Lockwood 8816LSS Code Handle Keyless Entry Lockset - Left Hand - Satin Stainless Steel
The Lockwood 8816LSS Code Handle is a keyless entry lockset with an integrated keypad built into the lever handle. It provides simple, key-free access using a programmable PIN code, so authorised users can enter without carrying a key. This is the left-hand version of the Code Handle, finished in satin stainless steel.
The Code Handle is a standalone, battery-powered lockset. It has no app, Wi-Fi, or Bluetooth connection - all programming is done at the lock itself. Up to nine user codes can be set, each four to six digits long, alongside a separate administration code for managing the lock. It is designed as a straightforward retrofit that replaces an existing door handle on doors already prepared with a standard 54mm lock hole.
Lockwood is an ASSA ABLOY brand and one of Australia's most recognised names in door hardware. The Code Handle suits internal applications such as offices, store rooms, and home study doors where convenient code access is wanted without the cost or complexity of a fully connected smart lock. For background on how a code lock differs from a connected smart lock, see Chapter 01 - Smart vs Connected in the Smart Lock Buyer's Guide.
This is the left-hand Code Handle (8816LSS). The Code Handle's handing is fixed and is not field-reversible - the correct hand must be ordered for your door. The right-hand version is the Lockwood 8816RSS Code Handle - Right Hand. If you are unsure which hand you need, see Understanding Door Handing in Australia - How to Determine Handing and Chapter 02 - Measuring Your Door (Handing). Ordering the wrong hand is a common and avoidable mistake - see what happens if you order the wrong handing.
Key Features
- Lever handle with an integrated keypad code lock for keyless entry.
- Programmable: up to nine user codes, each four to six digits long.
- Separate administration code for setting lock operation and managing user codes.
- Manual or automatic locking, plus a passage mode that leaves the door unlocked for free access.
- Code lockout activates after five incorrect attempts.
- Supplied with a Lockwood 530 60mm tubular deadlatch (brass, 13mm projection).
- Designed as a retrofit - replaces an existing door handle on doors with a standard 54mm lock hole.
- Durable stainless steel handles in a satin stainless steel finish.
- Available in right-hand and left-hand versions to suit different door configurations.
- Recommended for indoor use only.
Access Methods
For a plain-English comparison of PIN code entry against other credential types, see Chapter 03 - Access Methods (PIN).
What's in the Box
- 1 x Code Handle keyless lever set (exterior keypad lever and interior lever), left-hand
- 1 x Lockwood 530 60mm tubular deadlatch
- AA batteries (included)
- Fixing screws
- Fitting instructions
Suitable Uses
- Internal office doors requiring keyless code access
- Store rooms and back-of-house doors
- Home study or home office doors
- Doors that need to switch between free daytime access (passage mode) and locked at night
- Retrofit onto existing internal doors already prepared with a 54mm lock hole
The Code Handle is recommended for indoor use only. It is not weather-sealed and is not suitable for external entry doors, gates, or openings exposed to rain, salt air, or direct sun. For an external or weather-exposed door, choose a weather-rated lockset instead.
Available Finish Options
Satin Stainless Steel
(This Product)
STK 8816LSS
Finish selection does not affect functionality, compliance, or performance.
Code Handle Range - Item Codes
Full Specifications
Dimensions
Battery, Power & Backup Access
- Powered by AA batteries, included with the lockset.
- Rated for approximately 30,000 operations before the batteries need replacing.
- An audible indicator confirms operation at the keypad.
- The Code Handle is keyless and has no mechanical key override - keep fresh batteries on hand and replace them when signalled so you are not locked out.
Frequently Asked Questions
No. It is a standalone electronic keypad lockset with no app, Wi-Fi, or Bluetooth. All programming is done at the lock, and access is by PIN code only. If you want app control, remote access, or card and fingerprint credentials, this is not the right product - see Chapter 01 - Smart vs Connected and Chapter 03 - Access Methods.
The Code Handle's handing is fixed and cannot be reversed in the field, so you must order the correct hand for your door. This listing is the left-hand version (8816LSS); the right-hand version is the Lockwood 8816RSS Code Handle - Right Hand. For help determining your door's hand, see which products require handing and Chapter 02 - Measuring Your Door.
Yes. The Code Handle runs on AA batteries (included) and is rated for roughly 30,000 operations before replacement. Because it is keyless with no key override, replace the batteries as soon as they are signalled as low so you are not locked out.
No. Lockwood recommends the Code Handle for indoor use only. It is not weather-sealed and is not suitable for external entry doors, gates, or openings exposed to the weather. For an external or exposed door, choose a weather-rated lockset instead.
The lockset is supplied with a Lockwood 530 60mm tubular deadlatch (brass, 13mm projection). A 70mm backset latch (item code 8823-70) is available separately for deeper door preparations. For guidance on backset, see Chapter 02 - Backset and Measuring Your Lock Backset - Standard Sizes.
Additional Information
The Code Handle stores up to nine user codes of four to six digits each, plus a separate administration code used to set lock operation and manage user codes. After five incorrect code attempts, the keypad locks out temporarily to deter guessing. Choose codes that are not easily guessed and update them when staff or occupants change. For where PIN entry sits among access methods, see Chapter 03 - Access Methods (PIN).
The Code Handle is designed to replace an existing door handle. It fits the majority of doors already prepared with a standard 54mm lock hole and a 25mm latch hole, and fitting instructions are included in the box. Confirm your door's backset (60mm supplied, 70mm latch available), thickness (32-55mm), and hand before ordering. See Chapter 02 - Door Thickness for measuring guidance.
The Code Handle can be set to lock manually or automatically, and it offers a passage mode that leaves the door unlocked for free access - useful for doors that need to stay open during the day and locked at night. This flexibility suits offices, store rooms, and studies where access requirements change through the day.
If you want RFID card access, fire-door certification, or DDA compliance on the same Lockwood 530 latch platform, consider the Lockwood Cortex CTX530 digital lockset, which adds a card reader, a fire rating, and DDA-compliant hardware alongside keypad entry.
Lockwood is an ASSA ABLOY brand and one of the most recognised door hardware names in Australia. For a broader look at how Lockwood sits among the brands we stock, see Chapter 10 - Brand Profiles (Lockwood).
Lockwood branded products purchased new in Australia from authorised resellers are covered against defects in materials and workmanship as follows:
- Mechanical components: 25 years — covers mechanical components and workmanship under normal use and correct installation.
- Electronic & electrical components: 3 years (PADDE & electric mortice locks 5 years; batteries excluded).
- Keys: 12 months.
- Finish: varies by finish type and exposure — Everbrass 25 years; Stainless / Chrome / Anodised 10 years; PVD / VIVID 10 years; Symmetry range 5 years; decorative finishes such as bronze, antique and powdercoat 2 years (natural brass ageing excluded).
What's in the Box - Lockwood 8816LSS Code Handle
- 1 x Code Handle keyless lever set (exterior keypad lever and interior lever), left-hand
- 1 x Lockwood 530 60mm tubular deadlatch
- AA batteries (included)
- Fixing screws
- Fitting instructions
Lockwood 8816 Code Handle - Dimensions
Lockwood Code Handle - Product Brochure
Lockwood Warranty Overview
Lockwood branded products are covered by manufacturer warranties issued by ASSA ABLOY Australia Pty Ltd. Warranty periods vary depending on product type, mechanical components, electrical elements, and finish category.
This overview summarises the structure of Lockwood warranty coverage. Full terms, exclusions and claim procedures are set out in the official Lockwood Warranty document.
Warranty Periods Summary
Finish Coverage Guide
- Everbrass finishes: up to 25 years against corrosion, tarnishing and discolouration.
- Stainless steel, polished stainless steel, chrome plating and anodised finishes: typically up to 10 years.
- Decorative finishes including Antique Copper, Architectural Bronze, Oil Rubbed Bronze, Aged Brass, Polished Brass, Satin Brass and related variants: typically up to 2 years against corrosion.
- Unlacquered brass finishes will naturally age and change appearance over time. This is not considered a defect.
- Tea staining of stainless steel is not covered where cleaning and maintenance have not been followed.
What the Warranty Covers
- Defects in material and workmanship during the applicable warranty period.
- Assessment by ASSA ABLOY to determine repair, replacement with the same or closest equivalent product, or refund of purchase price.
Common Exclusions
- Normal wear and tear.
- Misuse, abuse, accidental damage or use outside published specifications.
- Improper maintenance or failure to follow care instructions.
- Unauthorised modification, repair or use of non-genuine parts.
- Exposure to corrosive environments including coastal air, salt spray, chemicals or pollution.
- Removal, refitment or associated labour charges.
- Products not originally sold in Australia through authorised channels.
Warranty Claim Process
- Retain proof of original purchase.
- Return the product through the original place of purchase where applicable.
- If claiming directly, obtain a case number before returning goods.
- Products must be securely packed and clearly identified.
- Warranty assessment determines repair, replacement or refund.
Australian Consumer Law
Lockwood warranties operate in addition to rights available under the Australian Consumer Law. Goods come with guarantees that cannot be excluded. Customers may be entitled to a replacement or refund for a major failure and compensation for reasonably foreseeable loss or damage.
Where a product fails to meet acceptable quality standards and the failure does not amount to a major failure, the customer is entitled to repair or replacement.
Official Warranty Document
