where the keyhole is on key-override locks.
What is the difference between the BL5701 and the BL5001?
The BL5001 uses a round bar inside handle that is always free to turn and has no key override. Code change on the BL5001 requires a bench tumbler procedure (lock removed). The BL5701 adds a key override cylinder inside the lever handle, replaces the inside round bar with a flat bar lever, and uses Easicode Pro on-door code change. If you do not need a key override, the BL5001 is a simpler and typically more economical choice. The BL5001 is also fire rated (AS1905.1 up to 4hr doorset dependent) while the BL5701 is not - if fire rating is required without key override, choose the BL5001. See when key override is needed.
The BL5001 uses a round bar inside handle that is always free to turn and has no key override. Code change on the BL5001 requires a bench tumbler procedure (lock removed). The BL5701 adds a key override cylinder inside the lever handle, replaces the inside round bar with a flat bar lever, and uses Easicode Pro on-door code change. If you do not need a key override, the BL5001 is a simpler and typically more economical choice. The BL5001 is also fire rated (AS1905.1 up to 4hr doorset dependent) while the BL5701 is not - if fire rating is required without key override, choose the BL5001. See when key override is needed.
What is the difference between the BL5701 and the BL7701?
The BL5701 uses the medium to heavy duty BL5000 series lock body. The BL7701 uses the heavier duty BL7000 series body with an SFIC (Small Format Interchangeable Core) cylinder format compatible with the Unican 1000/5000 and master key systems - making it the right choice for high-traffic commercial buildings with existing master key programs. For most standard commercial and external applications requiring code-plus-key access, the BL5701 is appropriate. If the door sees genuinely high traffic or must accept an existing keyed system, escalate to the BL7701.
The BL5701 uses the medium to heavy duty BL5000 series lock body. The BL7701 uses the heavier duty BL7000 series body with an SFIC (Small Format Interchangeable Core) cylinder format compatible with the Unican 1000/5000 and master key systems - making it the right choice for high-traffic commercial buildings with existing master key programs. For most standard commercial and external applications requiring code-plus-key access, the BL5701 is appropriate. If the door sees genuinely high traffic or must accept an existing keyed system, escalate to the BL7701.
How do I change the handing on the BL5701 - it's different from the BL5001
The BL5701 keypad handle handing procedure differs from the BL5001 because the key override cylinder adds a second fixing point. Remove the grey rubber grommet on both the top and bottom of the keypad handle to expose two grub screws. Use the included hex wrench to remove both grub screws, lift the handle off the spindle, rotate 180 degrees, refit, and retighten both grub screws, then replace both grommets. The inside flat bar handle is reversed the same way as other BL5000 models (one grommet and grub screw). Full instructions are in the ECP Instruction Segments V2.
The BL5701 keypad handle handing procedure differs from the BL5001 because the key override cylinder adds a second fixing point. Remove the grey rubber grommet on both the top and bottom of the keypad handle to expose two grub screws. Use the included hex wrench to remove both grub screws, lift the handle off the spindle, rotate 180 degrees, refit, and retighten both grub screws, then replace both grommets. The inside flat bar handle is reversed the same way as other BL5000 models (one grommet and grub screw). Full instructions are in the ECP Instruction Segments V2.
Is the BL5701 suitable for coastal or beachside environments?
Only the BL5701MGPROECP (black Marine Grade Pro) is rated for coastal and saline environments. It uses MG Pro 2 marine external grade coating with 316 stainless steel internal components, tested to 1,000 hours of continuous salt spray. The BL5701SCECP (satin chrome) is designed for internal and sheltered external use only and should not be specified in saline air, beachside, or marine environments. See our salt spray rating guide for the full comparison.
Only the BL5701MGPROECP (black Marine Grade Pro) is rated for coastal and saline environments. It uses MG Pro 2 marine external grade coating with 316 stainless steel internal components, tested to 1,000 hours of continuous salt spray. The BL5701SCECP (satin chrome) is designed for internal and sheltered external use only and should not be specified in saline air, beachside, or marine environments. See our salt spray rating guide for the full comparison.
Additional Information
Key Override Keys are Supplied - But Re-keying is Possible
Unlike the BL7701 where the SFIC cylinder is not included, the BL5701 ships with the key override cylinder pre-fitted and keys included. No additional sourcing is required for the key override to function. If you need the lock re-keyed to an existing master key system, a locksmith can replace the factory-fitted cylinder with a compatible keyed cylinder. Contact Terry's to discuss keyed-alike or master key options before ordering.
Unlike the BL7701 where the SFIC cylinder is not included, the BL5701 ships with the key override cylinder pre-fitted and keys included. No additional sourcing is required for the key override to function. If you need the lock re-keyed to an existing master key system, a locksmith can replace the factory-fitted cylinder with a compatible keyed cylinder. Contact Terry's to discuss keyed-alike or master key options before ordering.
Spindle Selection - Cut from Inside Handle Side Only
Two spindles are supplied (80mm and 90mm). The general rule is door thickness + 30mm = minimum spindle length (15mm must seat inside each lock body). Use the longest spindle that fits. If the spindle is too short it may disengage when the door is slammed hard. Do not trim the keypad-side spindle - this would disrupt the key override engagement geometry. Cut only from the inside handle side. Detailed spindle fitting instructions by lock type are in the ECP Instruction Segments V2 (page 3).
Two spindles are supplied (80mm and 90mm). The general rule is door thickness + 30mm = minimum spindle length (15mm must seat inside each lock body). Use the longest spindle that fits. If the spindle is too short it may disengage when the door is slammed hard. Do not trim the keypad-side spindle - this would disrupt the key override engagement geometry. Cut only from the inside handle side. Detailed spindle fitting instructions by lock type are in the ECP Instruction Segments V2 (page 3).
Marine Grade Maintenance Schedule (BL5701MGPROECP)
Monthly: apply a light spray of silicon-based lubricant (GT85 or equivalent) to the keypad face, button surfaces, and lever; wipe off excess immediately. Do not use oil-based lubricants - they attract dust and degrade the coding chamber. Annually: remove the lock from the door and spray internally through the button holes; test all buttons and lever operation; re-fit. This maintenance schedule is required to maintain the 12-month corrosion resistance warranty. Full details in the Borg Servicing Guide.
Monthly: apply a light spray of silicon-based lubricant (GT85 or equivalent) to the keypad face, button surfaces, and lever; wipe off excess immediately. Do not use oil-based lubricants - they attract dust and degrade the coding chamber. Annually: remove the lock from the door and spray internally through the button holes; test all buttons and lever operation; re-fit. This maintenance schedule is required to maintain the 12-month corrosion resistance warranty. Full details in the Borg Servicing Guide.
Testing the New Code - Do Not Close the Door Until You Have Tested
After any Easicode Pro code change, test the new code at least five times before closing the door. The code change is confirmed only when the lever operates successfully on the new code. If the code change is unsuccessful and the door closes, you will need to use the key override to re-enter. The safe testing procedure is detailed in our code change guide.
After any Easicode Pro code change, test the new code at least five times before closing the door. The code change is confirmed only when the lever operates successfully on the new code. If the code change is unsuccessful and the door closes, you will need to use the key override to re-enter. The safe testing procedure is detailed in our code change guide.
Range Context - Where the BL5701 Sits
The BL5701 is one product in a broader Digital Mechanical Locks range stocked by Gold Coast Smart Locks. Our range quality guide explains the differences between trade-grade mech-digi locks and hardware store alternatives. For a side-by-side brand comparison, see Lockwood vs Borg vs Carbine. More context on how mechanical digital locks work is in Chapter 16 of our Buyer's Guide.
The BL5701 is one product in a broader Digital Mechanical Locks range stocked by Gold Coast Smart Locks. Our range quality guide explains the differences between trade-grade mech-digi locks and hardware store alternatives. For a side-by-side brand comparison, see Lockwood vs Borg vs Carbine. More context on how mechanical digital locks work is in Chapter 16 of our Buyer's Guide.
Borg Locks Warranty - 12 Months (Australia)
All Borg locks are warranted against mechanical defects in materials and workmanship under normal use and service for a minimum of 12 months from date of sale. The warranty does not cover damage arising from misuse, vandalism, or improper installation. The lock must not be dismantled - doing so will invalidate the warranty. Corrosion resistance is separately warranted for 12 months on the BL5701MGPROECP under the specified maintenance schedule.
All Borg locks are warranted against mechanical defects in materials and workmanship under normal use and service for a minimum of 12 months from date of sale. The warranty does not cover damage arising from misuse, vandalism, or improper installation. The lock must not be dismantled - doing so will invalidate the warranty. Corrosion resistance is separately warranted for 12 months on the BL5701MGPROECP under the specified maintenance schedule.
Purchased through Terry's Locksmiths? Contact Terry's Locksmiths first - we manage your warranty claim on your behalf. This warranty operates alongside your rights under the Australian Consumer Law.
Download PDF Resources
Borg BL5000 / BL5700 ECP Series User Manual and Code Change Instructions
Borg BL5000 ECP Instruction Segments V2 - Handing, Spindle Fitting, Code Change, Operation
Borg BL5001 / BL5401 / BL5701 Drilling Template
Borg BL5700 ECP Series Brochure (BL5700 / BL5701 / BL5771)
Borg BL5700 MG Pro ECP Series Brochure (BL5701MGPROECP / BL5771MGPROECP)
Borg Lock Servicing and Maintenance Guide
Borg BL5000 / BL5700 ECP Series User Manual and Code Change Instructions
Borg BL5000 ECP Instruction Segments V2 - Handing, Spindle Fitting, Code Change, Operation
Borg BL5001 / BL5401 / BL5701 Drilling Template
Borg BL5700 ECP Series Brochure (BL5700 / BL5701 / BL5771)
Borg BL5700 MG Pro ECP Series Brochure (BL5701MGPROECP / BL5771MGPROECP)
Borg Lock Servicing and Maintenance Guide
What's In The Box - Borg BL5701SCECP / BL5701MGPROECP
- Borg BL5701 ECP outside keypad and lever assembly with built-in key override cylinder (selected finish)
- Key override keys - pre-fitted cylinder, keys included (typically 2 keys)
- Flat bar inside lever handle assembly (selected finish)
- 60mm heavy duty anti-thrust tubular latch (stainless steel)
- Strike plate and box keep
- Spindles - 80mm and 90mm
- M4 fixing screws - 40mm, 50mm, 60mm options
- 4 x 16mm screws
- Easicode Pro code change key (phi key)
- Code change deactivation plug (optional - permanently disables on-door code change)
- Free passage deactivation plug (optional - permanently disables F button)
- Hex wrench (Allen key)
- Handle screw rubber grommet
- Installation instructions
60mm anti-thrust stainless steel tubular latch - included with both variants
A 70mm backset latch (BLL500070) is available separately if required. No batteries, wiring, or electronic components are required or supplied.
Borg BL5701 ECP Series - Dimensions
Three dimensional drawings for the BL5701 ECP series are shown below: the keypad and inside lever engineering drawings (supplied by Borg), the latch body engineering drawing, and the legacy line drawing previously used on this page. All measurements from Borg engineering drawings.
BL5701 ECP - inside and outside lever handle dimensions (keypad: 178mm H x 48mm W; 129.4mm lever; 76.8mm depth)
BL5701 60mm latch body dimensions (faceplate 58mm H x 30mm W; bolt projection 20.5mm; backset 60mm; overall length 94.3mm)
BL5700 ECP series - outside keypad lever with key override and inside flat bar lever (legacy dimensional line drawing)
Borg BL5701 ECP Series - Product Brochure
BL5701 ECP Series - key override in lever handle, Easicode Pro, specifications and dimensional drawings
Download PDF Resources - Borg BL5701 ECP
Borg BL5000 / BL5700 ECP Series User Manual and Code Change Instructions
Borg BL5000 ECP Instruction Segments V2 - Handing, Spindle Fitting, Code Change, Operation
Borg BL5001 / BL5401 / BL5701 Drilling Template
Borg BL5700 ECP Series Brochure (BL5700 / BL5701 / BL5771)
Borg BL5700 MG Pro ECP Series Brochure (BL5701MGPROECP / BL5771MGPROECP)
Borg Lock Servicing and Maintenance Guide
Borg BL5000 / BL5700 ECP Series User Manual and Code Change Instructions
Borg BL5000 ECP Instruction Segments V2 - Handing, Spindle Fitting, Code Change, Operation
Borg BL5001 / BL5401 / BL5701 Drilling Template
Borg BL5700 ECP Series Brochure (BL5700 / BL5701 / BL5771)
Borg BL5700 MG Pro ECP Series Brochure (BL5701MGPROECP / BL5771MGPROECP)
Borg Lock Servicing and Maintenance Guide
Borg BL5701 ECP - In-Depth Questions and Answers
Detailed pre-purchase and installer questions for the Borg BL5701 ECP mechanical digital lever lock with built-in key override. Also see our What Is a Mechanical Digital Lock? and Heavy Duty Commercial Mechanical Digital Locks guides.
Key Override
Where exactly is the key override cylinder on the BL5701?
Inside the lever handle body of the outside (keypad) unit. There is no separate cylinder below the keypad on the face plate. The cylinder is positioned within the handle itself, and the key entry point is visible on the side or face of the lever depending on the door's handing. This is the defining feature that distinguishes the BL5701 from a standard keypad lock with a separate external cylinder: the face plate stays clean, the override is accessible in a natural gripping position, and the key rotation engages the clutch mechanism directly without a secondary linkage.
Inside the lever handle body of the outside (keypad) unit. There is no separate cylinder below the keypad on the face plate. The cylinder is positioned within the handle itself, and the key entry point is visible on the side or face of the lever depending on the door's handing. This is the defining feature that distinguishes the BL5701 from a standard keypad lock with a separate external cylinder: the face plate stays clean, the override is accessible in a natural gripping position, and the key rotation engages the clutch mechanism directly without a secondary linkage.
Can I re-key the BL5701 to match my existing door keys?
Yes, through a locksmith. The factory-fitted cylinder can be replaced with a keyed-alike or master-keyed cylinder to match an existing system. Contact Terry's Locksmiths before ordering if master keying or keyed-alike is required - we can advise which cylinder profiles are compatible with the BL5701 handle geometry. Read more about key override cylinder options.
Yes, through a locksmith. The factory-fitted cylinder can be replaced with a keyed-alike or master-keyed cylinder to match an existing system. Contact Terry's Locksmiths before ordering if master keying or keyed-alike is required - we can advise which cylinder profiles are compatible with the BL5701 handle geometry. Read more about key override cylinder options.
What is the difference between the BL5701 key override and the BL7701 SFIC override?
The BL5701 uses a conventional cylinder fitted inside the lever handle, with keys supplied at purchase. The BL7701 uses an SFIC (Small Format Interchangeable Core) cylinder format that matches the Unican 1000/5000 footprint. SFIC allows the core to be swapped by an authorised person without removing the lock from the door - a significant advantage in large commercial buildings with master key programs. If your building uses an SFIC key system (Unican, Best, Medeco), the BL7701 is the correct choice. If not, the BL5701's conventional cylinder is simpler and more economical.
The BL5701 uses a conventional cylinder fitted inside the lever handle, with keys supplied at purchase. The BL7701 uses an SFIC (Small Format Interchangeable Core) cylinder format that matches the Unican 1000/5000 footprint. SFIC allows the core to be swapped by an authorised person without removing the lock from the door - a significant advantage in large commercial buildings with master key programs. If your building uses an SFIC key system (Unican, Best, Medeco), the BL7701 is the correct choice. If not, the BL5701's conventional cylinder is simpler and more economical.
Code Change and Operation
How do I change the PIN code on the BL5701?
With the door open, enter the current code and rotate the lever to confirm you know the correct code. Insert the Easicode Pro code change key (phi key) into the phi button at the top of the keypad and rotate it 90 degrees clockwise, holding it in position. Press C to clear, then enter the new code digits, press the digits again to confirm, release and remove the key. Press C or rotate the lever to finalise. Test the new code at least five times before closing the door. The code is non-sequential - the buttons can be pressed in any order. Full step-by-step at ECP code change steps.
With the door open, enter the current code and rotate the lever to confirm you know the correct code. Insert the Easicode Pro code change key (phi key) into the phi button at the top of the keypad and rotate it 90 degrees clockwise, holding it in position. Press C to clear, then enter the new code digits, press the digits again to confirm, release and remove the key. Press C or rotate the lever to finalise. Test the new code at least five times before closing the door. The code is non-sequential - the buttons can be pressed in any order. Full step-by-step at ECP code change steps.
I've forgotten the PIN code - how do I recover access?
Use the key override: insert the key into the cylinder in the lever handle and rotate away from the door edge. Once inside, you can change the code to a new one using the phi-button ECP procedure. If you do not have the key, or if the cylinder has been lost, contact Terry's Locksmiths for assistance. In some cases, the lost code can be identified by a visual inspection of the coding chamber using the porthole method described in the ECP User Manual. See our guide to ECP code recovery.
Use the key override: insert the key into the cylinder in the lever handle and rotate away from the door edge. Once inside, you can change the code to a new one using the phi-button ECP procedure. If you do not have the key, or if the cylinder has been lost, contact Terry's Locksmiths for assistance. In some cases, the lost code can be identified by a visual inspection of the coding chamber using the porthole method described in the ECP User Manual. See our guide to ECP code recovery.
How does free passage work, and when would I use it?
Free passage lets the lever turn and the latch retract without entering the code on every use. Enter the code, rotate the lever, then press F while the lever is still rotating. The lever is now free-turning. To exit free passage mode, rotate the lever and press C until you hear an audible click. This is useful during business hours, move-in days, or any period when continuous code-free entry is wanted. It is not a holdback - the latch still engages when the door closes. Free passage can be permanently disabled with the supplied plug if the installation does not require it. See passage mode explained.
Free passage lets the lever turn and the latch retract without entering the code on every use. Enter the code, rotate the lever, then press F while the lever is still rotating. The lever is now free-turning. To exit free passage mode, rotate the lever and press C until you hear an audible click. This is useful during business hours, move-in days, or any period when continuous code-free entry is wanted. It is not a holdback - the latch still engages when the door closes. Free passage can be permanently disabled with the supplied plug if the installation does not require it. See passage mode explained.
Product Selection
Is the BL5701 fire rated?
No. The BL5701 is not fire rated. If you need a fire-rated lock with the ECP code change method in the BL5000 platform, the BL5001 is fire rated (AS1905.1, up to 4hr doorset dependent) but does not include a key override. Combining ECP code change with a key override in a fire-rated door requires assessment with the door manufacturer - contact Terry's. Read more at Fire Door Locks and our commercial fire door guide.
No. The BL5701 is not fire rated. If you need a fire-rated lock with the ECP code change method in the BL5000 platform, the BL5001 is fire rated (AS1905.1, up to 4hr doorset dependent) but does not include a key override. Combining ECP code change with a key override in a fire-rated door requires assessment with the door manufacturer - contact Terry's. Read more at Fire Door Locks and our commercial fire door guide.
I need key override on both sides of the door - which product?
The BL5771MGPROECP is the back-to-back version with key override on both sides. Note that on the BL5771, the inside handle is also a keypad unit (not a free-turning flat bar lever) - meaning code or key is required to exit from either side. The BL5701 has a free-turning inside lever. If you need code or key to enter from outside but free egress from inside, the BL5701 is correct. If you need controlled access from both sides, the BL5771MGPROECP is the right product. Compare in the Item Code Family table.
The BL5771MGPROECP is the back-to-back version with key override on both sides. Note that on the BL5771, the inside handle is also a keypad unit (not a free-turning flat bar lever) - meaning code or key is required to exit from either side. The BL5701 has a free-turning inside lever. If you need code or key to enter from outside but free egress from inside, the BL5701 is correct. If you need controlled access from both sides, the BL5771MGPROECP is the right product. Compare in the Item Code Family table.
How does the BL5701 compare to a smart lock with key override?
A smart lock with key override (such as the Yale Unity) relies on electronics, batteries, and firmware. The BL5701 has no electronics at all - if the door is accessible, the lock will always operate. There is no battery replacement, no app updates, no connectivity dependency. The trade-off is a single PIN (no user management, no audit trail) and no remote access. For an environment where reliability and low maintenance outweigh audit capability, the BL5701 is the better choice. For remote management, multi-user access, or activity logs, a smart lock platform is more appropriate. The comparison is explored in detail in our Mechanical vs Smart guide.
A smart lock with key override (such as the Yale Unity) relies on electronics, batteries, and firmware. The BL5701 has no electronics at all - if the door is accessible, the lock will always operate. There is no battery replacement, no app updates, no connectivity dependency. The trade-off is a single PIN (no user management, no audit trail) and no remote access. For an environment where reliability and low maintenance outweigh audit capability, the BL5701 is the better choice. For remote management, multi-user access, or activity logs, a smart lock platform is more appropriate. The comparison is explored in detail in our Mechanical vs Smart guide.
Installation and Fitting
My door is thicker than 54mm - will the BL5701 fit?
The BL5701 comes with fixings for 35-54mm doors. For thicker doors, an XL fixing kit (BLS275000) may extend the range - confirm with Terry's at order time. The spindle length also needs to be considered: for thicker doors, a longer spindle than the supplied 80mm and 90mm may be needed. The ECP Instruction Segments V2 (page 3) covers spindle selection by lock type and door thickness.
The BL5701 comes with fixings for 35-54mm doors. For thicker doors, an XL fixing kit (BLS275000) may extend the range - confirm with Terry's at order time. The spindle length also needs to be considered: for thicker doors, a longer spindle than the supplied 80mm and 90mm may be needed. The ECP Instruction Segments V2 (page 3) covers spindle selection by lock type and door thickness.
Can I use a 70mm backset with the BL5701?
Yes. The 60mm backset tubular latch is included. A 70mm backset latch (BLL500070) is available separately and is fire rated. The lock body accepts the 70mm latch without modification to the keypad or inside handle. Use the drilling template (BL5001/BL5401/BL5701 Drilling Template PDF) to mark both 60mm and 70mm positions.
Yes. The 60mm backset tubular latch is included. A 70mm backset latch (BLL500070) is available separately and is fire rated. The lock body accepts the 70mm latch without modification to the keypad or inside handle. Use the drilling template (BL5001/BL5401/BL5701 Drilling Template PDF) to mark both 60mm and 70mm positions.
What existing lock can the BL5701 replace or retrofit over?
The BL5701 uses an 8mm square drive spindle, which is the standard Australian preparation and is compatible with most existing tubular latch mortices. The drilling template confirms the hole positions. Unlike the BL7701 which is purpose-built to retrofit Unican 1000/5000 cylinders, the BL5701 is a standard new-installation product. It does not specifically retrofit Lockwood 530 or NK2000 bodies without confirming the door preparation matches. See our retrofit kits guide for combination options.
The BL5701 uses an 8mm square drive spindle, which is the standard Australian preparation and is compatible with most existing tubular latch mortices. The drilling template confirms the hole positions. Unlike the BL7701 which is purpose-built to retrofit Unican 1000/5000 cylinders, the BL5701 is a standard new-installation product. It does not specifically retrofit Lockwood 530 or NK2000 bodies without confirming the door preparation matches. See our retrofit kits guide for combination options.
Borg Locks Warranty
Borg products sold in Australia are covered against mechanical defects in materials and workmanship under normal use and service. Warranty claims are handled by Terry's Tradies Pty Ltd and its associated websites, trading names, and subsidiaries.
Warranty Summary
What the Warranty Covers
- Mechanical defects in materials and workmanship
- Defects arising under normal use and service conditions
- Repair or replacement of defective units at the discretion of the Australian distributor (LSC)
What the Warranty Does Not Cover
- Damage arising from misuse, vandalism, or abuse
- Damage resulting from improper installation
- Locks that have been dismantled - dismantling invalidates the warranty
- Normal wear and tear
- Cosmetic damage not affecting function
How to Make a Claim
For full returns and warranty claim procedures, visit our Returns & Warranty page - this is kept up to date and is the authoritative reference for current claim steps.
- Contact Terry's Tradies Pty Ltd first if you purchased through us or one of its associated trading names - we will assess the issue and manage the warranty process with LSC on your behalf. You do not need to contact LSC or Borg Locks UK directly.
- Have your proof of purchase ready (receipt or order confirmation).
- Warranty claims for Borg products in Australia are processed through LSC, the authorised Australian importer and distributor. Where an item is returned to LSC, freight charges must be prepaid and the item returned within the warranty period.
- If LSC finds the returned item to be defective, it will be repaired or replaced, and a detailed assessment report is provided to the customer after examination.
Australian Consumer Law
Our goods come with guarantees that cannot be excluded under the Australian Consumer Law. You are entitled to a replacement or refund for a major failure and compensation for any other reasonably foreseeable loss or damage. You are also entitled to have the goods repaired or replaced if the goods fail to be of acceptable quality and the failure does not amount to a major failure. The Borg manufacturer warranty above operates alongside - and does not limit - these statutory rights.
Our goods come with guarantees that cannot be excluded under the Australian Consumer Law. You are entitled to a replacement or refund for a major failure and compensation for any other reasonably foreseeable loss or damage. You are also entitled to have the goods repaired or replaced if the goods fail to be of acceptable quality and the failure does not amount to a major failure. The Borg manufacturer warranty above operates alongside - and does not limit - these statutory rights.
Confused? Overwhelmed? We get it.
Choosing the right smart lock can be genuinely tricky - door types, backsets, app platforms, compatibility with your existing hardware... there is a lot to consider. We have decades of experience fitting locks of all types, including smart locks, and we are happy to help.
Our expert recommendation service is free. Upload a few photos of your door and describe what you need, and one of our qualified locksmiths will give you a personalised recommendation.
Get Your Free Recommendation →How it works - three easy steps:
1. Upload photos
A few clear shots of your door, lock and frame - inside and out.
2. We assess
Our locksmith reviews your setup and requirements - door type, weather exposure, how you want to use it.
3. You get a recommendation
A personalised recommendation tailored to your door, budget and needs. No pressure, no upsell.
Also useful while you are deciding:
