dormakaba RB111 Heavy Duty Roller Bolt - Stainless Steel - Fire Rated
The dormakaba RB111 Heavy Duty Roller Bolt (BORB111SC) is a secondary latching device for commercial and residential doors. It pairs a stainless steel roller with a satin chrome pearl housing, and a fully adjustable strike position lets it cope with varying door-to-frame gaps on both timber and aluminium doors and frames.
The RB111 is fire rated to AS1530 Part 4 as a secondary latching device. It holds the door closed alongside a separately fire-rated primary lock such as the dormakaba MS2602 Primary Mortice Lock, and it is a common companion to the dormakaba M5 BLE smart lock on fire door installs.
Estimated Dispatch
Usually ships same day if ordered before 11am AEST (excludes weekends and Queensland public holidays).
Usually ships same day if ordered before 11am AEST (excludes weekends and Queensland public holidays).
Fire Rated - AS1530 Part 4 - Secondary Latching Device
The RB111 is fire rated in accordance with AS1530 Part 4 for use as a secondary latching device. On a fire door it always works alongside a separately fire-rated primary mortice lock, which carries the primary lock requirement of the doorset. The rating applies within a certified fire door assembly - see how lock fire testing works and the one-penetration principle before adding hardware to an existing fire door.
The RB111 is fire rated in accordance with AS1530 Part 4 for use as a secondary latching device. On a fire door it always works alongside a separately fire-rated primary mortice lock, which carries the primary lock requirement of the doorset. The rating applies within a certified fire door assembly - see how lock fire testing works and the one-penetration principle before adding hardware to an existing fire door.
Key Features
- Fully adjustable strike position to suit varying door-to-frame gaps.
- Heavy duty stainless steel roller for long-term mechanical durability.
- Satin chrome pearl faceplate and housing finish.
- Stainless steel strike plate included (69 x 28mm, 47mm lip).
- Suits timber and aluminium doors and frames.
- Fire rated to AS1530 Part 4 as a secondary latching device - pairs with fire-rated primary locks such as the MS2602.
- Compact profile - 86.2mm body length, 26mm faceplate width, 40.8mm depth.
What's in the Box
- 1 x RB111 roller bolt body (stainless steel roller, satin chrome pearl housing)
- 1 x Stainless steel strike plate (69 x 28mm, lip 47mm)
Suitable Uses
- Secondary latching device on fire-rated door assemblies where a fire-rated primary lock is also installed - browse our fire door smart locks.
- Timber and aluminium commercial doors requiring a supplementary catch.
- Doors where the door gap varies and a fixed-strike roller bolt would not engage reliably.
- Internal and cupboard doors requiring a light latching action without a key-operated lock.
- Fire door smart lock installations that need a secondary latch - for example alongside the dormakaba M5 BLE Smart Lock and MS2602 mortice lock.
Not Suitable For
Use on its own as the only hardware on a door - the RB111 must always be paired with a primary lock, including on fire doors. Doors that need resistance to forced entry - a roller bolt holds the door by spring pressure only, so fit a key-operated primary lock, or choose a deadlatch where a secondary device must resist back-pressure. DIY additions to a certified apartment fire door - read why fire door hardware is not a DIY job first.
Use on its own as the only hardware on a door - the RB111 must always be paired with a primary lock, including on fire doors. Doors that need resistance to forced entry - a roller bolt holds the door by spring pressure only, so fit a key-operated primary lock, or choose a deadlatch where a secondary device must resist back-pressure. DIY additions to a certified apartment fire door - read why fire door hardware is not a DIY job first.
Available Finish Options
Satin Chrome Pearl
(This Product)
BORB111SC
Finish selection does not affect functionality, compliance, or performance.
Full Specifications
Dimensions
Replacing an existing roller bolt? Check your existing hardware and the door preparation before ordering.
Manufacturer dimensional drawing for the dormakaba RB111. Key measurements: body length 86.2mm, housing height 22.25mm, depth 40.8mm, faceplate 72.8 x 26 x 4mm.
Frequently Asked Questions
What does "fire rated as a secondary latching device" mean?
A fire door assembly needs a primary lock, and many also carry a secondary latch. The RB111 has been tested to AS1530 Part 4 in the secondary latch role - it helps hold the door closed during a fire alongside a separately certified primary lock. It cannot be the only latching or locking device on a fire door: a fire-rated primary mortice lock such as the dormakaba MS2602 must also be fitted. Our article on primary and secondary locks explains the rules.
A fire door assembly needs a primary lock, and many also carry a secondary latch. The RB111 has been tested to AS1530 Part 4 in the secondary latch role - it helps hold the door closed during a fire alongside a separately certified primary lock. It cannot be the only latching or locking device on a fire door: a fire-rated primary mortice lock such as the dormakaba MS2602 must also be fitted. Our article on primary and secondary locks explains the rules.
How does the adjustment work?
The strike plate fixing slots are elongated, so the strike can sit closer to or further from the door edge to suit the gap on site. If the gap is too wide the roller will not compress and engage the strike; too narrow and the door will not close fully. Set the strike depth during installation before fixing - door misalignment is the usual reason a roller or latch will not catch.
The strike plate fixing slots are elongated, so the strike can sit closer to or further from the door edge to suit the gap on site. If the gap is too wide the roller will not compress and engage the strike; too narrow and the door will not close fully. Set the strike depth during installation before fixing - door misalignment is the usual reason a roller or latch will not catch.
Does this roller bolt provide any security against forced entry?
No. A roller bolt is a passive spring-loaded catch - it holds the door closed by spring tension against the strike, but gives no resistance to someone deliberately pushing or pulling the door open. Fit it alongside a key-operated primary lock on any door that needs security.
No. A roller bolt is a passive spring-loaded catch - it holds the door closed by spring tension against the strike, but gives no resistance to someone deliberately pushing or pulling the door open. Fit it alongside a key-operated primary lock on any door that needs security.
Can this be installed on aluminium door frames?
Yes. The RB111 suits both timber and aluminium doors and frames. On aluminium frames use self-tapping screws rated for the frame material, and if in doubt ask your frame manufacturer or talk to us about installation.
Yes. The RB111 suits both timber and aluminium doors and frames. On aluminium frames use self-tapping screws rated for the frame material, and if in doubt ask your frame manufacturer or talk to us about installation.
Is this roller bolt compatible with smart lock installations on fire doors?
Yes, provided the smart lock and the RB111 are both fire rated and the overall door assembly is certified. The smart lock provides the primary locking function and the RB111 the secondary latch - the dormakaba M5 BLE on an MS2602 mortice is a typical pairing. Adding hardware to a certified fire door can affect its certification, so confirm with your fire door specialist first. See Chapter 05 - Fire Door Smart Locks.
Yes, provided the smart lock and the RB111 are both fire rated and the overall door assembly is certified. The smart lock provides the primary locking function and the RB111 the secondary latch - the dormakaba M5 BLE on an MS2602 mortice is a typical pairing. Adding hardware to a certified fire door can affect its certification, so confirm with your fire door specialist first. See Chapter 05 - Fire Door Smart Locks.
Additional Information
Secondary latching device - fire door specification
On certified fire doors the one-penetration principle generally allows only one lock body penetration under the fire test certification. Adding a secondary device outside the terms of the certified doorset may affect compliance, so confirm with the door manufacturer or a fire door specialist before fitting the RB111 to an existing fire door. Secondary locks and the one-penetration principle covers what is and is not permitted, and how to identify a fire door helps if you are unsure what you have.
On certified fire doors the one-penetration principle generally allows only one lock body penetration under the fire test certification. Adding a secondary device outside the terms of the certified doorset may affect compliance, so confirm with the door manufacturer or a fire door specialist before fitting the RB111 to an existing fire door. Secondary locks and the one-penetration principle covers what is and is not permitted, and how to identify a fire door helps if you are unsure what you have.
Roller bolt vs deadlatch - choosing the right secondary device
A roller bolt holds the door closed by spring pressure alone - the roller compresses as the door closes and springs into the strike, with no deadlocking action. A deadlatch has an automatic deadlocking latch bolt that resists back-pressure. For external doors, or anywhere forced-entry resistance matters, a deadlatch is the better secondary device. The RB111 suits internal doors, controlled-access commercial doors and fire door assemblies where the primary lock provides the security. Latch vs bolt explains the difference.
A roller bolt holds the door closed by spring pressure alone - the roller compresses as the door closes and springs into the strike, with no deadlocking action. A deadlatch has an automatic deadlocking latch bolt that resists back-pressure. For external doors, or anywhere forced-entry resistance matters, a deadlatch is the better secondary device. The RB111 suits internal doors, controlled-access commercial doors and fire door assemblies where the primary lock provides the security. Latch vs bolt explains the difference.
Fire rating standards and certification
The RB111 is certified to AS1530 Part 4, the Australian standard for fire-resistance testing of building elements. Fire doorsets themselves are certified under AS1905 Part 1 - Chapter 11 explains that standard in plain English, and our fire rating certificates reference page covers test reports.
The RB111 is certified to AS1530 Part 4, the Australian standard for fire-resistance testing of building elements. Fire doorsets themselves are certified under AS1905 Part 1 - Chapter 11 explains that standard in plain English, and our fire rating certificates reference page covers test reports.
Other roller bolts in the range
For cupboards, pivot doors and light-duty internal doors the dormakaba 2520 roller bolt (nylon roller, adjustable holding force) is a lighter alternative, and the Lockwood 7580 roller bolt in matt black suits darker hardware schemes. Compare them in roller bolts for smart locks or browse all smart lock accessories.
For cupboards, pivot doors and light-duty internal doors the dormakaba 2520 roller bolt (nylon roller, adjustable holding force) is a lighter alternative, and the Lockwood 7580 roller bolt in matt black suits darker hardware schemes. Compare them in roller bolts for smart locks or browse all smart lock accessories.
Fitting on fire doors and commercial sites
Fire door and strata work should go to a licensed installer who can confirm the doorset certification before any hardware is added. When DIY makes sense covers simpler internal doors, and we can book a site survey for commercial and apartment installs.
Fire door and strata work should go to a licensed installer who can confirm the doorset certification before any hardware is added. When DIY makes sense covers simpler internal doors, and we can book a site survey for commercial and apartment installs.
Warranty
Warranty
10-year mechanical warranty - electronic components on digital door locks and electric locks are covered for 1 year from date of purchase. Backed by the Australian Consumer Law. Proof of purchase required for all claims. Returns & Warranty | dormakaba Warranty Terms | Warranty PDF
10-year mechanical warranty - electronic components on digital door locks and electric locks are covered for 1 year from date of purchase. Backed by the Australian Consumer Law. Proof of purchase required for all claims. Returns & Warranty | dormakaba Warranty Terms | Warranty PDF
dormakaba RB111 - Dimensions
Manufacturer dimensional drawing for the dormakaba RB111. Key measurements: body length 86.2mm, housing height 22.25mm, depth 40.8mm, faceplate length 72.8mm, faceplate width 26mm, faceplate thickness 4mm. Strike plate: 69 x 28mm, lip 47mm (stainless steel, included).
