BORG Mechanical Digital Cam Lock For Cabinet Door With Easicode Pro - Satin Chrome

Borg BL1006SCECP Mechanical Digital Cam Lock for Cabinet Doors - Easicode Pro - Satin Chrome

At A Glance

At A Glance

DISPATCHSame Day Before 11am

LOCK TYPEMechanical Digital Cam Lock

FINISHSatin Chrome

IN THE BOXLock + 2 Cams + Fixings

WARRANTY12 Months

ACCESSPIN Code Only

KEY OVERRIDENone - See BL1706

CODE CHANGEEasicode Pro - On the Door

COMBINATIONSOver 500

CODES STOREDSingle PIN Code

CODE RECOVERYRead at the Code Cover Plate

DOOR THICKNESSUp to 25mm

HANDINGNon-Handed

FOOTPRINT41mm Wide x 110mm High

SUITABLE FORLockers, Cabinets, Cupboards

WEATHERInternal Use Only

NOT HIGH TRAFFICLight-Medium Use

RANGESee BL1706 - Key Override

MAINTENANCESilicon Lubricant, Not WD-40

POWERFully Mechanical, No Batteries

UNLOCK WITH

PIN Code

The Borg BL1006SCECP puts proper keyless access on cabinets, lockers, cupboards, and built-in joinery. It is a fully mechanical digital cam lock - a compact pushbutton keypad on the front, a rotating cam behind the door, and not a battery or wire anywhere in the system. Enter the code, turn, open.

The feature that lifts it above generic cabinet locks is Easicode Pro: the code is changed on the door, in place, without pulling the lock off. In a staff room, gym, clinic, or school where locker codes rotate with the people using them, that is the difference between a two-minute job and an afternoon of unscrewing doors.

Estimated Dispatch
Usually ships same day if ordered before 11am AEST (excludes weekends and Queensland public holidays).

Fully Mechanical - No Batteries Required
Entirely mechanical throughout: no power source, no wiring and no battery to go flat across a bank of lockers. See how mechanical digital locks work.

Designed for Light to Medium Use
Suited to cabinets, lockers, cupboards and joinery in staff rooms, gyms, clinics and schools, where codes change with the people using them.

Not Suitable for High Traffic Commercial Use
This is a cam lock for cabinets and joinery, not a door lock. For heavy duty door applications consider the Lockwood 3572DX, Borg BL7701, or Carbine CDL7200LL-HD.

Key Features

• Fully mechanical digital cam lock - no batteries, wiring, or electronics anywhere in the system.
• Easicode Pro on-door code changing - codes rotate in minutes without removing the lock from the door.
• Compact 41mm-wide footprint sized for cabinets, lockers, cupboards, and joinery.
• Single PIN code with over 500 possible combinations (Borg figure).
• Non-handed - the one unit suits left-hand and right-hand opening doors.
• Two cams and mounting hardware supplied - covers different cupboard constructions out of the box.
• Suits door material up to 25mm thick.
• Satin Chrome finish.

Access Methods

One method, done properly. The greyed row shows what this model leaves out - if you need a key fallback on a cabinet, the BL1706 sibling adds exactly that.

Method	Availability	Notes
PIN Code	Available	Single PIN, over 500 combinations - fully mechanical entry
Key Override	Not Available	No key cylinder on this model - see the BL1706 for a keyed version

Changing the Code - Easicode Pro

Easicode Pro - Codes Change on the Door
Locks without Easicode Pro come off the door to be re-coded On The Bench. Easicode Pro does the whole job in place, following the steps in the BL1006SCECP Operation Instructions V2 (PDF) - a genuine two-minute task once you have done it twice. Our code changing guide explains how the ECP method compares with the bench method across the Borg range.

The steps, from Borg's sheet: With the door open: enter the existing code; press and hold the * button with a suitable tool and keep it held until the new code is entered; press C to clear; enter the new code; release the * button; press C to set. Then test the new code five times, watching the cam turn, before you close the door. If you make a mistake, press C while the * button is still held and start the new code again.

What's in the Box

• 1 x Borg BL1006SCECP mechanical digital cam lock
• 2 x cams
• Mounting hardware

Suitable Uses

This is the mechanical digital answer for anything cupboard-sized: staff lockers, medication and first-aid cabinets, stationery cupboards, gym and pool lockers, tradie van drawers, server and comms cabinets, and school or clinic joinery. Anywhere a shared key currently gets lost, copied, or carried home, a code on the door solves it without adding batteries to the maintenance list. It is internal-only hardware - not weather resistant, so outdoor cabinets and wet areas are out of scope.

Available Finish Options

•
  Satin Chrome
  (This Product)
  STK BL1006SCECP

Finish selection does not affect functionality, compliance, or performance.

This is currently the only finish for this model. For a black MG Pro 2 cam lock for outdoor cabinets, see the BL1706, which adds a key override.

Borg Cam Lock Family

Full Specifications

Dimensions

The front keypad unit stands 110mm high by 41mm wide, with a 22mm body depth and 40mm overall projection. The second drawing shows the rear fixing unit and cam arrangement on the same 41mm-wide plate - see the drawings for fixing centres and cam profiles, full size on the Dimensions tab.

Front keypad unit

Rear fixing unit and cam

Frequently Asked Questions

Can this lock be retrofitted to existing cabinets?
Yes - the compact cam lock format is the usual retrofit choice, provided the existing door cut-out and cam clearance suit. The horizontal and vertical drilling templates on this page let you check the hole pattern against your door before ordering.

Does this cam lock require batteries?
No. It is a fully mechanical digital lock - no batteries, no wiring, no charging, ever. That is precisely why the format suits banks of lockers: nothing to flatten across fifty doors. Our plain-English explainer covers how battery-free keyless entry works.

How is the code changed?
On the door, using the Easicode Pro method in the operating instructions - no need to remove the lock. The steps are under Changing the Code. Each lock accepts a single PIN at a time, so changing the code immediately retires the old one.

Is this lock suitable for external or wet areas?
No. It is intended for internal use only and is not weather resistant. For coastal or exposed conditions on cabinet doors, the BL1706 sibling carries the Marine Grade Pro coating.

What door thickness and construction does it suit?
Door material up to 25mm thick - standard melamine, MDF, plywood, and metal locker doors all fall within that. Two cams are supplied to cover different cupboard constructions; check the drilling templates for the cut-out.

Additional Information

Mounting Height:
Fit the lock so the keypad sits at a comfortable height for the people actually using it - on tall locker banks, that usually means the second row from the top, not the top row.

Buying for a Locker Bank:
Order one spare unit with the batch: a spare on the shelf turns any future damage into a ten-minute swap.

Code-Only Management:
Code-only access has a management upside: no master key to control, and no key copies to track - the code list is the whole system. New to the category? Chapter 16 of the Buyer's Guide covers how the Borg, Lockwood and Carbine mechanical ranges divide the work.

Recovering a Forgotten Code:
Borg's operating instructions show how to recover the current code from the lock: loosen the grub screw on the code cover plate, slide the plate up, then rotate it to read the code, which shows in red. Keep the operating instructions (PDF) with your locker records, and test every new code five times with the door open before you close it.

Maintenance:
Monthly: wipe the keypad and knob with a light spray of silicon-based lubricant (such as GT85) and remove the excess with a soft cloth. Do not use oil-based lubricants such as WD-40 - they attract dirt and wear down internal parts over time. Annually: remove the lock from the door, spray the inside through the code piece holes on the reverse of the keypad with silicon-based lubricant, spray the fixings and the cam with silicon-based lubricant, then press each button and turn the knob several times to confirm smooth operation. Full steps are in the Borg Lock Servicing Guide (PDF).

Warranty

Borg Locks Warranty - 12 Months (Australia)
All Borg locks are warranted against mechanical defects in materials and workmanship under normal use and service for a minimum of 12 months from date of sale. The warranty does not cover damage arising from misuse, vandalism, or improper installation. The lock must not be dismantled - doing so will invalidate the warranty. Proof of purchase required for all claims.

Purchased through Terry's Tradies Pty Ltd or one of its associated trading names? Contact us first - we will manage your warranty claim with the Australian distributor (LSC) on your behalf. This warranty operates alongside your rights under the Australian Consumer Law.

Returns & Warranty | Borg Locks Australia Warranty Statement (PDF)

Download PDF Resources

Borg BL1006SCECP Operation Instructions V2 (PDF)
Borg's two-page sheet written for this lock: the Easicode Pro code change steps, code recovery through the code cover plate, and an exploded diagram of the lock body.

Borg BL1000 ECP Series Horizontal Drilling Template (PDF)
Fold-along template for drilling a horizontal BL1000 ECP series cam lock, with mirrored sets for left and right door edges - two 8mm fixing holes and one 10mm cam hole per set. Print at 100%.

Borg BL1000 ECP Series Vertical Drilling Template (PDF)
Fold-along template for drilling a vertical BL1000 ECP series cam lock - two 8mm fixing holes and one 10mm cam hole, 88mm between fixing centres. Print at 100%.

Borg Lock Servicing Guide (PDF)
Borg's general maintenance guide for pushbutton keypad locks - monthly silicone-based lubricant care and an annual full service. This is the routine to follow for this lock.
