McGrath NX1 Digital Smart Lock

At A Glance

At A Glance

DISPATCHSame Day Before 11am

LOCK TYPETubular Latch or 60/50 Mortice

FINISHMatt Black or Satin Nickel

IN THE BOXLock, Latch or Mortice, Strike, Cylinder + 2 Keys

WARRANTY12 Months

WANT CHEAPER?See YLBL226NR - PIN + Key, No App

WANT HIGHER SPECS?More Expensive - See Vault Guardian Vision

MCGRATH NX FAMILYBrowse NX1 / NX5 / NX6 / NX6W

ACCESS5-in-1 Credential Set

FINGERPRINTUp to 100 Users

PIN CODES250 Codes, 4-8 Digits

RFID1,000 MIFARE Credentials

EKEYSUnlimited via App

KEY OVERRIDECylinder + 2 Keys Supplied

REMOTE ACCESSOptional G3 / G4 / G5 Gateway

POWER4 x AA, 12 Months

EMERGENCY POWERUSB-C Power Bank

DOOR THICKNESS35-55mm

BACKSET60/70mm Latch or 60mm Mortice

HANDINGField Reversible

WEATHERIP65 External Module

DURABILITY100,000 Cycles

PASSAGE MODEFree Entry When You Want It

PRIVACYInterior Privacy Button

PIN SECURITYAnti-Peep + Wrong-Attempt Lockout

ACTIVITY LOGIn-App Audit Trail

DOORBELLPress # at the Keypad

APP PLATFORMMcGrath Locks App (TTLock)

LOCAL SUPPORTManaged in Australia

SPARESCylinders, Blanks, Mortices, Latch

FITMENT OPTIONSLatch or Mortice + Longer-Faceplate Body

UNLOCK WITH

PIN Code Fingerprint RFID Card / Fob McGrath Locks App Mechanical Key Remote (Optional Gateway) Face / Palm
Not Available

The McGrath NX1 is a 5-in-1 digital smart lock for hinged timber and aluminium doors with a standard stile. It sits between the slimline McGrath A210 (narrow stile) and the larger McGrath NX5, giving a balanced 76mm-wide body that forgives an imperfect retrofit without the bulk of an oversized lock - one of the reasons it is the most-installed McGrath model in our own installation work across the Gold Coast. It suits residential entry doors and light-commercial doors alike; browse the wider regular front door and internal door categories for context.

Day-to-day access and lock setup run through the McGrath Locks App over Bluetooth as standard - the McGrath-branded build of the TTLock platform. Entry is by keypad PIN (up to 250 codes), MIFARE RFID card, fob, wristband or sticker (up to 1,000), fingerprint (up to 100), unlimited Bluetooth eKeys, or the mechanical key override - two keys and the cylinder are in the box. Remote unlocking and credential management from anywhere are added later by pairing a G3, G4 or G5 gateway; Bluetooth-only versus gateway explains what changes.

The NX1 ships with your choice of an adjustable 60/70mm tubular latch or a 60/50 Mortice Lock, so it can be matched to the door prep in front of you. It suits doors 35-55mm thick and the handing is reversed in the field with an allen key. Where door thickness, backset or stile width is in question, work through Measuring Your Door (Chapter 02) and how to measure your backset before ordering.

Estimated Dispatch
Usually ships same day if ordered before 11am AEST (excludes weekends and Queensland public holidays).

Key Features

• 5-in-1 access - keypad PIN, RFID card or tag, fingerprint, Bluetooth eKey and mechanical key override. Chapter 03 compares the credential types side by side.
• Standard-stile body, 76mm wide - covers more of an existing cut-out than the slimline models, which is what makes it the forgiving retrofit choice on timber and aluminium hinged doors. Check your stile width against the 76mm escutcheon before ordering.
• Latch or mortice - your choice at checkout. Supplied with either the adjustable 60/70mm tubular latch (simplest retrofit) or the 60/50 Mortice Lock for doors with existing mortice hardware. Tubular latch versus mortice latch is explained in Chapter 01.
• Five PIN types - permanent, timed, one-time, custom and recurring codes, up to 250 in the lock, 4-8 digits (minimum 4 when set from the app). See the TTLock passcode types and the 24-hour activation rule every new owner should know.
• Up to 100 fingerprints on the semiconductor reader set into the lever - use the three-angle enrolment technique for reliable reads.
• Up to 1,000 MIFARE RFID credentials (13.56 MHz) - cards, fobs, wristbands and stickers from the RFID credentials range; two tags are in the box.
• Unlimited Bluetooth eKeys - share timed, one-time or permanent app access with family, trades or guests without handing over a code; ideal for short-stay rentals on the TTLock route.
• Bluetooth 5.0 BLE management via the McGrath Locks App; add a G5, G4 or G3 gateway for Wi-Fi remote access - the lock itself has no built-in Wi-Fi, which is a battery-life advantage over the NX6W.
• Passage mode - hold the door unlocked for a meeting room, open day or busy household afternoon, then return it to secure mode from the app or keypad.
• Interior privacy button - the electronic locking switch on the inside unit blocks outside credential entry (bathroom, bedroom, home office) until it is released; only the administrator can override it from outside.
• Anti-peep PIN entry and wrong-attempt lockout - pad a real code with random digits either side so a shoulder-surfer learns nothing; repeated wrong entries lock the keypad for a cooling-off period. Browse security FAQs in Chapter 13.
• Doorbell on the # key - visitors press # at the keypad to chime the interior unit.
• Audit trail in the app - see who unlocked and when, a genuine help for dispute resolution on rentals.
• Field-reversible handing - the levers rotate to suit left or right hand doors with the supplied allen key (front panel 45 then 270 degrees counter-clockwise; back panel 180 degrees). Read field-reversible versus fixed handing and how to determine your handing.
• Durability tested to 100,000 cycles - roughly 27 years at 10 uses a day; what shortens a lock's life is covered in realistic lifespan expectations.
• Zinc alloy body with acrylic touch screen and an 8mm spindle - the standard hub size for Australian mortice and tubular hardware.
• IP65 rated external module (outside face only) for sheltered entries. The interior unit houses the battery compartment and is for interior use only - on the coast, read coastal environments and why coastal Queensland is not gentle on electronics.
• USB-C emergency power - wake a flat lock from a phone power bank, or use the mechanical key; what to do when the battery dies walks through it.
• Locally managed platform - the McGrath Locks App is supported and distributed in Australia by LSC, with globally proven TTLock infrastructure underneath; compare it with the alternatives in Chapter 15 and which platform suits a residential home.

Access Methods

Every credential on the NX1 is managed from the McGrath Locks App. Capacities below are from McGrath's current specification sheet; Chapter 03 compares the methods, and every method here has its own store category: PIN code, fingerprint, card and fob, Bluetooth, backup key and Wi-Fi capable smart locks.

Access Method	Availability	Notes
Keypad / PIN Code	Yes	Up to 250 codes, 4-8 digits (minimum 4 via the app). Permanent, timed, one-time, custom and recurring types - see the six passcode types. Anti-peep entry and wrong-attempt lockout.
Fingerprint Recognition	Yes	Up to 100 fingerprints on the semiconductor reader in the lever - getting fingerprints right.
RFID Card / Tag	Yes	Up to 1,000 MIFARE 13.56 MHz credentials: card, fob, wristband or sticker. Two tags included - IC cards and other credentials.
Bluetooth (App Control)	Yes	Bluetooth 5.0 BLE. Local unlock and unlimited eKeys via the McGrath Locks App (Android 4.3 / iOS 7.0 and above).
Wi-Fi Remote Access	Optional	Requires a G3 PoE, G4 4G or G5 dual-band gateway - do you actually need one?
Mechanical Backup Key	Yes	Cylinder and 2 keys supplied; keyed-to-differ and keyed-alike replacement cylinders available. Where the keyhole sits.
Palm Recognition	Not Available	Not supported on this model - see the palm and face recognition range.
Face Recognition	Not Available	Not supported on this model - the Vault Guardian Vision adds face recognition and a video intercom.

What's in the Box

Item (c) on the diagram is the fitment - one of a mortice body or a tubular latch ships with the lock, whichever you choose at checkout. See Fitment Options for the three bodies and their dimensions.

Note: 4 x AA alkaline batteries are not included - Terry's Locksmiths recommends Duracell. A Wi-Fi gateway is sold separately. The full parts diagram is in the NX1 Installation Guide (PDF).

Suitable Uses

• Residential front and side hinged doors on a standard stile, 35-55mm thick, in timber or aluminium - confirm the door type against the door type compatibility matrix in Chapter 04.
• Internal office, bedroom and study doors where the interior privacy button and passage mode earn their keep.
• Light-commercial entry doors wanting 5-in-1 access without an oversized retrofit lock - for staff attendance and commercial platform fit, see the TTLock guides.
• Retrofit upgrades over existing lever or mortice hardware where the 76mm standard-stile body gives some forgiveness over the old cut-out - identify what is on the door now with Chapter 02 - existing hardware, and avoid the three most common DIY installation mistakes.
• Households wanting keyless family access (fingerprint and PIN) with RFID and Bluetooth eKeys for visitors and trades - browse all app-enabled, fingerprint and backup key smart locks.
• Short-stay and rental properties managed on the TTLock route, with a gateway for remote code issue - what a McGrath lock does without Wi-Fi and what changes with a gateway.
• Strata apartments on non-fire-rated entry doors - run the four strata checks first; for a fire door choose the Windsor or Hamilton from the fire door category instead.

Not suitable for: sliding doors, external pedestrian gates, fully exposed weather positions, or fire-rated doors. The IP65 rating covers the external face only - the interior battery unit is not weather sealed. For a gate choose the double-sided McGrath Ascot; for a narrow aluminium stile choose the A210, A231 or A236 from the narrow frame range.

Available Finish Options

•
  Matt Black
  (This Product)
  STK MLNX1
•
  Satin Nickel
  (This Product)
  STK MLNX1

Matt Black and Satin Nickel are both supplied under the one listing (SKU STK MLNX1) - select your finish at checkout. Finish selection does not affect functionality, compliance, or performance. Both finishes appear in the Installation Gallery tabs.

McGrath Hinged-Door Smart Lock Range

Where the NX1 sits in the McGrath range. Every model below runs on the same McGrath Locks App and shares the G3 / G4 / G5 gateways, so a mixed installation (say an NX1 on the front door and an A236 on the aluminium side door) is managed from one app - see gateway interchangeability.

This product (bold row) is the NX1. Comparing standard-stile against slimline? Measure the stile first - the narrow frame category lists every slim option, and the McGrath brand card in Chapter 10 summarises the whole range. Browse everything in the McGrath NX family.

Accessories and Spares

Every confirmed spare, credential and add-on for the NX1, itemised. Cylinders and keys are cut and keyed by Terry's Locksmiths - see the cylinders and barrels, keys and key blanks, mortice locks, tubular latches, rebate kits and strikes, RFID credentials and gateways categories for the wider range.

Choosing a gateway? G2 vs G3 vs G4 vs G5 compared and where to place it settle most questions; what happens when the internet goes down is worth reading before you rely on remote access. Spares not listed here can be sourced through Terry's Locksmiths - see Advice and Installation.

Battery, Power and Backup Access

• Powered by 4 x AA alkaline batteries (not included) - a 6V pack. Fit four fresh cells of the same brand; the installation guide is explicit that old and new cells must never be mixed. Terry's Locksmiths recommends Duracell.
• Battery life is rated at 12 months at around 10 uses per day. Heavy fingerprint use, a stiff latch or a misaligned door will shorten that - the truth about smart-lock battery life and battery management in the TTLock app explain what actually drains a lock.
• Low-battery warnings are given audibly at the lock and in the McGrath Locks App once the pack drops below 4.6V - read how to read a low-battery fault correctly before assuming the lock is faulty.
• USB-C emergency power on the underside of the exterior unit wakes a flat lock from any phone power bank long enough to enter a code or present a card.
• Mechanical key override - the cylinder and two keys are in the box, so the door always opens regardless of battery state. Where the keyhole sits, what to do when the battery dies and where to store the override key are all covered in our key override guide.
• No mains wiring, no hub required for day-to-day use - see how smart locks are powered in Chapter 01 and the power and battery FAQs in Chapter 13.

For a realistic picture of what fails on electronic locks in coastal Queensland - batteries, alignment and salt air rather than electronics - read what actually fails and why electronic locks are not set and forget.

Wi-Fi Remote Access (Optional)

The NX1 has no built-in Wi-Fi. Out of the box it is a Bluetooth lock: you manage it from the McGrath Locks App when your phone is within range, and every PIN, card, fingerprint and eKey works at the door without any internet connection. That is deliberate - it keeps battery life at 12 months and avoids the radio drain that the built-in Wi-Fi NX6W has to manage. What a McGrath lock does without Wi-Fi is worth reading before you decide you need more.

Pair the lock with a McGrath gateway and remote access switches on: unlock the door from anywhere, issue or revoke PINs, cards and eKeys while you are away, receive real-time notifications and read the activity log live. Three gateways suit the NX1 - the G3 PoE / Ethernet for a wired connection, the G4 with 4G SIM for holiday homes without reliable NBN, and the G5 dual-band Wi-Fi for most homes. One gateway serves every McGrath lock within Bluetooth range, so it covers the NX1 plus an Ascot on the gate or an A210 on the side door. G2 vs G3 vs G4 vs G5 compared, choosing the right gateway in Chapter 14 and gateway placement in Chapter 08 cover the decision; if a gateway later drops its connection, band steering is the usual culprit and these fixes resolve most cases. Gateways draw mains power - the 240V dual-USB wall adaptor is the matching supply.

App Platform and Data Hosting

The McGrath Locks mobile app is a customised, McGrath-branded platform tailored specifically for the McGrath Locks product range, available for iOS and Android(Android 4.3 / iOS 7.0 and above). The app is managed, supported and distributed locally by McGrath Locks in Australia. Australian-based support staff handle warranty claims, app troubleshooting and platform queries - you are not dealing with an overseas vendor. The underlying cloud infrastructure is provided by TTLock, a globally deployed IoT platform; the lock is also listed on the TTRenting and TTHotel platforms for property managers. For a plain-English overview of the platform this lock runs on, see the TT Lock Platform Guide (Chapter 14), TTLock in the App Platforms guide, Which Smart Lock Platform Is Right for You and, if you are weighing a hardware-store alternative, why the platform matters more than the brand. Owners get the most from it with TTLock tips, tricks and hidden features.

Long-Term Support and Confidence
McGrath smart locks are backed by long-established industry partners and supported locally. LSC has a century in the security industry, Terry's Locksmiths has 50 years on the front line, and the supply chain behind every McGrath installation means spares, cylinders and support are here in Australia. Read Why Terry's Locksmiths, LSC and McGrath Locks Give Long-Term Confidence and what happens if a manufacturer discontinues the app.

McGrath NX1 - Full Specifications

Figures below are from McGrath's current NX1 Technical Specifications sheet (April 2025) - download it from PDF Downloads below. Where the older 2022 datasheet differs, the current sheet wins.

Dimensions

All dimensions are in millimetres. The drawing shows the front elevation and side profile of the interior and exterior escutcheons and levers.

Escutcheon 234mm high by 76mm wide; overall width to the lever tip 154mm; body depth 25mm exterior and 24mm interior. The drawing labels the handle projection 66.8mm; McGrath's current specification sheet gives 68.8mm - work to 68.8mm. Check backset and door thickness against these figures before ordering; the full-width drawing is in the Dimensions tab. The latch and mortice bodies are dimensioned separately under Fitment Options below.

Fitment Options - Tubular Latch or 60/50 Mortice

Pick your fitment when you order. Choose tubular latch and the adjustable 60/70mm McGrath latch (MLTL6070) comes in the box - that is the one for a bored door with a single round latch bolt. Choose mortice and the 60/50 Mortice Lock with the 147mm faceplate (MLM6050LSS147) comes in the box instead - that is the one for a door cut with a rectangular mortice pocket. Only one of the two is supplied.

One alternative body is stocked: the same 60mm low-spindle mortice with a longer 180mm faceplate (MLM6050LSS180), for a door whose existing cut-out is taller than the 147mm plate will cover. Add it from the Accessories and Spares table; measure the door edge first - how to measure your backset and standard backset sizes in Australia cover it. All three fitments are pictured below, with the two mortice bodies dimensioned against the reference drawing.

What "low spindle" and "high spindle" mean
Not the size of the spindle - both are 8mm square. It is where the spindle hub sits in the mortice case: low down on a low-spindle body, higher up on a high-spindle one. The NX1 takes the low-spindle bodies (MLM6050LSS147 and MLM6050LSS180), because that is where the lever spindle comes through on this lock. The high-spindle body looks near enough identical on the shelf but belongs to the NX5 - fit one to an NX1 and the spindle will not line up with the hub. When you order a spare, check the item code, not just the backset and faceplate.

IN THE BOX WITH THE LATCH OPTION
McGrath Adjustable 60/70mm Tubular Latch - Satin Stainless
MLTL6070
Adjusts between a 60mm and 70mm backset. The fitment for a bored (cylindrical) door - a single round latch bolt through the door edge.

IN THE BOX WITH THE MORTICE OPTION
McGrath 60/50 Mortice Lock - 8mm Low Spindle - 147mm Faceplate
MLM6050LSS147
60mm backset, SS304 body, 147mm faceplate. Supplied with the lock when you choose the mortice fitment - fits a standard mortice pocket.

OPTIONAL - ADD TO CART
McGrath 60/50 Mortice Lock - 8mm Low Spindle - 180mm Faceplate
MLM6050LSS180
The same 60mm low-spindle body with a longer 180mm faceplate - covers a taller cut-out left by an older mortice lock.

Mortice Dimensions - A to G as marked on the reference drawing

Reference drawing for the table below: A body depth, B backset, C body height, D pitch (spindle centre to cylinder centre), E faceplate height, F faceplate width, G body width. It is a generic mortice outline for reading the letters, not a scale drawing of either body - the figures in the table are the ones to work from. The tubular latch is not dimensioned here; it adjusts between a 60mm and 70mm backset.

Frequently Asked Questions

Will the NX1 fit my door?
It suits standard-stile timber and aluminium hinged doors from 35mm to 55mm thick, with either the adjustable 60/70mm tubular latch or the 60/50 Mortice Lock. Measure three things first - door thickness, backset and stile width (the escutcheon is 76mm wide). Measuring your lock backset and the door type compatibility matrix settle most fit questions; for a narrow aluminium stile move to the A210 or A231.

Does the NX1 have built-in Wi-Fi?
No. Bluetooth is standard for local app control, and every credential works at the door without internet. Remote unlocking, remote code issue and live notifications need a G3, G4 or G5 gateway, sold separately. Do you actually need a gateway? is the honest starting point, and what happens when the internet goes down explains why the lock keeps working either way.

How many fingerprints, PINs and cards can it store?
Up to 100 fingerprints, 250 PIN codes of 4-8 digits, 1,000 MIFARE RFID credentials and unlimited Bluetooth eKeys, all managed from the McGrath Locks App. PINs can be permanent, timed, one-time, custom or recurring - the passcode types - and new permanent codes obey the 24-hour activation rule. Chapter 03 compares the credential types.

What happens if the batteries go flat?
You get audible warnings at the lock and alerts in the app once the pack drops below 4.6V, well before it dies. If it does go flat, touch a phone power bank to the USB-C port under the exterior unit to wake the lock, or use one of the two supplied mechanical keys. What to do when the battery dies and where to keep the override key cover planning for it.

My NX1 will not lock after installation - what is wrong?
Almost always installation, not a fault. Straight out of the box the NX1 sits in an always-open state - the handle is free and the lock will not secure - until batteries are fitted and an administrator is set in the app, at which point it switches to secure mode automatically. If it still will not lock, check spindle and hub position, backset and door alignment: Smart Lock Not Locking? 3 Common DIY Mistakes uses the NX1 as its worked example, and Chapter 12 troubleshooting maps symptom to fix. Still stuck? Advice and Installation or a free site survey.

Additional Information

Set the lock up with the app first. The NX1 is designed to be commissioned from the McGrath Locks App - add the lock, set yourself as administrator and it leaves factory default open state. The keypad still works day to day without a phone nearby, but full functionality (eKeys, timed codes, the activity log, gateway pairing) only exists through the app. Transferring or re-adding a lock matters at a property handover.

Latch or mortice - choose to match the door prep. The adjustable 60/70mm tubular latch is the simplest retrofit over a bored cylindrical door; the 60/50 Mortice Lock suits a door with an existing mortice pocket, with a 180mm faceplate version to cover a larger old cut-out and a rebate kit for rebated door pairs. Bored versus mortice door prep and the wrong-backset mistake explain the choice.

Handing is reversed in the field. Both levers rotate to suit a left or right hand door with the supplied allen key - the exterior lever turns 45 degrees, the grub screw comes out, the lever rotates 270 degrees counter-clockwise and the screw goes back in the other side; the interior lever simply rotates 180 degrees. The procedure is on page 4 of the Installation Guide (PDF). How to determine your door's handing comes first.

Distributed by LSC, supported by Terry's. The NX1 is a McGrath-branded lock on the TTLock platform, managed locally in Australia, distributed through LSC and installed and supported by Terry's Locksmiths - see the installer's perspective and warranty as a confidence signal. Comparing standard-stile against slimline? The A210 is the narrow-stile option and the NX5 the larger-bodied retrofit.

A note on the app's vibration alert toggle. The TTLock app exposes an alert toggle that the NX1 hardware does not support; if it is switched on it produces phantom notifications. Leave it disabled - background in why McGrath locks do not support it and the three-step how to turn it off.

Warranty

Warranty
12-month warranty against defects in materials and workmanship (24-month on ALBION, ASCOT, ASHGROVE, BARDON, GRANGE, HAMILTON, KEDRON, MANLY, SANDGATE, STAFFORD, ULTRA SECUA and WINDSOR models). McGrath Locks will repair, replace, or refund at their discretion. Proof of purchase required for all claims. Returns & Warranty | McGrath Locks Warranty

This warranty sits alongside your rights under Australian Consumer Law. Claims are lodged through Terry's Tradies Pty Ltd as the place of purchase - see the Returns and Warranty page for current claim steps, and warranty as a confidence signal for why the local claim path matters.

Download PDF Resources

NX1 Technical Specifications (PDF)
McGrath's current 2-page specification sheet (April 2025) - the authoritative source for every figure on this page: hardware, door thickness, capacities, battery, environment, IP class and warranty.

NX1 Installation Guide (PDF)
4-page installer sheet: safety and general-usage notes, centre-line marking and handing chart, accessory kit and installation steps 1-8, reset button location and the handle-reversal procedure.

NX1 Technical Datasheet (PDF)
9-page 2022 McGrath datasheet with product photography, the dimension drawing, mortice options, installation steps and feature overview. Its specification tables predate the current sheet - use the Technical Specifications above for figures.

NX1 Product Brochure (PDF)
One-page overview of the NX1 - unlock methods, timed passwords, passage mode, privacy button and McGrath range copy.

TT Lock App User Manual (PDF)
56-page platform manual for the app the McGrath Locks App is built on: registration, adding a lock, passcode types, eKeys, card and fingerprint management, attendance and gateway setup.
