Carbine CDL7200LL-HD Mechanical Digital Lock - Heavy Duty Dual BCA Lever
At A GlanceAt A Glance
PIN Code - Outside
Free Lever - Inside
Key OverrideNot Available
The Carbine CDL7200LL-HD is a heavy duty mechanical digital lockset with a BCA-compliant lever handle on both faces of the door. A code is entered on the external keypad to gain entry; the internal lever always turns freely, so anyone inside can leave at any time without a code. That combination - controlled entry, unrestricted exit - is what makes this single-keypad model suitable for fire and egress doors, where the double-sided CDL7200LL-KDSC-HD is not. If mechanical digital locks are new to you, our guide to how a battery-free keypad lock works covers the coding chamber behind the buttons.
Both lever handles meet AS1428.1 clearance, so this is one of the few keyless mechanical digital locks that satisfies dual-sided accessibility where it is specified - accessible entry doors in aged care, hospitals, medical centres and schools. As part of the CDL7 HD series it runs stainless steel cryptographic elements, exceeds 100,000 tested cycle openings, and is salt spray tested to 240 hours (C7 High). Our heavy duty commercial guide explains what those internals mean over years of high-traffic use, and the Buyers Guide's commercial mech-digi chapter puts the CDL7 range in context against the rest of the Digital Mechanical Locks range.
The lock comes in two backsets - 60mm standard (CDL7200LLSCHD) and 70mm (CDL720070LLSCHD) - in satin chrome, reversible for left and right hand doors, and suits doors 32 to 54mm thick. The 59mm-wide body covers the fixing holes of common NK2000 and Lockwood 530 installations, making it a clean retrofit upgrade. One design point to understand before you buy: the external lever carries a security break point - see the caution below.
The external lever features a security break point: it shears off under excessive pull force, which stops the lever being used to force the lock. The trade-off is that the lever must never be used as a pull handle. On heavy doors, or doors with strong closers or wind load, fit a separate pull handle rated for the job - or choose the knob-external Carbine CDL7100SC-HD instead. Using the external lever as a pull handle causes premature failure and is not covered by warranty.
Exceeds 100,000 cycle openings with stainless steel cryptographic elements - the HD series runs steel where standard mechanical digital locks run zinc. Suited to high-volume commercial and institutional doors where dual BCA lever access is required. Our guide to high-traffic keypad locks covers when heavy duty is worth paying for.
Salt spray tested to 240 hours per AS4145.2-2008 and rated C7 (High) - suited to moderate, tropical and industrial or marine environments 100m to 10km from the coast. Finish degradation from salt and weather exposure is excluded from warranty, so on coastal sites plan on wiping the finish down regularly. Carbine's salt spray testing information sheet (PDF) explains the test method, and the Buyers Guide's corrosion grade explainer shows where C7 sits on the AS4145.2 scale.
Both lever handles meet BCA accessibility clearance (35-45mm grip clearance per AS1428.1) on the external and internal faces. The internal lever operates the latch freely regardless of code state, so exit is always single-action - part of what makes this model workable on accessible and egress doors.
Key Features
- BCA-compliant lever handle on both external and internal faces (AS1428.1).
- External lever clutches - free-turning without a valid code, engaging the latch on correct code entry.
- Internal lever always operates the latch freely - single-action exit, no code needed to leave.
- External lever has a security break point - shears under excessive pull force; never use as a pull handle.
- Fully mechanical push-button lockset - no batteries, electronics, or connectivity.
- Heavy duty series build: stainless steel cryptographic elements, exceeding 100,000 cycle openings.
- Ball bearing style push buttons resist code manipulation and decoding.
- Code changed via slider switches at the rear of the external pad, without disassembling the body - see Code Control below.
- Fire rated -/120/30 with the supplied latchset on Firecore and E-Core doorsets.
- 240 hour salt spray tested, rated C7 High per AS4145.2-2008.
- 60mm backset standard, 70mm available; suits doors 32-54mm thick; reversible for left and right hand doors.
- 59mm body width covers NK2000 and Lockwood 530 fixing holes for clean retrofits.
- Satin chrome finish. Factory default code C13579 - must be changed before installation.
Code Control and the Clutching Lever
Entry works through the external keypad only. With no valid code entered, the external lever clutches - it turns freely without moving the latch. Enter the correct code and the lever engages the latch for one operation, letting the door open. The internal lever is different: it always drives the latch, so exit from inside never needs a code. That is the single most important behaviour to understand on this model, and it is why it suits fire and egress doors where the dual-keypad KDSC does not.
Changing the code is a straightforward bench task: slide code-select switches at the rear of the external assembly are set to the new combination, and the CLEAR (C) button must always be pressed before a new code is entered. The factory default is C13579 and must be changed - and tested with the door open - before the door is closed on it. Carbine recommend 4-5 digit codes for higher security. The full procedure with figures is in the installation instructions (PDF), and our Carbine slider code-change walkthrough steps it through with realistic timings.
What's in the Box
- 1 x CDL7200LL-HD front body lock assembly (external lever and keypad)
- 1 x interior lever handle assembly
- 1 x 60mm tubular latch assembly
- 1 x notched tailbar
- 1 x fitting plate
- 1 x strike box and strike plate
- 1 x latch support post
- 2 x gaskets (front and rear)
- 2 x 25mm M5-M5 hex lugs
- 2 x 30mm M5 screws and 2 x 40mm M5 screws
- 4 x 8G x 25mm wood screws
- 1 x Allen key
- 1 x installation template and instruction manual
Suitable Uses
- Commercial and institutional doors requiring BCA-accessible lever handles on both faces
- Access doors in disability and aged care facilities, hospitals, and medical centres
- School and education facility internal doors with accessibility requirements
- Storerooms, plant rooms, and utility access needing code control with dual lever access
- Fire-rated door assemblies built on Firecore or E-Core systems - see Fire Rating below
- Pool gates, pedestrian gates, and light-duty external gates (confirm door weight and pull-force) - see Gate Installations
- Retrofit of NK2000 or Lockwood 530 installations where dual lever compliance is needed
Gate Installations
A large share of the CDL7200 units we fit go onto gates - the Installation Gallery tab shows real pool and pedestrian gate installs from around the Gold Coast. On a gate, weigh two things: the external lever's break point means it must not be pulled hard (fit a separate pull handle where the gate is heavy or spring-loaded), and the pool barrier itself must still self-close and self-latch to meet barrier rules - the lock provides code control, it never substitutes for the barrier's own compliance. The pool gate section of our latch vs bolt guide covers the setup requirements.
For gate posts and mounting, the Carbine Gate Guard for CDL7 (mounting box) adapts the lock to gate frames - see its specification sheet (PDF) and installation instructions (PDF), or ask us about fitting. The Buyers Guide's gate keypad locks chapter covers the wider decisions - stile widths, latch types, and exposure.
Available Finish Options
Satin Chrome
(This Product)
STK CDL7200LL
Finish selection does not affect functionality, compliance, or performance.
CDL7 HD Series - Product Family
Four heavy duty configurations share the CDL7 platform - the differences are handle type, holdback, and how many keypads. Our three-brand comparison covers where the CDL7 sits against Lockwood DX and Borg equivalents.
All models satin chrome. HD series runs stainless steel cryptographic elements and exceeds the 100,000 cycle test. Need a code required to exit as well? That is the dual-keypad CDL7200LL-KDSC-HD - but note it cannot go on fire or egress doors. Need holdback? That is the CDL7100-HBSC-HD; our holdback mode explainer covers what it does.
Full Specifications
Dimensions
Manufacturer dimensional drawing for the Carbine CDL7200LL-HD. Overall height 191mm, body width 48mm (59mm total with lever), lever projection 132mm. Backset 60mm standard. Door thickness 32-54mm.
Not sure of your backset? Our backset measuring guide shows how to check it in under a minute, and the Buyers Guide's door measuring chapter covers thickness, handing, and everything else worth checking before ordering.
Fire Rating - When and How It Applies
Unlike the dual-keypad KDSC, this single-keypad model is suitable for fire and egress doors: the internal lever always operates freely, so occupants can exit without a code - the single-action egress that fire-rated doors require. It achieves FRL -/120/30 with the supplied 60mm tubular latchset on a tested Firecore or E-Core doorset.
Two conditions matter. First, the fire rating applies only with the supplied latchset on a genuinely tested doorset - all other assembly hardware (closer, hinges, seals) must be independently fire rated too. Second, the certification is doorset-specific: Warringtonfire assess the CDL7100 and CDL7200 at -/120/30, 60mm backset, on E-core doorsets in report FAS220275 (Table 10, page 14) and on Firecore doorsets in report FAS220387 (Table 9, page 10) - and the two are not interchangeable across core types.
Our guide to reading fire certification documents explains how to match a report to your actual door, the Buyers Guide's fire door core types chapter covers what E-core and Firecore mean, and our apartment fire door compliance guide explains FRL ratings and what certifiers look for. You can browse everything we carry for those doors in the Fire Door category. As always, confirm the full doorset with your certifier before specifying.
Frequently Asked Questions
Yes - with the supplied latchset on a tested Firecore or E-Core doorset, achieving FRL -/120/30. Because the internal lever always operates freely, exit is single-action with no code, which is what fire and egress doors require. All other assembly hardware must also be fire rated. See Fire Rating above for the certification detail.
With no valid code entered, the external lever rotates freely without moving the latch. After a correct code, the lever engages the latch for one operation, letting the door open. The internal lever always drives the latch regardless of code state, so you can always get out.
It has a deliberate security break point - it shears off if excessive pull or torque is applied, so it can't be used to force the lock. On a heavy door needing real pull force, fit a separate pull handle rated for the job, or choose the knob-external CDL7100SC-HD instead.
Yes - the CDL7200LL-KDSC-HD adds a keypad to the internal face, so a code is required from both sides. Note the trade-off: because it needs a code to exit, that model cannot go on fire or egress doors - this single-keypad model is the one for those.
Yes. Order item code CDL720070LLSCHD for the 70mm version; the standard is 60mm (CDL7200LLSCHD). If you are not sure what your door needs, our backset measuring guide takes a minute.
Additional Information
External lever and pull force: The security break point is a safety and anti-tamper feature, not a defect. On heavy doors - external gates, heavy fire doors, doors with strong closers - calculate the pull force required to open the door before specifying this model. If a pull handle is needed, install a separate one; the CDL7100SC-HD (knob external) is the alternative where a pull handle is not wanted.
Fire door installations: Fire rating applies only with the supplied 60mm tubular latch on a tested Firecore or E-Core doorset, and all hardware must be independently rated. Our apartment fire door compliance guide covers what certifiers check.
Code change before installation: The factory default C13579 must be changed and tested before fitting - test with the door open. Carbine recommend 4-5 digit codes for higher security. Our code change guide's test-five-times rule exists for exactly this moment.
Retrofitting older locks: The 59mm body width covers the fixing holes of NK2000 and Lockwood 530 installations, so most swaps need no door patching. Where an older lock left larger scarring, the CDL72 edge plate (PDF) covers the door edge. Our guide to retrofit kits and spare parts covers why serviceable hardware matters over a lock's life.
Salt spray rating context: The 240-hour C7 rating is a laboratory result. Real-world coastal performance depends on site exposure, wind direction, proximity to water, and local conditions. Finish degradation is excluded from warranty regardless of corrosion rating - a regular freshwater wipe-down keeps the satin chrome presentable; the mechanism itself stays covered for the full 10 years.
Warranty
Carbine is a Davcor Group brand, and Davcor backs its mechanical digital locks with one of the longest warranties in the category: 10 years against defects in materials and workmanship from the date of original purchase. There are no electronics or batteries in this lock to shorten the cover - the whole product is warranted for the full term.
On a valid claim, Davcor will repair the lock, replace it, or supply an equivalent product. Keep your proof of purchase, and make the claim as soon as a defect becomes apparent.
What the warranty does not cover: fair wear and tear; damage caused by faulty installation, misuse, or modification of the product; and tarnishing or change to the finish from weather, salt, or chemical exposure. On coastal and exposed sites, regular cleaning of the finish is the practical answer - the lock mechanism itself remains covered.
Our goods come with guarantees that cannot be excluded under the Australian Consumer Law. You are entitled to a replacement or refund for a major failure and compensation for any other reasonably foreseeable loss or damage. You are also entitled to have the goods repaired or replaced if the goods fail to be of acceptable quality and the failure does not amount to a major failure.
Purchased through Terry's Locksmiths? Contact us first - we'll manage your warranty claim with Davcor on your behalf. Full terms: davcor.com.au/warranty
Download PDF Resources
- Carbine CDL7100/CDL7200 - Installation Instructions
- Carbine CDL7100/CDL7200 - Spec Sheet
- Warringtonfire Fire Assessment FAS220275 - E-Core Doorsets (CDL7200 at Table 10, page 14)
- Warringtonfire Assessment FAS220387 - Firecore Doorsets (CDL7200 at Table 9, page 10)
- Carbine CDL72 Edge Plate - Spec Sheet
- Carbine Salt Spray Testing Information
- Carbine CDL7 Lock Series - Brochure
- Carbine Gate Guard for CDL7 - Specification Sheet
- Carbine Gate Guard for CDL7 - Installation Instructions
Carbine CDL7200LL-HD - Deeper Questions
Yes. The single keypad sits on the outside only; the inside lever always operates freely, so occupants exit with a single action and no code - which is precisely what a fire or egress door requires. The dual-keypad CDL7200LL-KDSC-HD needs a code to exit, so it cannot go on those doors even though the lock body carries the same assessment. Fire rating here is -/120/30 with the supplied latchset on a tested Firecore or E-Core doorset.
The code lives in mechanical slide switches behind the external pad, so it can only be read or reset with the lock accessible - normally with the door open. Since the inside lever is always free, you can still get out; getting back in without the code is a locksmith visit. Record the code somewhere secure the day it is set.
The rear slider switches let you re-code without disassembling the lock body, which is quicker than the fully-stripped procedure on some brands. Comfortable with tools, it is a routine job; first time through, allow longer and follow the figures in the installation instructions (PDF). Our code change guide gives realistic timings across brands.
A competent DIYer with the right tools can: the instructions call for a chisel, a 25mm spade bit, a 10mm drill bit, and a Phillips head screwdriver, and the box includes the drilling template. The bevelled latch bolt must face the direction the door shuts - the instructions (PDF) diagram it. Important: if the door is a fire door, installation must not compromise the fire-rated doorset - that is a job for a competent installer. We install across the Gold Coast; the Installation Gallery tab shows our work.
In most cases, cleanly - the 59mm body covers the standard fixing holes both leave behind. Check your backset first (how to measure) and choose the 60mm or 70mm item code to match. If the old install left wider scarring, the CDL72 edge plate tidies the door edge.
No - this is a pure keypad lock, PIN entry outside and a free lever inside, no key cylinder. No keys to cut, lose, or control; the discipline is guarding the code. If your application genuinely needs a key path, talk to us before ordering.
Yes - several of the installs in our gallery are pool gates. Two rules: the external lever's break point means it must not be pulled hard (fit a pull handle on a heavy or spring-loaded gate), and the pool barrier must still self-close and self-latch to meet barrier requirements. The pool gate section of our latch vs bolt guide covers this properly.
The lock is reversible for left and right hand doors - the handles are handed during installation per the figures in the installation instructions (PDF). Check your door's handing first; the Buyers Guide's handing explainer shows how.
All three are quality mechanical digital platforms with different strengths - Lockwood's DX range converts existing mortice locks, Borg leads on marine-grade finishes and on-door code changing, and the Carbine CDL7 HD is the heavy duty commercial pick with its stainless internals and dual-lever accessibility. Our Lockwood vs Borg vs Carbine comparison puts them side by side, and the Buyers Guide's three-brand chapter goes deeper.
What's in the Box
- 1 x CDL7200LL-HD front body lock assembly (external lever and keypad)
- 1 x interior lever handle assembly
- 1 x 60mm tubular latch assembly
- 1 x notched tailbar
- 1 x fitting plate
- 1 x strike box and strike plate
- 1 x latch support post
- 2 x gaskets (front and rear)
- 2 x 25mm M5-M5 hex lugs
- 2 x 30mm M5 screws and 2 x 40mm M5 screws
- 4 x 8G x 25mm wood screws
- 1 x Allen key
- 1 x installation template and instruction manual
Carbine CDL7200LL-HD Mechanical Digital Lock - Real Installations
Dimensions
Manufacturer dimensional drawing for the Carbine CDL7200LL-HD. Overall height 191mm, body width 48mm (59mm total with lever), lever projection 132mm. Backset 60mm standard. Door thickness 32-54mm.
Carbine CDL7 Lock Series Brochure
Download the Carbine CDL7 Lock Series Brochure (PDF) - the CDL7100, CDL7100-HD, CDL7200, and NK2000 model spread is on page 2.
PDF Resources
- Carbine CDL7100/CDL7200 - Installation Instructions
- Carbine CDL7100/CDL7200 - Spec Sheet
- Warringtonfire Fire Assessment FAS220275 - E-Core Doorsets
- Warringtonfire Assessment FAS220387 - Firecore Doorsets
- Carbine CDL72 Edge Plate - Spec Sheet
- Carbine Salt Spray Testing Information
- Carbine CDL7 Lock Series - Brochure
- Carbine Gate Guard for CDL7 - Specification Sheet
- Carbine Gate Guard for CDL7 - Installation Instructions
