Carbine CDL7200LL-KDSC-HD Mechanical Digital Lock - Dual Keypad Dual BCA Lever

At A Glance

At A Glance

LOCK TYPEMechanical Digital - No Batteries

DUAL KEYPADCode Both Sides

CODE CHANGERear Slider Switches

HANDINGReversible LH & RH

BACKSET60mm Standard

DOOR THICKNESS32 - 54mm

CYCLE TESTED100,000+ Openings

SALT SPRAY240hr - C7 High

INTERNALSStainless Steel

DUTY RATINGHigh Volume Commercial

LEVERSBCA Both Sides

SECURITY LEVERBreak Point Fitted

RETROFITCovers NK2000 & 530 Holes

STANDARDSAS1428.1 + AS4145.2

FIRE / EGRESS DOORSNot Allowed

OUTDOOR USEGate Installs Proven

WARRANTY10 Years

FINISHSatin Chrome

IN THE BOXComplete Fitting Kit

UNLOCK WITH

PIN Code - Both Sides Key Override
Not Available

The Carbine CDL7200LL-KDSC-HD is the dual keypad model of the CDL7200 Heavy Duty series. It carries a mechanical digital keypad on both the external and internal faces, along with BCA-compliant lever handles on both sides, so a valid code must be entered to operate the lever from either side of the door. That gives you keyless, code-controlled access and exit in both directions - without a battery, an app, or a single electronic component. If mechanical digital locks are new to you, our guide to how a battery-free keypad lock works covers the coding chamber that sits behind those buttons.

Bidirectional code control suits rooms where movement in and out both need restricting: server and data rooms, pharmaceutical storage, cash-handling areas, and restricted zones in institutional buildings. Like every CDL7 HD series lock, it runs stainless steel cryptographic elements, exceeds 100,000 tested cycle openings, and is salt spray tested to 240 hours (C7 High). Our heavy duty commercial guide explains what those internals mean over years of high-traffic use, and the Buyers Guide's commercial mech-digi chapter puts the CDL7 range in context against the rest of the Digital Mechanical Locks range.

The standard unit is 60mm backset, satin chrome, reversible for left and right hand doors, and suits doors 32 to 54mm thick. The 59mm-wide body covers the fixing holes of common NK2000 and Lockwood 530 installations, which makes it a tidy retrofit upgrade. One design point to understand before you buy: the external lever carries a security break point - see the caution below.

Important - External Lever Security Break Point
The external lever on this lock features a security break point: it will shear off under excessive pull force. This is deliberate - it stops the lever being used to force the lock - but it means the lever must never be used as a pull handle on a heavy door. If real pull force is needed to open the door (a strong closer, wind load), fit a separate pull handle rated for the job. For heavy-door applications, the knob-external Carbine CDL7100SC-HD is often the better pick.

Heavy Duty - Rated for High Volume Commercial Use
Exceeds 100,000 cycle openings with stainless steel cryptographic elements - the HD series runs steel where standard mechanical digital locks run zinc. Suited to secure commercial and institutional doors that get worked all day. Our guide to high-traffic keypad locks covers when heavy duty is worth paying for.

Weather Resistant - 240 Hour Salt Spray Tested (C7 High)
Salt spray tested to 240 hours per AS4145.2-2008 and rated C7 (High) - a genuine tested figure, not a marketing line. Finish degradation from salt and weather exposure is excluded from warranty, so on coastal sites plan on wiping the finish down regularly. Carbine's salt spray testing information sheet (PDF) explains the test method, and the Buyers Guide's corrosion grade explainer shows where C7 sits on the AS4145.2 scale.

BCA Compliant - Dual Lever Both Sides (AS1428.1)
Both lever handles meet BCA accessibility clearance requirements (35-45mm grip clearance per AS1428.1). Note the flip side: because a code must be entered before either lever will operate, this model needs assessing against any DDA or egress requirements that apply to the specific doorway before it is specified.

Key Features

• Mechanical digital keypad on both external and internal faces - a code is required to operate the lever from either side.
• BCA-compliant lever handles on both faces (AS1428.1 clearance).
• External lever runs a clutching mechanism and a security break point - never use it as a pull handle.
• Fully mechanical push-button lock - no batteries, no electronics, no connectivity, nothing to charge or pair.
• Heavy duty series build: stainless steel cryptographic elements, exceeding 100,000 cycle openings.
• Ball bearing style push buttons resist code manipulation and decoding attempts.
• Code changed via slider switches at the rear of the external pad - see Code Control below.
• 240 hour salt spray tested, rated C7 High per AS4145.2-2008.
• 60mm backset, suits doors 32-54mm thick, reversible for left and right hand doors.
• 59mm body width covers NK2000 and Lockwood 530 fixing holes for clean retrofits.
• Satin chrome finish. Factory default code C13579 - must be changed before installation.

Code Control - Both Sides of the Door

Both keypads use the same code. It is set once, via slide code-select switches behind the external pad, and applies to both faces - there is no separate internal code. Enter the code, turn the lever, and the latch withdraws; on the other side of the door, exactly the same. This is what separates the KDSC from the single-keypad CDL7200LL-HD, whose internal lever always operates freely.

Changing the code is a bench job: the lock comes off the door, the slide switches at the rear of the external assembly are set to the new combination, and the CLEAR (C) button must always be pressed before a code is entered. The factory default is C13579 and must be changed - and tested from both sides with the door open - before the door is closed on it. The full procedure with figures is in the installation instructions (PDF), and our Carbine slider code-change walkthrough steps it through with realistic timings.

What's in the Box

• 1 x CDL7200LL-KDSC-HD front body lock assembly (external keypad and lever)
• 1 x interior handle assembly with keypad and lever
• 1 x 60mm tubular latch assembly
• 1 x notched tailbar
• 1 x fitting plate
• 1 x strike box and strike plate
• 1 x latch support post
• 2 x gaskets (front and rear)
• 2 x 25mm M5-M5 hex lugs
• 2 x 30mm M5 screws and 2 x 40mm M5 screws
• 4 x 8G x 25mm wood screws
• 1 x Allen key
• 1 x installation template and instruction manual

Suitable Uses

• Server rooms, data rooms, and IT equipment stores where entry and exit must both be code-controlled
• Pharmaceutical stores, dispensaries, and restricted medical storage
• Secure stockrooms and cash-handling areas in retail environments
• Restricted zones in institutional buildings requiring bidirectional code control
• Retrofit of NK2000 or Lockwood 530 installations where dual keypad control is required
• Pedestrian and pool gates where code control is wanted in both directions - see Gate Installations below

Gate Installations

A large share of the CDL7200 units we fit go onto gates - the Installation Gallery tab shows real pool and pedestrian gate installs from around the Gold Coast. Double-sided code control earns its keep on gates because a reach-over or reach-through defeats a single-sided keypad in seconds; our guide to why double-sided locks make sense on gates walks through exactly that problem.

On pool gates, one thing matters above all: the lock controls access, but the pool barrier itself must still self-close and self-latch to meet barrier rules - fitting a keypad lock never substitutes for that. The pool gate section of our latch vs bolt guide covers the setup requirements. For gate posts and mounting, the Carbine Gate Guard for CDL7 (mounting box) adapts the lock to gate frames - see its specification sheet (PDF) and installation instructions (PDF), or ask us about fitting. The Buyers Guide's gate keypad locks chapter covers the wider decisions - stile widths, latch types, and exposure.

Available Finish Options

•
  Satin Chrome
  (This Product)
  STK CDL7200LL-KDSC-HD

Finish selection does not affect functionality, compliance, or performance.

CDL7 HD Series - Product Family

Four heavy duty configurations share the CDL7 platform - the differences are handle type, holdback, and how many keypads. Our three-brand comparison covers where the CDL7 sits against Lockwood DX and Borg equivalents.

All models satin chrome. HD series runs stainless steel cryptographic elements and exceeds the 100,000 cycle test. Need holdback? That is the CDL7100-HBSC-HD - the CDL7200 models do not carry it. Our holdback mode explainer covers what the function actually does.

Full Specifications

Dimensions

Manufacturer dimensional drawing for the Carbine CDL7200LL-KDSC-HD. Overall height 191mm, body width 48mm (59mm total), lever projection 132mm. Backset 60mm. Door thickness 32-54mm.

Not sure of your backset? Our backset measuring guide shows how to check it in under a minute, and the Buyers Guide's door measuring chapter covers thickness, handing, and everything else worth checking before ordering.

Fire Doors and Egress - Read Before Specifying

This dual-keypad model must never be fitted to a fire door or any regulated egress door. A double-sided keypad requires a code to exit, and Australian building codes require occupants to exit fire-rated egress doors without operating a key, code, or similar device. That rule applies to every double-sided keypad setup, regardless of how the lock body itself is fire assessed.

The distinction matters, so here it is plainly: the CDL7200 lock body has genuine fire assessment behind it. Warringtonfire's master door hardware assessments cover the CDL7100 and CDL7200 at FRL -/120/30 with 60mm backset - on E-core doorsets in report FAS220275 (Table 10, page 14) and on Firecore doorsets in report FAS220387 (Table 9, page 10). Those assessments apply per doorset type and are not interchangeable between core types - our guide to reading fire certification documents explains how to match a report to your actual door, and the Buyers Guide's fire door core types chapter covers what E-core and Firecore mean.

But the body assessment never rescues the dual-keypad configuration: code-controlled egress rules it off fire and egress paths full stop. If the doorway is a fire door, look at the single-keypad CDL7200LL-HD, whose internal lever always operates freely, and confirm the full doorset compliance with your certifier - our apartment fire door compliance guide explains FRL ratings and what certifiers look for, and you can browse everything we carry for those doors in the Fire Door category.

Frequently Asked Questions

Do both keypads use the same code?
Yes. Both the external and internal keypads use the same code. It is set once, via the slide switches behind the external pad, and applies to both sides - there is no separate internal code. See Code Control above for how changes work.

Can this lock be used on a fire door?
No. Because a code must be entered to open the door from the inside, this model cannot go on any door that forms part of a fire egress path - the lock body's fire assessment does not change that. The full explanation, with the certification documents, is in Fire Doors and Egress above.

Why does the external lever have a break point, and what does that mean in practice?
The break point is a security feature: the lever shears off if excessive lateral or pull force is applied, so it cannot be used to force the lock. In practice it means the lever is not a pull handle - on heavy doors, or doors with strong closers, fit a separate pull handle rated for the load.

What is the difference between the CDL7200LL-KDSC-HD and the CDL7200LL-HD?
The CDL7200LL-HD has a keypad on the external face only - its internal lever operates freely, no code needed to exit. The KDSC adds a keypad to the internal face as well, so a code is required from both sides. Free internal egress also makes the single-keypad model the one to discuss for fire doors.

Can this lock be supplied in a 70mm backset?
The standard listed item (CDL7200LL-KDSC-HD) is 60mm. 70mm and 127mm backset options exist in the CDL7 range but are sold separately - contact us to confirm availability for this dual-keypad variant. If you are not sure what backset your door needs, our backset measuring guide takes a minute.

Additional Information

Egress compliance: This lock requires code entry to open from the internal face. It must not be specified on any door forming part of a regulated egress path under the National Construction Code - fire exits, stairwell doors, or any door occupants must pass through to reach safety in an emergency. Certain occupancies and door positions carry mandatory free-egress requirements. Confirm suitability with your building certifier before specifying.

External lever and pull handles: The security break point means the external lever must not be used to pull heavy doors open. Where a closer or wind load needs real pull force, install a separate pull handle rated for the door.

Code change before installation: The factory default code C13579 must be changed and tested before the lock is fitted. The single code applies to both keypads - test both sides with the door open before closing it. Our code change guide's test-five-times rule exists because of exactly this moment.

Retrofitting older locks: The 59mm body width covers the fixing holes of NK2000 and Lockwood 530 installations, so most swaps need no door patching. Where an older lock has left larger scarring, the CDL72 edge plate (PDF) covers the door edge. Our guide to retrofit kits and spare parts covers why serviceable hardware matters over a lock's life.

Coastal sites: The C7 High salt spray rating is strong, but finish tarnish from salt exposure is excluded from warranty across the industry - Carbine included. A regular freshwater wipe-down keeps the satin chrome presentable; the mechanism itself stays covered for the full 10 years.

Warranty

Carbine 10 Year Warranty - Mechanical Digital Locks
Carbine is a Davcor Group brand, and Davcor backs its mechanical digital locks with one of the longest warranties in the category: 10 years against defects in materials and workmanship from the date of original purchase. There are no electronics or batteries in this lock to shorten the cover - the whole product is warranted for the full term.

On a valid claim, Davcor will repair the lock, replace it, or supply an equivalent product. Keep your proof of purchase, and make the claim as soon as a defect becomes apparent.

What the warranty does not cover: fair wear and tear; damage caused by faulty installation, misuse, or modification of the product; and tarnishing or change to the finish from weather, salt, or chemical exposure. On coastal and exposed sites, regular cleaning of the finish is the practical answer - the lock mechanism itself remains covered.

Our goods come with guarantees that cannot be excluded under the Australian Consumer Law. You are entitled to a replacement or refund for a major failure and compensation for any other reasonably foreseeable loss or damage. You are also entitled to have the goods repaired or replaced if the goods fail to be of acceptable quality and the failure does not amount to a major failure.

Purchased through Terry's Locksmiths? Contact us first - we'll manage your warranty claim with Davcor on your behalf. Full terms: davcor.com.au/warranty
